Title: Rigid Flex PCB at EFPCB
1
WELCOME TO EFPCB.COM
Wwww.efpcb.com
T 86-755-23724206
E sales_at_efpcb.com
S shawnwang2006
2
MICROWAVE PCB, RADIO FREQUENCY PCB, TLY-8 PCB,
F4BM255 PCB, LOW DK PCB
Part No. E0215060179A Layer Count
2 layerMaterial FR4, 0.5mm,TLX-8-200, 1 OZ for
all layerMinimum tack 16 mil Minimum
space(gap) 16 mil
Minimum hole 0.5mmSurface finished LF
HASL Application Telecommunication
equipment, antenna main board
3
TS16949 Certified PCBLF HASL PCB Part No.
E0215060179ALayer count2 layerMaterial FR4,
1.6mm, 1 OZ for all layerMinimum tack 6 mil
Minimum space(gap) 4 milMinimum hole
0.20mmSurface finished Lead free HASLPanel
size 108198mm/8up
4
High frequency PCB Rogers4350 FR4 PCB Part
No. E0415060179A Layer count 4 layerMaterial
FR4, 1.6mm, high TGRO4350B, 1 OZ for all layer
Minimum tack 8 mil Minimum space(gap) 8
milMinimum hole 0.30mmSurface finished
ENIGPanel size 5838mm/1up
5
High Thermal Conductive PCB Part No.
M0125060189A Layer count 1 layer metal core
PCBMaterial Aluminum core, 1.5mm, 1 OZ, 2.0
W/MK Minimum tack 25 mil
Minimum space(gap) 25 milMinimum hole
3.0mmSurface finished ENIEPIGPanel size
28258mm/1up
6
Our Organization
Our Milestones
7
