A Brief Introduction to UiPath ReFramework

1

• A Brief Introduction to UiPath ReFramework

2

• UiPath Robotic Process Automation is a global
  automation tool that assists businesses with
  Citrix automation, Windows desktop automation and
  many more. In 2019, UiPath became the first
  vendor to combine process mining and RPA with the
  purchase of both ProcessGold and Stepshot.
  UiPath's Commercial RPA technology is used by
  over 2,750 enterprise customers and government
  agencies to successfully deploy software bots
  that execute monotonous tasks.
• Through its comprehensive software platform,
  businesses are increasing productivity and
  improving customer experience across front-office
  and back-office processes. Taking this into
  consideration, in this article, well be shedding
  some light on UiPaths ReFramework and everything
  there is to it.

3
The Primary Purpose of Uipath ReFramework

• Uipath framework, also known as robotic
  enterprise framework, is a framework designed to
  assist developers in creating RPA procedures that
  are both quick and efficient. It is the UiPath
  Template, which has a well-written structure and
  is used to create a scalable large-scale solution
  using Queue Transactions. The Uipath framework is
  based on state machines in general which
  businesses can utilize as a foundation for all of
  their user interface initiatives.
• UiPath makes use of the ReFramework because it
  makes tasks considerably easy for developers. The
  Robotic Enterprise Framework can retry failed
  transactions, re-initialize apps, and handle
  exceptions appropriately without the need for
  human interaction. It also keeps track of all
  processed, failed, and successful transactions.
  As a result, the UiPath development uses the
  ReFramework to create a strong and speedy
  procedure.

4
UiPath ReFrameworks Architecture Unique
Features

• Every project in ReFramework contains a
  "Main.Xaml file" that employs the State machine
  workflow. This file is utilized to make the
  process flow more visually appealing. Three state
  activities, one final state activity, and seven
  transitions are included. Moreover, transitions
  have been established for each state.
• The state machine diagram is used in the Robotic
  Enterprise Framework, which contains four states
• 1. Init state
• 2. Get the status of a transaction
• 3. Complete the transaction state
• 4. State of the Process at the End
• All of these states work together to complete the
  business transaction in the following manner

5

• Init State
• In the ReFramework, every robotic process
  automation project begins in the Init stage. The
  bot reads the initial project settings and starts
  the application in this condition. The
  transaction advances to the next state Get
  Transaction Data.
• Get the status of a transaction
• After the Init state, the Get Transaction Data
  state comes next with two primary alternatives.
  If a new process is retrieved, it advances to the
  Process Transaction state otherwise, if all
  transactions have been processed, it advances to
  the End Process state.
• Complete the transaction state
• The Success state, Business Transactions, and
  System Error states are all possible outcomes in
  the process transaction state. The loop is
  completed and the following transaction data is
  taken into consideration in the success state.
  When a specific action is completed, the
  execution state returns to Get Transaction Data,
  resulting in the Business Rule Exception.
• The System Error transaction is used to walk
  through an error step by step. All applications
  are closed in this transaction, and the execution
  loops back to the Init state.
• State of the Process at the End
• This is the final state of the transactions after
  they have all been completed. In other words, it
  is utilized to bring the process to a close.

6
UiPath ReFramework Unique Features

• Now that you have a better understanding of
  UiPath Robotic Process Automation ReFramework
  architecture, lets shed some light on its unique
  features
• ? Reusability Developers can reuse the logic
  code efficiently. This is possible because the
  logic code is segregated from other components of
  ReFramework.
• ? Scalability The Robotic Enterprise
  Framework can deliver exception messages and
  retry a failed transaction several times.
• ? An effective logging system UiPath
  ReFramework has a good logging system for keeping
  track of the process and resolving errors.
• ? Handling Exceptions Exception handling is
  quite simple with UiPath ReFramework. When an
  exception occurs, the Robotic Enterprise
  Framework has the ability to take action. That
  way, users won't have to be concerned about
  process halts or other similar issues.
• ? Screenshots of errors ReFramework includes
  the ability to take a snapshot of the screen at
  the point where it fails, allowing you to see the
  unattended automation and troubleshooting.
• ? Consistency The variables, assets, and
  settings are all constant throughout the Robotic
  Enterprise Framework, making it simple to
  comprehend. The code standards also make it
  simple to pass the project on to another
  developer.

7
A Few Common Examples of UiPath Reframeworks

• Let's look at some of the most prevalent
  scenarios in which the Uipath Development Robotic
  Enterprise Framework makes things easier for
  business units.
• Scraping the Internet
• In web scraping, the ReFramework structure is
  extremely beneficial when users need to scrape
  data from numerous sources and feed it into a
  specific excel sheet. It is also beneficial when
  used for a specific purpose on a wide scale, such
  as financial markets, e-commerce, and others.
  UiPath Robotic Enterprise Framework becomes quite
  effective in making the process fast and
  error-free.
• Inventory Control is Important.
• For stock management, many merchants rely on
  outdated legacy systems. The ReFramework bots
  examine the systems on a regular basis and
  provide data on vital indicators. Items with low
  supply levels or stocks that are constantly
  changing are a few examples that fall in this
  category.

8

• Onboarding of Customers and Users
• Customer onboarding is a difficult task in many
  B2C businesses. Customer onboarding activities
  can be completed in a single step utilizing the
  Robotic Enterprise Framework. This is especially
  important in companies that rely on outdated
  systems to improve the customer experience.
• Creating a Large Number of Emails
• Manually generating a large number of emails
  based on data from several platforms is
  difficult. As a result, for companies that need
  to send them regularly, UiPath ReFramework uses
  bots to automate the process hence making it
  easier.
• The Evaluation and Processing of Online Loan
  Applications
• UiPath Robotic Enterprise Framework can be used
  to create mediator bots between the online system
  and the mainframe. It asks the user to correct
  invalid entries using business logic. The Robotic
  Enterprise Framework also enables loan decisions
  and the generation of confirmation letters. These
  are the large-scale installations that may be
  observed in manufacturing, healthcare, banking,
  e-commerce, and a variety of other industries.

9
UiPath ReFramework to Handle Exceptions

• Users can use the UiPath ReFramework to get a
  high-level exception or anomaly handling
  appliance. It accomplishes this by retrying a
  failed transaction, recovering an application,
  and terminating the process. It actively works in
  situations where the robot's continued operation
  may cause more harm than good. Additionally, the
  UiPath Robotic Enterprise Framework enables users
  to save external settings in a Config.xlsx file.
• Also, instead of hard coding settings,
  Orchestrator Assets can be used. The
  exception/anomaly management section of UiPath is
  primarily concerned with handling mistakes
  related to various operations. There are four
  different error handling actions available for
  the same Rethrow, Terminate Workflow,
• ? When users want activities to display before
  the anomaly is thrown, they can utilize the
  Rethrow option.
• ? The Terminate Workflow activity is useful
  for terminating or ending a workflow when a task
  encounters an
• ? When the user wants to throw an error before
  performing a step, the toss action comes in
  handy.
• Source https//www.zenesys.com/blog/introduction-
  to-uipath-reframework
