Tiles & Ceramics Testing Instruments (1)

1
(No Transcript)
2
History

• At EIE, we always think and analyze the scenario,
  no matter what, from customers point of view. Be
  it, Quality of goods, delivery schedules or after
  sales service support, we always think of
  customers delight and satisfaction.
•  Thermal, Mass, Pressure Dimension parameters
  to ensure the genuineness of the products we
  supply. However, this is just beginning. We have
  lot more to offer.
• Undertaking sponsored research to develop
  specific product, if it is not found easily in
  the market.
• Technical assistance to the ceramic industries in
  improving quality, productivity cost reduction
• Training of personnel for QC Check to ensure
  immaculate products
• Rendering consultancy services turnkey solution
  of complete Laboratory set up

3
Product

• Bending strength testing machine
• Ceramic tile Flexural strength testing machine
• Ceramic tile bending strength testing machine
• ISO 10545-12 Frost resistance tester
• ISO 10545-5 Impact tester
• Impact resistance of ceramic tile
• Coefficient of restitution tester
• Ceramic laboratory testing equipment
• Tiles testing instruments
• Tiles laboratory testing equipment
• Tiles ceramic testing instruments

4
Bending strength testing machine

• Tile Dimensions (600 x 600 or 1000 x 1000 mm)
• Specialized machines for green or fired ceramic
  bar
• Exclusive range for ceramic fire bricks
• Complies with various parts of ISO regulations
• Compatible with servo-controlled stabilizers
• Add-on Software and mechanism to enhance the
  functioning
• Automatic operation
• Test unit selection between KG and KN
• Security settings like acrylic guard
• LCD display and digital modeling
• Accuracy rate of 0.2 of full scale

5
Ceramic tile Flexural strength testing machine

• Variety of models as per the ceramic tile size
• High load ratings
• Detachable fixtures available as accessories
• Compliant with ASTM standards for ceramic
• Apt for flexural strain and stress testing
• Suitable for the concave and convex sides of
  material
• Electromechanical and manual operation
• Force range from 10 kN to 2 MN
• Additional rollers available
• Fixtures have adjustable span

6
Ceramic tile bending strength testing machine

• Electronic display and electric operation
• Based on hydraulic load application
• Adheres to international export standards
• Determines resistance strength
• Loading capacity ranges from 500 to 6000 kg
• Ceramic tile dimension from 60 x 60 to 1200 x
  1200 mm
• Adjustable loading limits
• Automatic data processing
• Variety in terms of load and size combination
• Sleek and Trendy design

7
ISO 10545-12 Frost resistance tester

• Temperatures ranges from 20º C to 20ºC
• Different grades of steel used for body and
  fabricating interior
• Flawless powder-coated finish to add to look and
  feel
• Consistent temperature across the interior of the
  machine
• Provision for vertical tile placement
• In-built tank for immersing tiles
• Automatic timer for freezing, thawing, and
  immersing
• In-built drain valve for ease of cleaning and
  replacing fluid
• Ceramic tile dimension 60 x 60 mm

8
ISO 10545-5 Impact tester

• Our ISO 10545-5 impact tester is a ball release
  test apparatus which is based on the coefficient
  of restitution principle that helps you to gauge
  the impact resistance of an object.
• Body made from steel
• Powder coated finish
• Steel ball dropping mechanism
• Chrome plated ball finish
• Ball diameter ranges from 19 to 0.05 mm
• Electrical operation including automatic timing
  device
• Ball drop height specifier

9
Impact resistance of ceramic tile

• Works of coefficient of restitution principle
• Comes with a sturdy main machine and a steel ball
  for impact
• Diameter of ball varies from 19 0.05 mm
• The ball is chrome plated
• The height of ball drop can be adjusted up to 1
  m.
• Steel body with powder-coated finish
• Slender and sleek design
• In-built device to track time between impact
  intervals

10
Coefficient of restitution tester

• Designed to perfectly fit in your labs
• Fabricated with steel
• Finished with powder-coating
• Equipped with a steel ball with chrome finish
• Based on ball drop testing mechanism
• Laced with timing device for measuring intervals
• Capable of providing direct readings through
  controlled reader
• Perfect for testing with drop height of 1m

11
Ceramic laboratory testing equipment

• ISO 10545 ceramic testing instruments
• IS 13630 ceramic testing instruments
• Dimension gauging instruments
• Density and absorption testing instruments
• Bending strength testing instruments
• Frost testing instruments
• Impact testing instruments
• Abrasion and thermal testing instruments
• Skid resistance testing instruments

12
Tiles testing instruments

• Impact resistance testers
• Bending strength testers
• Frost resistance testers
• Thermal testers
• Water Absorption testers
• Dimensions testers
• Abrasion-prone testers
• Universal testers
• Flexure testers

13
Tiles laboratory testing equipment

• ISO compliant
• Made from quality material
• Automatic and semi-automatic operation
• Digital display
• Sleek design and great finish
• Impact and skid resistance
• Bending and flexure
• Heat and frost resistance
• Skid and absorb rate
• Dimension deciphering

14
Tiles ceramic testing instruments

• Diverse machines for testing bending, reflection,
  dimension accuracy, etc.
• Instruments for testing resistance to impact,
  frost, abrasion, etc.
• Aesthetically designed with focus on finishing
  for longevity
• Automatic and semi-automatic operation
• Lightweight and easy to operate
• Digital display with LCD screen (in selected
  models)
• Accurate results backed by compliance to
  international standards
• Various models for different sizes of ceramic
  tiles
• In-built security and customizable features

15
Thank you
