techno design ppt

1
(No Transcript)
2
Company profile

• Techno Designs experts manufacture plants and
  equipment for mineral, paint, resin, chemical and
  pharmaceutical industries.
•  There are two manufacturing units covering 3000
  sq meters total industrial area in Vitthal Udyog
  Nagar in Anand, Gujarat (India).
• Started in 1993, Techno Designs has served the
  market of process industries by designing and
  manufacturing equipment for the process industry.
• In 2009, Techno Designs recognized the strong
  demand in the solids handling market and started
  the design and manufacturing of Solids Handling
  product.
• In 2011, Techno Designs entered into the business
  of design and fabrication of aluminum, stainless
  steel and mild steel silos, available in both
  welded and bolted construction.

3
Serving Industry

• Mineral processing industry
• Solid material handling industry
• Paints and Resins industry
• Specialized process equipment

4
Vision and Mission

• Customer First approach
• Excellence in supply and services
• Integrity to act truthfully without compromise
• To be a global leader in providing quality
  engineering solutions to make solids handling and
  processing effective, efficient and sustainable
  in India and abroad.
• Our products must match the global standards to
  provide quality supply and after sales service to
  satisfy all our customers

5
Company product

• Solids Processing
• Solids Handling
• Special Process Products
• Storage Silo Systems
• Resin Paint Industries
• Mineral Grinding Plant

6
Solid processing

• Ball Mills

• Rotary Dryer

• Techno Designs is a ball mill manufacturer with
  an experience in designing, engineering, and
  manufacturing over 150 grinding mills.
•  We deliver quality-approved batch type ball
  mills with sizes in the range of 1.5m x 2m and 3m
  x 7.5m and power ranging from 50 HP to over
  1000HP.

• Robust roller-type drive setup with heat guards
  for drive components
• Specially cast, machined and heat treated tough
  idler rollers and thrust rollers with long
  operational life
• Complete internal piping and baffle arrangement

7

• Air Classifier Manufacturer India

• Pin mills

• We are a leading Air Classifier Manufacturer
  India. Air classifiers are employed in industries
  to separate various particles in dry powder

• Techno Designs has worked in the field of
  commination for over 20 years and our pin mills
  have been developed based on such extensive
  experience in particle processing.

8
Solids Handling

• Rotary Airlock Valve

• Dual Tunnel Diverter Valve

• Cement industry where the handling of raw
  materials and mixtures requires high-quality
  rotary valves India.
• Plastics industry where a powerful and sturdy
  rotary valve is the need for economical and
  reliable handling of products and material.

• Plug with two separate channels
• Full Aluminum body with Stainless Steel pipe
  inserts
• Diverting angle of 40
• Position indicator Packaged with dual solenoid,
  limit switches and proximity switches

9

• Y-Type Diverter Valve

• Flap Type Gravity Diverter Valve

• Cast Iron body
• Distribution of conveying stream is achieved by a
  swivel throw-arm using a powerful rotary
  pneumatic actuator or Electrical actuators
• Ceramic lining provided on the inside.

• Fabricated Stainless steel and Mild steel
  construction.
• Square to round transitions available
• Sizes ranging from 6 to 30

10
Special Process Products

• Rotary Vacuum Dryer

• Pug Mills

• breaker bar, which is used to minimize lumps
  formation for the particle size decrease
• purging that are responsible for explosion proof
  surroundings
• Fixed scrapper blades to have scrapping rotating
  agitators for highly muggy material

• Heavy-duty irons
• Heavy-duty bearings
• Gears
• Pneumatic clutches
• Huge diameter shafts

11

• Plough Shear Mixer Manufacturer

• Bead Mill Manufacture In India

• Highly Efficient and productive shear mixers and
  blenders.
• Low processing time and quick processes.
• Low power requirements indicating savings in
  costs.
• Reliable for use in various gain-sizes of powder
  and pastes.

• Premixing
• Grinding
• Dispersing
• Having a team of quality analysts and
  supervisors, Techno Designs is able to bring
  intuitive and most consistent bead mill solutions
  at reasonable rates. To get a sample quote for
  your requirement, share basic information and
  specifications with us.

12
Storage Silo Systems

• Finished Silos

• Storage Silo Systems

• Aluminum, Mild Steel Stainless steel
  construction
• Welded/Bolted configuration
• Single/Double chamber silos
• Blending Mixing silos
• Silo accessories

• Our Silos are designed, fabricated, delivered and
  commissioned in an extensive range of
  applications.
•  Every silo is developed according to the
  customer's unique requirements and constraints

13

• Fluidization

• Load cell arrangement

• Both short skirt and long skirt silos can be
  provided with a load cell mounting arrangement
  for real-time weight monitoring.
• This gravimetric measurement system is provided
  with a control panel.

• Based on our assessment of the requirement, we
  provide air-pulsation based fluidization system,
  cloth or nozzles as an accessory for the silo
  system.
• This system ensures detachment of the bulk solids
  which are not free-flowing, thereby i n d u ci n
  g m ovum en t for the con sequel unloading.

14
Bolted Silo containerization

• For silos that are to be transported to remote
  locations, or exported, we provide the option of
  silos in bolted configuration.

15
Thank you
