Puzzle Parking with Wohr Combilift Series

1
PUZZLE PARKING WITHWOHR COMBILIFT SERIES
Add Title
2
Wohr possesses a wide range of puzzle parking
solutions, celebrating a success story that
extends back decades. Wohr installed its very
first Combilift puzzle car parking system in
1988, and the technology has been continuously
optimised and developed keeping pace with the
latest technical progress made in recent decades.
3
OPERATING CONCEPTS
The Combilift series from Wohr is a
semi-automatic, space-multiplying car puzzle
parking system that offers convenient parking in
the tightest of spaces by utilising the principle
of stacking vehicles and moving them closer
together. Wohr also facilitates the user-friendly
operation of the Combilift through a number of
easy operating concepts. The safety of the system
is a particular priority. The Combilift works
with an RFID chip as an operating device.
4
WOHR COMBILIFT SERIES
Wohrs Combilift puzzle parking system has been
designed for efficient usability, high levels of
functionality and ample availability. It comes in
numerous configurations now in order to make
parking even more convenient.
5
COMBILIFT 551
This multi level car parking system from Wohr
offers two parking levels without a pit and
provides independent parking. The lifting and
sliding of the parking platforms allow all
parking spaces to be accessed right from the
entrance level. There always remains one empty
space at the entrance level. This is a smart car
parking system wherein entrance level platforms
move laterally and those on upper levels move
vertically. When bringing down the upper platform
for parking, the entrance level platforms will
move to one side to provide an empty space into
which the desired platform is lowered.
6
COMBILIFT 552
When there is additional depth available, the
Combilift 552 multi level parking system can be
installed to add an extra parking row in front of
the Combilift 551, 542 or 543. Up to three units
of the Combilift can be arranged one behind the
other. Parking spaces are summoned using a
central operating device. Spaces that are in the
way of the desired space automatically slide to
the side, allowing users to park in the selected
space.
7
COMBILIFT 542
This is a pit puzzle parking system that offers
independent parking on 2 levels above one
another, and is ideal for when headroom is
limited. This system needs a clearance height of
only 2.20 m as a result of which, it can be built
into regularly sized underground parking areas.
8
COMBILIFT 543
This is a compact, space-efficient smart parking
system with three vertically stacked levels, with
the entry always at the middle level. An
operating panel is used to select the desired
parking space. Vehicles make their entry and exit
at the middle level. It allows up to 10 grids to
be placed next to each other and is operated with
a single operating device. The system can be
operated using an RFID tag, handheld transmitter
or the Wohr smart-parking app.
9
SAFETY GATES
Wohr recommends using safety gates to safeguard
against incidents of theft or vandalism and
prevent accidents caused by people loitering
within the system or drivers trying to park
before the platform is in place. Wohr offers a
range of safety doors for its Combilift series in
order to meet the individual requirements of its
customers - ranging from metal sheet, perforated
metal, and metal mesh doors to rolling
shutters. With these doors, Wohr hasnt just
focused on appealing design, but also on their
functionality. The materials and processing
methods used maximize the life of the doors and
ensure the safe parking of vehicles. The standard
doors offered are operated manually. Doors with
optional electric drives available as well.
10
WHY WOHR?
Wohr is well-known across the world among car
parking system manufacturers and offers a wide
range of car parking solutions including stack
car parking, puzzle parking systems, tower car
parking solutions, hydraulic parking,parking
platforms and turntables. WPS (Wohr Parking
Systems) has a proactive attitude and partners
with developers and architects - beginning at the
planning stage, to the configuration, design and
installation of customised solutions that
maximise parking space in the smallest area. WPS
manufactures its parking systems in its
leading-edge facility in Pune as per stringent
German standards. WPS offers quick and
trustworthy after-sales services. WPS also takes
up Annual Maintenance Contracts (AMCs) that
ensure that every Wohr parking system operates
effectively and safely for many years. For more
information, visit www.wohrparking.in
