HÖRMANN Perimeter Protection Systems Innovations
2022
2
Fixed bollards ST Simple bollardsF 275-M30-900
ST / F 275-M30-1200 STF 275-M50-900 ST / F
275-M50-1200 ST

• M30 / M50 certification (to be done)
• same design as FF, matchable with automatic
  bollards
• Available in normal steel and with SS-sleeve
• Possibility of LED lighting strip
• Possibility of marine anti-corrosion treatment
  for the internal cylinder
• Possibility to choosing welded cover plate

F 275-M30-900 ST / F 275-M30-1200 ST

• ADVANTAGES
• Entry level for fixed bollards HS range
• Simple bollards Good quality price ratio

F 275-M50-900 ST / F 275-M50-1200 ST
3
Fixed bollard SF with flat ground fittingF
275-M50-900 SF / F 275-M50-1200 SF1200F

• M50 certification (to be done)
• Very low fitting depth of only 200 mm, optionally
  300 mm, e.g. for using paving stones
• For fitting over supply lines laid in the ground
  or e.g. over parking garages
• Arrangement with any number of rows, with
  multiple bollards
• Flexible, individual angled arrangements possible
• Can also be used with gradients
• Reduced assembly thanks to fit modules
• Also available as a removable variant

4
Stainless steel sleeve for High Security Fixed
bollards

• Available for M30/M50 fixed bollards
• Replaceable stainless steel sleeve painted or
  brushed
• Easy replacement of the sleeve in case of
  accident or damage
• Possibility of choosing between standard cylinder
  cover (head) and welded cover
• Possibility of LED lighting strip
• Possibility of marine treatment for the internal
  cylinder

• ADVANTAGE
• Cheaper price compared to full inox

Standard cylinder cover (head)
Welded cover
5
Customizable covers

• Make it unique! Cylinder cover surface can be
  customised, e.g. with a city crest or a logo, on
  request
• Choose between black/white or color engraving
• Available in stainless steel or other materials,
  on request

Luxury Hotel Logo, TURKEY
Heraldry of the municipality, GERMANY
MILAN City map, ITALY
6
RBS 1000 Dead-Man e Semiautomatic version

• M30 certification
• Platform height 1000 mm
• Integrated hydraulic operator
• Quick and easy fitting on finished ground
  surface, no excavation work required
• Convenient operation via web platform
• Three versions available
• Automatic
• NEW! Dead man's control, to improve the safety of
  the system
• -20 cheaper compared to the automatic model
• NEW! Semiautomatic, battery drill operated, ideal
  for less frequent use
• -30 cheaper compared to the automatic model

7
Kit Full Inox

• Special kit for bollards with stainless steel
  components (available on A 275-600 H and A
  275-800 H)
• Cylinder AISI 316
• Frame plate and cylinder cover plate
• Frame parts
• brackets for hydraulic pump
• component holder bracket kit
• head and crown
• hydraulic fittings kit
• kit 3 sideblocks upper stop brackets
• And also
• piston with anti-corrosion marine treatment

8
Kit full inox
Hydraulic fittings kit
Frame and cylinder cover head
Frame parts
Piston
