In-Line Test System

1
EQUIPTEST'S TEST SYSTEMS
www.equip-test.com
2
WE VALUE YOUR PRIVACY
We and our company and/or access information on a
device, such as cookies and process personal
data, such as unique identifiers and standard
information sent by a device for personalised
ads and content, ad and content measurement, and
audience insights, as well as to develop and
improve products. With your permission we and our
partners may use precise geolocation data and
identification through device scanning. You may
click to consent to our and our partners
processing as described above. Alternatively you
may access more detailed information and change
your preferences before consenting or to refuse
consenting. Please note that some processing of
your personal data may not require your consent,
but you have a right to object to such
processing. Your preferences will apply to this
website only.
www.equip-test.com
3
ABOUT US

• The Vecsés operation of Equip - Test focuses on
  high-complexity engineering in NPI and RD. In
  addition, our team develops solutions for the
  most difficult engineering challenges in the
  field of fixture customisation. The development
  of test programmes for automation, robotics, and
  testing is also done here. This is where the
  central warehouse, global technical support, and
  management are all located. We provide high-
  quality spring-loaded test probe for everyone. We
  deliver great quality products, quickly deliver
  along with amicable services. Visit our site
  https//equip-test.com/ to place your order for a
  high-quality and right fixture kit, ICT, FCT, RF.

www.equip-test.com
4
TRIO Test System

• Mount
• 19 Rack with Pylon Receiver Frame
• 12x Pylon Blocks
• TRI 5001T SII Tiny ICT Mainset
• ESD Safe

www.equip-test.com
5
TR5001 SII Series ICT
with LED Testing

• Features
• Max. 1080 LED Channels
• Non-Multiplexing 11 per Pin Architecture
• MDA ICT FCT
• High Accuracy
• High Throughput
• Quick Disconnection Interface
• Automatic Conveyor Width Positioning
• Board Warp and Mis-Alignment Notification

www.equip-test.com
6
TR5001 SII INLINE SERIES

• Features
• Features
• Multi-Core Parallel Tester
• Serial Test Controller with up to 8 ports on any
  pin
• PXI Ready
• Self Diagnostics
• Auto-Calibration function
• High-Accuracy Measurement
• SMEMA compatible
• Easy Program Development - Flow Based

www.equip-test.com
7
TR5001 SII QDI SERIES - ICT

• Features
• Flexible Multi-Core Parallel / Merged-Core
  Tester
• Serial Test Controller with up to 8 ports on any
  pin
• Light - Curtain Protected Press - Down Platform
• PXI Ready
• Built-in Self Diagnostics and Auto- Calibration
  function
• High-Accuracy Measurement
• Flow - based Easy Program Development

www.equip-test.com
8
THANK YOU
