Medical Oxygen Plant (2)

1
Medical Oxygen Plant
2
Introduction
01
Medical Oxygen Plant Types
02
CONTENTS
Compressed Air System
03
Air Separation Unit (ASU)
04
3
Introduction
A medical oxygen plant is a facility that
produces and supplies medical- grade oxygen to
hospitals, clinics, and other healthcare
facilities. The purpose of this presentation is
to provide an overview of the key components
and processes involved in producing medical
oxygen and its applications.
4
01
Medical Oxygen Plant Types
02 Liquid oxygen plants These plants produce
oxygen off- site and deliver it in liquid form
to the healthcare facility.
On-site oxygen generation plants These plants
produce oxygen on- site at the healthcare
facility using air compressors and filtration
systems.
Each type has its own advantages and
disadvantages that should be considered when
selecting a medical oxygen plant.
5
Compressed Air System
Compressor A device that compresses air to the
desired pressure. Air dryer A system that removes
moisture from the compressed air to prevent
corrosion and contamination. Filters A system
that removes contaminants from the compressed
air, such as dust and oil.
6
Air Separation Unit (ASU)

• The air separation unit (ASU) is the heart of a
  medical oxygen plant. It is responsible for
  separating air into its constituent parts,
  including oxygen, nitrogen, and argon. The
  process used to separate air is called cryogenic
  distillation, and it involves cooling the air to
  extremely low temperatures and separating the
  gases by their boiling points.
• The oxygen produced by the ASU must meet medical-
  grade purity standards, which require a minimum
  purity level of 99.5.

7
Thank you very much! Medical oxygen plants are
critical in providing life-saving oxygen to
patients in healthcare facilities. By
understanding the components and processes
involved in producing medical-grade oxygen, we
can ensure that we provide the best possible
care to patients who need it. Visit https//www.
nitrogenium.co.in/medical-oxygen-plant.php Mail
i'd info_at_nitrogenium.co.in
