• Arduino Pro Mini ATmega328 3.3V
• ? 13845 Views
• IN STOCK SKU RM000940
• ? 293.82
• (inc GST)
• ? 249.00 ( 18.00 Gst Extra )
• Product Highlights
• 131 Powerful Instructions Most Single Clock
  Cycle Execution Up to 20 MIPS Throughput at 20
  MHz
• Two 8-bit Timer/Counters with Separate Prescaler
  and Compare Mode One 16-bit Timer/Counter with
  Separate Prescaler, Compare Mode, and Capture
  Mode
• Real Time Counter with Separate Oscillator

DESCRIPTION
The Arduino Pro Mini is intended for advanced
users who require flexibility, low-cost, and
small size. It comes with the minimum of
components (no on-board USB or pin headers) to
keep the cost down. Be sure to provide the
correct power and use components whose operating
voltage matches that of the board. The board
comes without built-in USB circuitry, so an
off-board USB-to-TTL serial convertor must be
used to upload sketches. This can be a FTDI
TTL-232R USB - TTL Level Serial Converter Cable
for the 5V Arduino Mini Pro), or a FTDI
TTL-232R-3V3 USB - TTL Level Serial Converter
Cable. One quick way to connect these is by
inserting a six-pin 0.1" male pin header into the
end of the FTDI cable or breakout board, and
pressing it against the six hole programming
header on the Mini Pro. If, however, you're
going to be uploading lots of sketches to your
Pro Mini, you'll probably want to solder some
pins (male headers) to the holes. The board can
be powered through USB via the six-pin
programming header, or from a regulated 5V
(depending on the model) supply applied to the
VCC pin or an unregulated supply on the RAW
pin. Any standard 0.1" spaced header can be
soldered to the holes on the Arduino Pro Mini. To
use every pin requires two 12-pin headers, plus a
six pin header for programming, if desired. Bare
wire can also be soldered directly to the
holes. ATMEGA 328 Specifications 131 Powerful
Instructions Most Single Clock Cycle Execution
Up to 20 MIPS Throughput at 20 MHz Two 8-bit
Timer/Counters with Separate Prescaler and
Compare Mode One 16-bit Timer/Counter with
Separate Prescaler, Compare Mode, and Capture
Mode Real Time Counter with Separate
Oscillator Six PWM Channels 8-channel 10-bit ADC
in TQFP and QFN/MLF package Programmable Watchdog
Timer with Separate On-chip Oscillator On-chip
Analog Comparator 23 Programmable I/O Lines
