ProDDS Multiparameter Water Quality Meter | Hoskin

1
PRODSS MULTIPARAMETER WATER QUALITY METER
HTTPS//HOSKIN.CA/
2
OVERVIEW
The YSI ProDSS (digital sampling system) handheld
multiparameter water quality meter provides
extreme flexibility for the measurement of a
variety of combinations for dissolved oxygen,
turbidity, conductivity, specific conductance,
salinity, resistivity, total dissolved solids
(TDS), pH, ORP, pH/ORP combination, ammonium
(ammonia), nitrate, chloride and temperature
along with depth and GPS.
3
(No Transcript)
4

• The YSI ProDSS (digital sampling system) is a
  portable water quality multiparameter instrument
  for the measurement of several critical
  parameters dissolved oxygen (optical), total
  algae, turbidity, pH, ORP, conductivity, specific
  conductance, salinity, TDS, resistivity, TSS,
  ammonium, ammonia, chloride, nitrate, depth
  (optional), temperature and GPS coordinates.
• Designed for use in applications such as surface
  water, groundwater, coastal/estuarine,
  aquaculture, and wastewater, the rugged and
  reliable ProDSS allows for the measurement of
  water quality parameters with digital sensors.
  The ProDSS water quality meter uses smart sensor
  technology that allows sensors to be
  automatically recognized by the handheld while
  retaining calibration data.
• An easy-to-read backlit color display, large
  memory capacity, simple calibration procedures,
  rechargeable battery and powerful data management
  program (KorDSS) all help to make your sampling
  experience more convenient.
• The optional GPS and depth along with a wide
  range of cables and sensors (sold separately)
  allows for complete customization of the ProDSS.
  Military spec connectors, IP-67 waterproof
  rating, rubber over-molded case and 1-meter drop
  tests ensures durability to provide years of
  sampling even in the harshest field conditions.

5

• Parameters Available
• PH
• OXIDATION REDUCTION POTENTIAL (ORP)/REDOX
• OPTICAL DISSOLVED OXYGEN
• TURBIDITY
• CONDUCTIVITY
• SPECIFIC CONDUCTANCE
• SALINITY
• TOTAL DISSOLVED SOLIDS (TDS)
• RESISTIVITY
• DENSITY
• TOTAL SUSPENDED SOLIDS (TSS)
• AMMONIUM
• AMMONIA
• CHLORIDE
• NITRATE
• DEPTH
• TEMPERATURE
• TOTAL ALGAE (TAL)

6

• There are multiple features of the ProDSS water
  quality meter
• SINGLE CABLE DESIGN WITH LENGTHS UP TO 100 METERS
• USER-REPLACEABLE CABLES PROVIDE VERSATILITY,
  REDUCE DOWN TIME AND REDUCE OVERALL COST OF
  OWNERSHIP
• 4 PORT CABLES FEATURE USER-REPLACEABLE SENSORS
  UNIVERSAL PORTS CAN ACCEPT ANY 4 SENSORS
  OPTIONAL DEPTH SENSOR AVAILABLE (WITH DEPTH AND
  NO DEPTH)
• ODO/CT PROBE AND CABLE ASSEMBLIES FEATURE
  INTEGRAL (BUILT-IN) OPTICAL DO AND CONDUCTIVITY
  SENSORS RUGGED ODO SENSOR CAP WITH 2-YEAR
  WARRANTY IS PRE-INSTALLED ON NEW ASSEMBLIES KITS
  WITH AN ODO/CT ASSEMBLY AND A PRODSS HANDHELD ARE
  AVAILABLE
• LONG-LIFE RECHARGEABLE LITHIUM-ION BATTERY TO
  POWER HANDHELD AND SENSORS
• COLOR DISPLAY AND BACKLIT KEYPAD MENU-DRIVEN
  OPERATION
• DIGITAL SMART SENSORS ARE AUTOMATICALLY
  RECOGNIZED BY THE INSTRUMENT AND STORE
  CALIBRATION DATA
• LARGE MEMORY (gt100,000 DATA SETS) WITH EXTENSIVE
  SITE LIST AND DATA ID TAG CAPABILITIES
• KORDSS SOFTWARE (INCLUDED) AND USB ON-THE-GO
  CONNECTOR ASSIST WITH DATA MANAGEMENT
• GLOBAL POSITIONING SYSTEM (GPS) (OPTIONAL)
• RUGGED, WATERPROOF CASE (IP-67 RATED) WITH RUBBER
  OVER-MOLD AND METAL, MILITARY-SPEC (MS) CABLE
  CONNECTORS AS WELL AS RUGGED TITANIUM SENSORS
• MULTIPLE LANGUAGES ENGLISH, SPANISH, PORTUGUESE,
  FRENCH, GERMAN, ITALIAN, JAPANESE, NORWEGIAN,
  CHINESE (SIMPLIFIED AND TRADITIONAL), KOREAN, AND
  THAI
• 3 YEAR INSTRUMENT WARRANTY 2 YEAR CABLE WARRANTY
  (SENSOR WARRANTIES VARY)
