Omega Graphite

1
Omega Graphite
https//www.omegagraphite.com
2
https//www.omegagraphite.com
About Us

• Chemical Process equipments in Graphite
  construction find extensive use in application
  handling highly corrosive media.
• Impervious Graphite is used as construction
  materials in Process equipments used for Heating,
  Cooling, Condensing, Evaporating and
  Distillation, Absorption, mixing reaction and
  other processes involving highly corrosive media.
• Graphite has high thermal conductivity excellent
  resistance to corrosion and thermal shock. This
  makes graphite the most suitable material for
  Heat Trans for equipments handling corrosive
  media.
• Omega Engineering Corporation is involved in the
  manufacture of a wide range of Graphite
  Equipments India, Mumbai, UAE, Saudi Arebia
  Brazil.

3
Products

• Cubic Block Type Graphite Heat Exchangers
• Cylindrical Block type Graphite Heat Exchangers
• Falling film HCL Absorbers
• Sulfuric Acid Dilutors
• Vacuum Ejector Systems
• Graphite Components Shapes
• Graphite Cement
• Graphite Powder

https//www.omegagraphite.com
4
Cubic Block Type Graphite Heat Exchangers

• Cubic block type Graphite Heat Exchangers have
  number of cube shaped Graphite Blocks Assembled
  and bolted together. Each cubic block has two
  sets of holes one set of holes runs axially throw
  adjacent blocks carrying corrosive process. We
  are the best Manufacturer, supplier of Cubic
  block type Graphite Heat Exchangers in Mumbai,
  India, UAE Saudi Arebia, Brazil. media while
  another set of holes run perpendicular to the
  axial holes carrying service media. Heat transfer
  takes place by conduction through the Graphite
  material separating the two sets of holes. Cast
  Iron end covers carry and channelize the service
  media from one block to the other.Cubic Block
  Heat exchangers are available in horizontal and
  vertical mounting designs. Cubic Block Heat
  exchangers are extensively as Heaters, Coolers
  and Condensers using liquid as heating or cooling
  media

https//www.omegagraphite.com
5
Cylindrical Block type Graphite Heat Exchangers

• Cylindrical Block type Graphite Heat Exchangers
  have a number of Cylindrical blocks stacked
  together in vertical position and encased in
  steel shell. Rows of vertical and horizontal
  holes carry process and service media. Heat
  Transfer take place by conduction through the
  Graphite material separating the two sets of
  holes.Cylindrical Block Graphite heat
  exchangers are generally used in vertical
  mounting designs.These are extensively used as
  Heaters, Evaporators, Coolers Condenser.

https//www.omegagraphite.com
6
Falling film HCL Absorbers

• Falling film HCL absorbers is similar in
  constructional design to Cubic Block Graphite
  Heat Exchangers in vertical Position.It has a
  number of Cubic shape Graphite Block stacked
  together vertical alignment on top of the stock
  of blocks is mounted a distributor block evenly
  distributing Absorption water through wires into
  vertical holes. This creates a thin film of water
  flowing down to the inner surface of the
  holes.Hydrogen chloride Gas flowing
  co-currently down words is continuously absorbed
  into the film of water. Heat of mixing is
  continuously carried away by cooling water
  passing through the horizontal holes in the
  Graphite blocks.

https//www.omegagraphite.com
7
Sulfuric Acid Dilutors

• Sulfuric Acid dilutor cooler is used for
  continuous production of desired dilute sulfuric
  Acid of desired concentration and temperature.
  Its design is similar to cubic block Graphite
  Heat Exchanger fitted with a mixing head at
  Inlet.Dilution water and concentrated Acid
  flowing through concentric passages mix in the
  mixing head and flow through multiple pass cubic
  block heat exchanger to achieve thorough mixing.
  Cooling water passing through the service side
  cools the mixture simultaneously to produce cool
  Sulphuric Acid of desired concentration and
  temperature at the outlet. As no moving
  components are used in the equipment, it is
  preferred over convensional mixers and coolers

https//www.omegagraphite.com
8
Vacuum Ejector Systems

• Vacuum Ejector Systems in Graphite construction
  find extensive us in chemical plants handling
  corrosive media under high vacuum conditions.
  Single and multi-stage ejectors employing up to
  four ejectors in combination with Graphite
  Condensers of appropriate Heat transfer areas are
  successfully employed in creating high vacuum in
  Large volumes.Graphite Ejectors arse available
  in solid graphite construction as well as in
  Graphite lined in steel constructions.Ejector
  System use both water as well as steam as motive
  fluid - passing through high density Graphite
  Nozzles. Water Ejectors in Graphite construction
  find extensive use in Gas scrubber.

https//www.omegagraphite.com
9
Graphite Components Shapes

• Various Components, Spares and Shapes are
  available in various Grades of Graphite - virgin
  Graphite for high temperature applications as
  well as Resin impregnated Grades for Pressurised
  corrosive fluid handling applications.These
  include Heat Exchanger blocks, Column Sections,
  Grid plates, Sparges, column components nozzles,
  Raschig rings and others for corrosive media
  handling duties.Virgin Graphite Components in
  Extruded, Isotropic and ISO static grades in
  coarse- and fine-grained construction are
  available for metallurgical and other high
  temperature applications.

https//www.omegagraphite.com
10
Graphite Cement

• Graphite cement in two component system with
  modified furan resin binder and Graphite filler
  is available for joining Graphite Components,
  Fire clay components and as other anticorrosive
  linings.

11
Graphite Powder

• Graphite powder of various mesh sizes and high
  purity are avail for use in foundry, Lubricants
  and others.

https//www.omegagraphite.com
12
Contact Us

• Email ifo_at_omegagraphite.com
• Call Us Now 919820045787
• Visit Our Website https//www.omegagraphite.com

• Address
• 106, Gurunanak Industrial Estate, L.B.S. Road,
  Bhandup (w), Mumbai - 400078, India.
• info_at_omegagraphite.com
• 022-62934212
