YKM International LLC

1
(No Transcript)
2
R
DEVELOPMENT
POLICY
We believe to provide the permanent solution with
best quality at competitive price. Our Corporate
Policy is to work as a partner with our clients.
YKM Group is a Branded Wire Mesh Manufacturer
YKM
WWW.YKMGROUP.COM
COMPANY
INTRODUCTION
YKM RD is the result of combination of
information and resource from technical,
production sales department. Our team consist
of 2 material engineers, 4 weaving engineers, 4
painting engineers, 2 electronic engineers, 2
mechanical engineers, 2 IE engineers an 1 Switzer
professor with more that 40 years experience in
wire mesh industry.
Established in the 1984. YKM Group is the MENA
Subdivision of YingKaimo Metal Net Company Ltd
has always been one of the leading choice for
metal wire meshes across the world. Our annual
sales volume has been over 50 million, 90 of
which are from overseas, covering over 70
countries and regions.
YKM comprises of two factories with a total
production area of 156,000 square meters. In
2003, Our Quality Management System EMS was
certified to meet ISO9001 ISO14001 standards.
Subsequently we established our International
Office in Dubai, UAE in 2004.
YKM self-developed epoxy coated wire mesh, fuel
cell mesh, exhaust emission control system mesh,
Auto safety system mesh, Oil industry mesh are
environmental and clean energy oriented and
innovative alternative solutions. Our laboratory
is qualified with corrosion limit test, metal's
inner structure analysis and the assessment of
filtration stability, which can offer
environmental simulation and data support for new
product development.
www.ykmgroup.com
sales_at_ykmgroup.com
01
3
S.S. Mesh Weaves
PLAIN WEAVE
TWILL WEAVE
Warp wire crosses alternately above and below
every weft wire and vice versa. Warp and weft
wires are normally of the same diameter. Used for
the majority of commercial applications and for
filtration where a high flow rate is required.
Each weft wire passes alternately above and below
every successive pair of warp wires and vice
versa. This mesh weave permits a heavier wire
diameter to be used than a plain weave with
similar mesh count.
WWW.YKMGROUP.COM
PLAIN DUTCH WEAVE
TWILL DUTCH WEAVE
Plain dutch weave is the combination of dutch
weave and plain weave. Each warp wire with coarse
wire diameter passes alternately over and under
one weft wire to supply high tensile strength for
the netting.
Twill dutch weave is the combination of dutch
weave and twill weave. The weft wires passes
alternately over and under two warp wire forming
a finer mesh in the warp direction and the warp
wires forms a coarser mesh in the warp direction
in the same weaving.
REVERSE PLAIN DUTCH WEAVE
REVERSE DUTCH TWILL WEAVE
Reverse dutch weave is the same as plain Dutch
weave but the warp and weft wires are woven in
reverse. Thin warp wires are placed close
together and woven with thicker weft wires, which
creates higher strength in the warp wires.
It is Reverse of Plain Dutch Weave in a twill
pattern, which reduces the deformation of the
warp wire, this cloth is very stable and
particularly strong in the warp direction with a
high flow rate.
www.ykmgroup.com
sales_at_ykmgroup.com
02
4
S.S. Mesh Solutions
WWW.YKMGROUP.COM
Stainless Steel Square Mesh Dutch Weave Mesh
with PDW, TDW, RDT for Sand Control Screen.
Stainless steel special alloy mesh over 1000
meters in length used in three way catalytic
convertors kinds of precise slitting mesh
individual packing solution.
Optimized Square Mesh, Dutch Weave Mesh, (Plain
Dutch Weave, PZ80) for leaf filters. Mesh
Grades 304, 316L, 317L, 904L etc
Square or 5 Heddle Mesh for packing structure,
1000 meter in length or as per client's
requirement Precise cutting available.
www.ykmgroup.com
sales_at_ykmgroup.com
03
5
S.S. Mesh Solutions
AUTOMOTIVE
WATER TREATMENT
NEW ENERGY
Mesh for Gasoline Filters, Hydraulic Filters,
Frequency Damper, Air Bags and more.
Filter Cylinder Wire Cloth, Basket Filter Screen
Mesh, Mesh Screen for Settling Tank other
Seperation Equipments.
Catalyst Screen for Molten Carbonate, Alkaline,
Solid oxide, Phosphoric acid Fuel Cells and more.
WWW.YKMGROUP.COM
AEROSPACE
FOOD BEVERAGE
CERAMIC
Vertical Horizontal Pressure Leaf Filter
Screen, Hops, Rotary, Dewatering, Grains Flour
Filter Screen and more.
Acoustic Supression Screen, Fuel Filters, Air
Oil Filters, Engine Protection Screens and more.
Filter Screen for Hot Gas Filter, Bag Filters,
Ceramic Vibrating Screen and more.
OIL GAS
PETROCHEMICAL
CONSTRUCTION
Hot Gas Bag Filters, Sand Control Shale
Shaker Screen, Demister Pads Mesh and more.
Depth, KO, Melt Blown Filter Screen, Sintered
Mesh for Coalescence Filter Screen and more.
Filter Screen for Screening Separation, Gutter
Guards, Infill panels, Foundation vents and more.
PHARMACEUTICAL
SCREEN PRINTING
AGRICULTURE
Analytical Sieve Screen, Tablet Coating Rollers,
Surgical Tray Mesh and more.
SS316 SS316L Mesh for Screen Printing and more.
Drip, Gravel, Media Filter Screens more.
www.ykmgroup.com
sales_at_ykmgroup.com
04
6
Other Mesh Types
Nickel Mesh
Copper Mesh
Copper wire mesh is a highly durable material
with excellent conductivity property. Raw
Material Red Copper, Brass (H65, H80) Phosphor
Bronze (CSn6.50.4). Weaving Pattern Square Mesh
(Plain Weave, Twill Weave) Knitted, Coarse.
Nickel Wire Mesh is made of pure nickel with
nickel content of 99.5 or more. The material is
highly resistant to oxidation and corrosion.
Raw Material Pure Nickel Weaving Pattern
Nickel Woven Mesh, Nickel Knitted Mesh, Nickel
Stretching Mesh, Nickel Punching Mesh.
WWW.YKMGROUP.COM
Low Carbon Steel Mesh
Epoxy Coated Mesh
Low carbon steel mesh is a kind of wire mesh made
of various carbon steel wires through warp and
weft woven pattern Raw Material Q195, Q235,
C1006, 72A, 82B, 65Mn, etc. Weaving Pattern
Square Mesh (Plain Weave, Twill Weave) Dutch
Weave Mesh (Plain Weave, Twill Weave)
Herringbone Mesh.
Epoxy Coated Mesh are optimized primarly for
Hydraulic Filters after years of R D Research.
Raw Material Low Carbon, Galvanized Iron,
SS304, SS316 Weaving Pattern Plain Weave
www.ykmgroup.com
sales_at_ykmgroup.com
05
7
Other Mesh Solutions
Nickel Mesh is widely used in the production of
alkali and hydrogen electrolysis cell electrodes,
battery electrodes, current collecting mesh,
shielding radiation, special gas liquid
filtration, and more.
WWW.YKMGROUP.COM
Epoxy coated mesh find its major application as
both main layer and support layer for hydraulic
filters, air filters, fly screens and more.
Copper mesh have its primary application as RFI
Shielding in Research Centers, Ceramic printing,
Gas-liquid Filtration, Military Shelters, Modular
Containers etc. to shield against external
frequency and more.
YKM Group's dedicated R D Team is constatly
engaged in analysis of industrial physical
scenario and developing optimal mesh that cope up
with the situation. Our industrial experience has
enabled us with manufacturing of optimal
Stainless Steel, Nickel, Epoxy, Aluminium, Low
Carbon Steel Mesh at custom mesh count and size
based on client's demand.
www.ykmgroup.com
sales_at_ykmgroup.com
06
8
Manufacturing Equipments
WWW.YKMGROUP.COM
Automatic ZWJ looms can produce 20 mesh to 635
mesh for square mesh, 3600 dutch mesh, with
0.018"-0.0006" wire dia and 70" maximum width.
These looms perform very stable, easy to
maintain. The mesh length can reach over 1000
meters with good surface quality.
Jager looms have following DFS, DS, DMA, DM
etc., whose weaving range is from 1 mesh to 50
mesh with 0.157"- 0.0074" wire dia and 79"
maximum width, which are suitable for plain
weaving and crimp weaving. These looms are
mainly for mid-heavy square mesh or dutch weave
mesh because of its big wefting force and tight
weaving, especially for high quality oil and
petro oil completion filtration process.
RGK-VII is numerical control loom. The mesh range
from 14 mesh to 110 with 0.018" - 0.0059" wire
dia and 50" max width can provide good surface
quality, suitable for large batch continous
weaving and easy to control mesh aperture,
thickness and weight by machine advanced tension
algorithm.
www.ykmgroup.com
sales_at_ykmgroup.com
07
9
Quality Control Equipments
WWW.YKMGROUP.COM
Portable Radiation Detector
Innov-X Systems XRF Analyzer
C.S. Analyzer
Under the help of experts in NIM (recognized by
CIPM and BIPM), by the end of 2007, YKM
introduced radiological detection equipment for
inspecting raw material and finished product to
protect personnel from the damage of radioactive
contaminants.
With the condition full of oxygen and
high-temperature heating, the Carbon and Sulphur
get transformed into CO2 and SO2. C.S. Analyzer
analyse exact Cabon, Sulphur composition inside
the metal and hence distinguish between 304
304L 316 316L, etc.
The XRF Analyzer is the internationally advanced
analyzer specialized in metal chemical analysis,
it can exactly analyze chemical components within
30 seconds. Permanent testing records can
gurantee the traceability of raw material quality.
Micro Hardness Testing Machine
Photodosimeter
Electrical Testing Machine
It is a high-precision device with non-contact
online measurement with optical, fast-data
collection and micro programming technology. Test
range with wire diameter 0.01mm-2mm tolerance
/-0.0001mm.
Test the materials mechanic performance, like
elongation, rupturing, peeling, cutting, bending,
compressing etcs. It can calculate the max.
force, yield strength, average peeling force,
max. deformation, yield point, elastic modulus
etc.
It tests the objects's indentation hardness which
test the object's indentation capacity against
other objects. This machine is mainly used for
hardness testing of stainless steel wire.
www.ykmgroup.com
sales_at_ykmgroup.com
08
10
Mesh Specification
Square Mesh
Meshes Per Linear Inch Wire Diameter Width Of Opening Open Area
Meshes Per Linear Inch mm mm Percent
11 4 21.4 71 .0
22 2.5 10.2 64.0
33 2 6.4 58.0
44 1.6 4.75 56.0
44 1.19 5.16 65.9
55 1.4 3.68 52.0
66 1.2 3.03 51.0
88 1.1 2.08 42.0
1010 1 1.54 36.0
1010 0.51 2.03 64.0
1212 0.584 1.52 51.8
1212 0.508 1.6 57.2
1414 0.584 1.22 45.2
1414 0.508 1.3 51.0
1616 0.457 1.13 50.7
1818 0.432 0.98 48.3
2020 0.508 0.76 36.0
2020 0.406 0.86 46.2
2424 0.356 0.7 44.2
3030 0.33 0.52 37.1
3030 0.305 0.54 40.8
3030 0.229 0.62 53.1
3535 0.279 0.45 37.9
4040 0.254 0.38 36.0
Meshes Per Linear Inch Wire Diameter Width Of Opening Open Area
Meshes Per Linear Inch mm mm Percent
5050 0.229 0.28 30.3
5050 0.203 0.31 36.0
6060 0.191 0.23 30.5
6060 0.178 0.25 33.9
7070 0.165 0.2 29.8
8080 0.165 0.15 23.0
8080 0.14 0.18 31.4
9090 0.127 0.16 30.1
100100 0.114 0.14 30.3
100100 0.102 0.15 36.0
100100 0.089 0.17 42.3
110110 0.1016 0.1295 30.7
120120 0.094 0.1168 30.7
150150 0.006 0.1041 37.4
160160 0.0635 0.0965 36.4
180180 0.0584 0.0838 34.7
200200 0.0533 0.0737 33.6
250250 0.0406 0.061 36.0
270270 0.0406 0.0533 32.2
300300 0.0381 0.0457 29.7
325325 0.0356 0.0432 30.0
400400 0.0254 0.037 36.0
500500 0.0254 0.0254 25.0
635635 0.0203 0.0203 25.0
WWW.YKMGROUP.COM
www.ykmgroup.com
sales_at_ykmgroup.com
09
11
Twill Dutch
Reverse Twill Dutch
Mesh Count Per Inch Wire Diameter Inches Absolute Filter Rating Microns Nominal Filter Rating Microns
20250 .0098.0079 110-120 98-105
30360 .0098.0060 90-100 80-84
40560 .0070.0040 70-75 47-52
80700 .0040.0030 35-40 24-26
200600 .0024.0018 28-32 19-21
165800 .0028.0020 24-26 14-16
1651400 .0028.0016 16-18 09-11
2001400 .0028.0016 12-14 05-06
2501400 .0022.0016 11-12 03-04
3252300 .0015.0010 08-09 02-03
400x2800 .0011x.0008 05-06 -
YKM-Code Mesh Wire Diameter (µm) Wire Diameter (µm) Micron Retention (µm) Micron Retention (µm) Porosity Theory () Weight (kg/m2) Cloth Thickness (mm)
YKM-Code Mesh Warp Weft Nominal Absolute Porosity Theory () Weight (kg/m2) Cloth Thickness (mm)
RFD400 8414 - - - 450-530 62 3.5 1.15
RFD125 26040 - - 125 112-125 54 2.25 0.62
RFD90 17040 - - 90 106-118 54 2.1 0.57
RFD85 17537 - - 85 100-106 54 2.1 0.57
RFD80 13030-35 200 380 80 95-105 57 2.7-3.10 .77-.80
RFD60 17540-50 150 300 60 65-72 55 2.1-2.40 .57-.60
RFD40 28060-70 90 200 40 54-60 56 1.34-1.55 .38-.40
RFD25 600100-105 42 140 25 34-38 57 .75-.80 .22-.23
RFD20 630125-130 42 125 17 22-26 53 .75-.85 .20-.22
RFD15 720140-150 35 110 15 16-20 52 .65-.70 .15-.18
WWW.YKMGROUP.COM
Plain Dutch
Mesh Count Per Inch Wire Diameter Inches Absolute Filter Rating Microns Nominal Filter Rating Microns
885 014.0126 318-340 250-255
1264 .024.0165 270-285 200-205
1488 .020.013 225-245 150-155
20150 .0098.007 155-165 100-105
24100 .015.010 115-125 80-85
30150 .009.007 95-100 65-70
40200 .007.0055 65-70 55-60
50250 .0055.0045 55-60 40-45
80400 .0049.0028 43-48 35-40
www.ykmgroup.com
sales_at_ykmgroup.com
10
12
CERTIFICATES
WWW.YKMGROUP.COM
ACHIEVEMENTS
www.ykmgroup.com
sales_at_ykmgroup.com
11
13
YKM GROUP
www.ykmgroup.com
Sharjah Head Office Store. 1 2, Sharjah,
UAE Mob 971 58 677 7772 E-Mail
sales_at_ykmgroup.com
Anping Factory No.128 Ping'an East Street, Anping
county, Hebei, China Mob [phone]
293 E-Mail trade_at_yingkaimo.cn
De Zhou Factory Jinghua Road South, Dezhou,
Shandong, China Mob [phone] E-Mail
trade_at_yingkaimo.cn
ykmwiremesh
ykmwiremesh
ykm_wiremesh
ykm_wiremesh
ykm_wiremesh
ykm_wiremesh
ykm_wiremesh
ykm_wiremesh
ykm_wiremesh
_at_ykm_wiremesh
