7262947 532385807 AHL TFL TMS Headlight Driver Module

1
7262947 532385807 AHL TFL TMS Headlight Driver
Module
2
7262947 03 532385807 AHL TFL TMS Headlight Driver
Module for bmw cars. AHL/TFL TMS Module is
factory fitted on 5 Series F10 F11 Pre-Facelift
and F07 GT with Xenon Adaptive Headlamps and D1S
35W Gas Discharge HID bulbs. Module is
responsible for light levelling also know as
vertical aim control, LED Angel Eyes (Halo Rings)
Daytime Running Lights and front turn signal
indicator lights. Please double check provided
BMW and LEAR part numbers to make sure it is
correct part for your car. Each headlight uses
one 726294703 module unit, coding is required
after replacing part, otherwise vertical aim
won't work.
3

• Most common BMW warning messages
• Daytime/parking lamp malfunction
• Parking/daytime lights
• Left turn signal malfunction
• Right turn signal malfunction
• Headlight Vertical Aim Control Failure
• Headlamp vertical aim control malfunction
• Turn indicator front right failure
• Adaptive headlights failure
• Adaptive headlight malfunction
• Adaptive Lichtsysteme defekt
• Leuchtweitenregulierung defekt

Please note This list is not full, for a
complete list of warning messages visit our
website.
4

• BMW part numbers
• 7262947 03
• 726294703
• 7262947 02
• 726294702
• AHL/TFL
• AHLTFL

• LEAR part numbers
• 532385807 04
• 53238580704
• 532385807 02
• 53238580702
• 532385807 03
• 53238580703

Please note This list is not full, for a
complete list of part numbers visit our website.
5

• Compatible BMW Cars
• 5 Series F10 Saloon Sedan Pre-Facelift 2010 2011
  2012 2013
• 5 Series F11 Estate Touring Pre-Facelift 2010
  2011 2012 2013
• 5 Series F07 GT Gran Turismo Pre-Facelift 2008
  2009 2010 2011 2012 2013T LCI Facelift 2014 2015
  2016 2017
• 520i 523i 528i 530i 528xi 535i 550i M5 petrol
  gasoline
• 520d 525d 530d 535d diesel xDrive M-Sport
• 5 Series F07 G

6
CONTACT US
www.xenons4u.co.ukinfo_at_xenons4u.co.uk
