Process of Production Of Kamdhenu TMT Bars

1
PROCESS OF PRODUCTION OF Kamdhenu TMT BARS

• The TMT process

2
PROCESS AUTOMATION
The TMT process is widely accepted as the best
process for production of high quality rebars
since the technology uses low cost raw materials
against costly alloy elements but results in the
same high mechanical properties ensuring
excellent weldability, ductility and bendability
a notable saving in alloy cost per ton. The
process involves heating of steel billets in a
Reheating furnace and rolling them through a
sequence of rolling stands which progressively
reduce the billet to the final size and shape of
the reinforcing bar.
3
PROCESS OF PRODUCTION OF TMT BARS
The production process of TMT bars involves
several stages that transform raw materials into
the finished steel bars suitable for construction
purposes.

• Raw Material

• Raw material yard - In this section we maintain
  proper stock and sort them according to size. We
  then sample it for chemical testing as per
  IS1786.

Pusher
Pusher - Chemically OK tested raw material
comes to pusher pushed into the re-heating
furnace.
4
PROCESS OF PRODUCTION OF TMT BARS

• Re-heating furnace

• Re-heating furnace - Raw material is heated up to
  1200(/-50) degree centigrade. So that it becomes
  ready for hot rolling

Roughing mill
Roughing mill - Properly heated raw material
first enters into roughing mill and is rolled
into different shapes.
5
PROCESS OF PRODUCTION OF TMT BARS

• Intermediate Mill

• Intermediate mill - After getting finished by
  roughing mill raw material comes into
  intermediate mill.

DC drive continuous mill
DC drive continuous mill - From this section of
RMD(rolling mill division) we get 25, 20, 16, 12,
10, 8 mm TMT bars.
6
PROCESS OF PRODUCTION OF TMT BARS

• Quenching box

• Quenching box - We have an advanced technology
  for producing TMT Bars. When bar enters this
  quenching box, it comes in contact with
  continuous high pressure and flow of water which
  hardens the outer surface of bar while the inner
  core remains soft.

Cooling bed
Cooling bed - After passing through Quenching box
, bars are laid down on cooling bed where natural
cooling of bars occur.
7
PROCESS OF PRODUCTION OF TMT BARS

• Cold shearing

• Cold shearing - At this shearing machine we can
  cut the required length of TMT bars, before
  sending for bundling to yard section.

8
PROCESS OF PRODUCTION OF TMT BARS

• At last, samples are collected for final testing.
  Ok tested finished goods are now bundled
  dispatched.

https//www.kamdhenulimited.com/process-automation
.php
