REYNOARCH Façade Specialists
1.Management team has an effective experience
of more then 2 decades
2.Factory is located in Kothputli
Rajasthan. 3.Manufacture ACP, FR ACP, ZCP, HPL
Honeycomb panels 4.Pan India presence,
5.Production capacity is around 22.5 m Sqft/ Annum
3
REYNOARCH FR Aluminium Composite Panels
Now what prompted us to discuss use of FR
GradeACP to High traff i c, High risk projects
like Airports are the followingFi re accidents
whereinvestigators found out the primary
cause/culprit of Fast spreading of Fireis the
extensive use of PE (Polyethylene) Core A CP
4
REYNOARCH FR Aluminium Composite Panels
The government all around the world including
India has laid down stringent Fire Safety
guidelines rulesfor External Façades. Most of
theseGovts made it mandatory to use OnlyFR ACPin
all Government projects with heavy human traffic.
In India
For ACP it is IS 17682-2021 For FR ACP it is IS
733-1983
5
Faç ade/A CP Fi re accidents
Grenfell Tower Fire, May 2017,
6
Façade/ACP Fire a ccide nts
Fire in Dubai Marina Tower, UAE
7
Façade/ACP Fire a ccide nts
Fire in Dubai Marina Tower, UAE
8
Façade/ACP Fire a ccide nts
Fire Accidents due to Faulty ACP
9
REYNOARCH FR A2 B1 Aluminium Composite Panels
We add following Inorganic Fire Retardant
Agents in PE to make FR Core Aluminium Hydroxide,
Magnesium Oxide,
Alumina Trihydrate (ATH) Stablizers
These agents are added in Polyethylene in
proportion for achieving different grades of FR
Core like A2, B1 Grades.
A2 Grade FR ACP Ratio forA2 Grade FR ACP Core
we have 90 Inorganic Compound 10 Plastic
B1 Grade FR ACP Ratio for B1 Grade FR ACP core
we have 70 Inorganic Compound 30 Plastic
10
REYNOARCH FR A2 B1 Aluminium Composite Panels
REY NOARCH FR Grade ACP has been tested for
EN 13501-1, ASTM E-119 ASTM NFPA 285 along
with general testing for the physical
mechanical properti es
We have done these testing in NABL Accredited
ATMY Labs, Faridabad
By doing these test we have addressed most of the
parameters, like
Flame Spread Toxic Fumes Dripping
11
(No Transcript)
12
(No Transcript)
13
REYNOARCH ZINC COMPOSITE PANELS (ZCP)
A 100 Year Product
14
For Unique Projects made in Bharat
15
REYNOARCH ZINC COMPOSITE PANELS (ZCP)
Zinc Composite Panel takes cladding dreams
several notches higher. Super endearing, natural,
durable and magnificent. The top layer of ZCP
(Z-A) is of zinc-titanium (Zn-Ti), and the bottom
layer
is of aluminium. It s available in FR grades
core.
ZCP combines the natural beauty of zinc, with the
flatness, durability, ease of fabrication and
cost effectiveness with all the benefits
of composite panels
Titanium zinc alloy absorbs greenhouse gas,
carbon dioxide and develop a natural zinc
carbonate patina which does not only protect the
surface, but also removes scratches and
imperfections over time.
This PATINA has a lifetime potential of over 100
years,
16
REYNOARCH ZINC COMPOSITE PANELS (ZCP)
Environment-Friendly Zinc is a natural element.
It can be recycled at a rate of 90 to 100
percent. This is why it uses less energy at the
time of production and have a second life after
it comes off. Combining a high recycle-rate with
a low maintenance rate and a long life cycle
equating into lower costs. The use of Zinc
enables buildings qualify for LEED points. Part
of the beauty of zinc comes from its natural
colour. This means no additional paints, sprays,
or other treatment is needed.
Consequently, no Volatile Organic Compounds
(VOCs)healthy indoor environmental quality.
17
REYNOARCH ZINC COMPOSITE PANELS (ZCP)
S pe cifica tions
4mm thickness Skin of ZINC Alloy on top
Aluminium skin at the back for composite panels
. Environment friendly, Natural beauty, Self He
a ling.
Width 1220mm,1020mm, 1000mm Length 2440mm
Exterior Interior application,
Lifetime FOREVER warranty.
18
HoneyComb Cladding
19
REYNOARCH Honeycomb Panels (AHP)
Why
Reyno arch
Honeycomb
Compos ite Panel
Aluminum Honeycomb P anels are e xtre me ly res
ilient and to ugh. The y als o ha ve exceptional
peel strength and toughnes s .
20
REYNOARCH Honeycomb Panels (AHP)
NEW GENERATION OF ADVANCED MATERIALS FOR BUILDING
AND INDUSTRY
ReynoArch is a panel formed by two aluminium
skins bonded to an aluminium honeycomb core,
forming a ?nal structure with ideal properties
for facade applications. It is made of aluminium,
an fully recyclable metal.
HONEYCOMB Technology
The main properties of the Reynoarch Honeycomb
panels are - High rigidity - Lightness -
Flatness - Compressive strength - Easy
machining - Good behaviour to fire and smoke
21
REYNOARCH Honeycomb Panels (AHP)
22
REYNOARCH Honeycomb Panels (AHP)
Aluminium Fire Resistant A2 Grade
Reynoarch Aluminium Honeycomb Panels it self
offer good fire resistance performance which meet
A 2 grade.
Fire Protection Reynoarch A luminium Honeycomb
Panels has replaced LDPE core with
non-combustible core which prevents from spread
of f ire.
Fire Classification
23
REYNOARCH Honeycomb Panels (AHP)
A pplications
P anel Di mensi ons
24
HPL
25
90 Degree Bendable HPL , with color warranty of
12 Years
26
Rivet less Façade with HPL
27
Conca ve Convex s hapes on HPL
28
Pergola CNC
29
Pergola
30
Canopy
31
(No Transcript)
32
(No Transcript)
33
Fin Ventilated Louver Solution makes Façade
Amazing
34
(No Transcript)
35
Aluminum Composite Fin and Fluted Louvers
12 Years Color Warranty Highly Durable
Light weight Variety of Colors Ventilation
Airflow control Recyclability
Fire resistance
36
3D Way Application of ACP
37
3D way Application of ACP
38
Rustic ACP sheets/High Pressure Laminates A
Replacement of Corten Steel
39
Rustic Series of Reynoarch ACP sheets and HPL
sheets
Real Effect of Corten Steel
No Rusting Problem Like In Mild Steel
Not Heavy like Mild Steel
No Color Variation Easy to Install Light Weight
40
Rustic Finish is the New Fashion !!
41
??? Beauty lies in rustic simplicity
42
WPC Exterior Fluted Louvers
43
Embrace Real Beauty of Fluted Louvers
44
Our Customers in India
