Discover Creature Industry's Masala Pouch Packing Machine

1
MASALA
SET-UP MACHINE
Parking No. 3, Piyush Tower, E-110, Transport
Nagar, Lucknow, Uttar Pradesh 226012
2
TRAY DRYER MACHINE
Uses- To Remove Moisture from Spices ?????-
???? ?? ??? ?? ????? ?? ???
No. of Trays Temprature Range Structure Capacity Rate
6 Trays 50-300 degree celcius Contact Part - SS (Trays) Non-contact Part - MS 50-60 kg/hr (Depend On Material) 35,000/- GST Extra
12 Trays 50-300 degree celcius Contact Part - SS (Trays) Non-contact Part - MS 100-120 kg/hr (Depend On Material) 50,000/- GST Extra
24 Trays 50-300 degree celcius Contact Part - SS (Trays) Non-contact Part - MS 200-250 kg/hr (Depend On Material) 95,000/- GST Extra
3
BLOWER PULVERIZER
Uses- To Grind All Spices ?????- ????? ????? ??
???
Model No. Chamber Size Capacity Rate WITH MOTOR
CIBPHP2 8''X4'' 15-20KG/HR 35,000/- GST Extra
CIBPHP3 10''X5'' 25-30 KG/HR 40,000/- GST Extra
4
BLOWER PULVERIZER
Uses- To Grind All Spices ?????- ????? ????? ??
???
Model No. Chamber Size Capacity Rate WITHOUT MOTOR Rate Crompton Motor (1440 RPM)
CIBPHP5 12''X6'' 50-55 KG/HR 50,000/- GST Extra 20,000/- GST Extra
CIBPHP7.5 14''X8'' 70-80 KG/HR 65,000/- GST Extra 30,000/- GST Extra
CIBPHP10 16''X9'' 90-100 KG/HR 85,000/- GST Extra 32,000/- GST Extra
CIBPHP15 20''X10'' 130-140 KG/HR 1,05,000/- GST Extra 52,000/- GST Extra
CIBPHP20 24''X12'' 180-190 KG/HR 1,15,000/- GST Extra 58,000/- GST Extra
CIBPHP25 28''X14" 200-250 KG/HR 1,30,000/- GST Extra 72,000/- GST Extra
5
IMPACT PULVERIZER
Rate Without Motor
Coal ?????
Turmeric ?i?
Motor Crompton 1440 RPM
Sandal Wood ????
Salt ???
Gram Flour ????
Kattha ? ?
Model No.
60,000/- GST Extra
28-30 kg/hr
35-40 kg/hr
35-40 kg/hr
35-40 kg/hr
35-40 kg/hr
28-30 kg/hr
CI-IP-HP5 CI-IP-7.5HP CI-IP- HP10
19,500/-
65,000/- GST Extra
60-65 kg/hr
70-80 kg/hr
45-50 kg/hr
45-50 kg/hr
35-40 kg/hr
75-80 kg/hr
30,000/-
70,000/- GST Extra
80-90 kg/hr
100-120 kg/hr
55-60 kg/hr
55-60 kg/hr
45-50 kg/hr
100-120 kg/hr
32,000/-
6
IMPACT PULVERIZER
CAPACITY (In kg/hr) CAPACITY (In kg/hr) CAPACITY (In kg/hr) CAPACITY (In kg/hr) CAPACITY (In kg/hr) CAPACITY (In kg/hr) CAPACITY (In kg/hr)
Model No. Turmeric ?i? Gram Flour ???? Coal ????? Sandal Wood ????. Kattha ? ? Salt ??? Rate Motor Without Crompton Motor 1440 RPM
100-120 kg/hr 120-140 kg/hr 65-75 kg/hr 65-75 kg/hr 50-55 kg/hr 120-140 kg/hr 1,25,000/- 45,000/- GST Extra
150-180 kg/hr 160-180 kg/hr 80-90 kg/hr 80-90 kg/hr 60-65 kg/hr 160-170 kg/hr 1,35,000/- 58,000/- GST Extra
200-220 kg/hr 180-200 kg/hr 90-100 kg/hr 90-100 kg/hr 70-75 kg/hr 180-200 kg/hr 1,45,000/- 72,000/- GST Extra

CI-IP-HP15 CI-IP-HP20 CI-IP- 25HP
7
MS VIBRO SHIFTER MACHINE
USES- TO SEIVE POWDER SPICES ????? - ????? ??
????? ?? ???

0.5 HP THREE PHASE GST Extra
1 HP THREE PHASE GST Extra
Size
Motor
Capacity
Rate
70-80 KG/HR (DEPEND ON MATERIAL)
24" SINGLE DECKER
80,000/-
80-100 KG/HR (DEPEND ON MATERIAL)
30" SINGLE DECKER
85,000/-
8
FLAT GRADER
CAPACITY POWER TRAY SIZE RATE
50 TO 60 KG/HR (AS PER MESH) ONLY 0.5HP (3/PH) L-2FEET X W-1FEET X H-2FEET 38,000/- GST Extra
200KG/HR (AS PER MESH) ONLY 0.5HP (1/3PH) L-3FEET X W-1.5FEET X H-3FEET 52,000/- GST Extra
500KG/HR (AS PER MESH) ONLY 0.5HP (1/3PH) L-4FEET X W-3FEET X H-3FEET 68,000/- GST Extra
9
PACKING MACHINE ??? ?? ????
MODEL NO. WEIGHING CAPACITY SEALER SIZE MAX OPEN ROLL SIZE RATE
LD 50 Single Head 1-50 gm 135mm 240mm 95,000/- GST Extra
LD 100 Single Head 1-100 gm 135mm 240mm 1,15,000/- GST Extra
LD 500 Single Head 15-500 gm 200mm 420mm 1,85,000/- GST Extra
LD 1000 Double Head 50-1000 gm 300mm 580mm 3,20,000/- GST Extra
10
PACKING MACHINE
??? ?? ????
BAND SEALER MACHINE(SEMI-AUTOMATIC) ? ? ????
???? ???? ????? ?? RATE - 18,000/- GST
EXTRA AUTOMATIC POUCH PACKING MACHINE ????? ??
???? ?? ?? ????
BAND SEALER MACHINE
HAND SEALER MACHINE ?? ???? ???? RATE- 3,000/-
(GST EXTRA)
HANDY BATCH CODER MACHINE ???? ??? ???? RATE-
20,000/- (GST EXTRA)
11
BANK DETAILS

• P R O P R I E T O R S A D I Y A B A N O
• O U R B A N K D E T A I L S
• C O M P A N Y N A M E C R E A T U R E I N D
  U S T R Y B A N K N A M E A X I S B A N K
• B R A N C H A D D R E S S A A S H I A N A ,
  L U C K N O W B R A N C H C O D E 1 8 7 8
• A C C O U N T N U M B E R 9 2 0 0 2 0 0 5 6 5
  0 4 8 2 9
• I F S C C O D E U T I B 0 0 0 1 8 7 8
• TERMS AND CONDITION
• DELIVERY TIME 10 -15 DAYS AFTER YOUR ORDER WITH
  ADVANCE PAYMENT.
• PAYMENTTERMS 100 ADVANCE PAYMENT IN CASE OF
  BANK FINANCING.
• 25 ADVANCE IN CASE OF SELF-FINANCING REST 75 TO
  BE PAID BEFORE DELIVERY OF MACHINE
• PACKAGING FORWARDING WILL BE CHARGED EXTRA AS
  ACTUAL.
• IN CASE OF COSTUMER WANTS PETTY PACKING THEN IT
  WILL COST AS PER THE MACHINE SIZE.
• INSTALLATION THE INSTALLATION AND DEMO SERVICE
  WILL BE PROVIDED. BUYER SHOULD PAY ENGINEERS
  ROUND WAY TICKET, FOOD AND ROOM
• (ALL LABORCHARGES ACCORDING TO MACHINE). COMPANY
  WILL COMMUNICATE THE DAY AND TIME SLOT OF THE
  SCHEDULED INSTALLATION AND
• DEMO THROUGH A CALL FROM HEAD OFFICE (OIL
  EXPELLER AND PATTHAR CHAKKI INSTALLATION WILL NOT
  PROVIDE BY COMPANY.)
• COMPANY WILL PROVIDE ONLY 1 VISIT FOR THE
  INSTALLATION, REST VISIT ARE FOR SERVICE. BUYER
  MUST ARRANGE ALL NECESSARY REQUIREMENTS LIKE
  ELECTRICITY WIRING, ELECTRICITY SUPPLY RAW
  MATERIAL ETC.
• THE AUTHORIZED SERVICE ENGINEER WILL PROVIDE
  DETAILS DEMO THAT INCLUDES- USAGE OF PRODUCT.
  EXPLAIN ALL THE FUNCTIONALITY
• OF THEPRODUCT. PREVENTIVE MAINTENANCE ACTION TO
  BE TAKEN.
