Why the Invacare Oxygen Concentrator Beeps?

1
Ilvagare Oxygel Colgellralor is Beepilg, Whal
Does Il Meal?
N O V E M B E R 1 2 , 2 0 1 9 K E V I N L Y O N
S

• When your patients oxygen concentrator will not
  stop beeping what should you do?
• Invacare oxygen concentrators have an audible
  alarm which is a safety feature. The Invacare
  Oxygen Concentrator will Beep for any one of the
  following reasons
• Loss of power
• User error
• System failing to produce enough Oxygen
• Lack of oxygen ??ow
• The unit is overheated
• There is little red green and yellow LED lights
  on the front panel of the concentrator which will
  help you distinguish what problem may be
  occurring.
• The following will help you discern what the
  problem may be

1) Alarm Is Sounding But No Light Are On.
This is a power loss. Try unplugging and re-plug
the unit in, if this doesnt work be sure the
breaker switch on the front of the machine is not
tripped. If that does not work plug something
else into the outlet you have the oxygen
concentrator plugged into to see if there is
power at the outlet
2
If none of these those suggestions take care of
the problem you may have a bad power cord, bad
switch, or some wiring came loose, call your
repairman.
2) Alarm Is Sounding And The Red Light Is On.
This may also be a power issue so try the
suggestions in step one. If those to not ??x it,
it could be your cabinet ??lters are clogged and
you unit is overheated. Remove and clean the
cabinet ??lters located on the side of the Oxygen
concentrator. After that you may need to wait a
few minutes until the Invacare oxygen
concentrator cools before it will come back on
again.
3) Alarm Is Beeping And The Green Light Is On
This is caused by lack of oxygen ??ow. Check to
make sure the ??ow meter is turned up enough (has
to be above .5 L/min). Another common problem is
that something is blocking your line or it is
kinked, be sure the line is not kinked and free
of all obstructions, also be sure the line is
clear and not clogged with debris.
Read About Important Electrical Safety
Inspection Information for Medical Equipment
4) Yellow Or Red Light Illuminated
Start by checking all everything in the ??rst 3
steps and if you still are not having any success
with clearing the alarm, it is likely the oxygen
purity level is not su??cient or the concentrator
has an internal leak. The concentrator has to
produce an O2 level of over 92. This can be
measured with an oxygen sensor. If the
Concentrator is delivering under 92 oxygen it is
possible that the sieve beds need replaced, call
your local medical equipment repair company to
have repair this or it may be time to purchase a
new oxygen concentrator.
3
5) The Green With Yellow Light Is Flashing
This means there is a problem inside the machine,
only a medical equipment service provider will
be able to help you. Contact Now.
