SINAMICS V90: Future-Proofing Your Automation System

1
SINAMICS V90 Future-Proofing Your Automation
System

• Naksh Technology

2
Introduction

• Automation systems are central to achieving
  heightened efficiency, precision, and scalability
  across various sectors. However, as  important as
  these systems are, they face significant
  challengescomplex installation processes,
  integration issues with existing technologies,
  and a constant need for upgrades to handle
  evolving industrial demands.
• A good example of this technological breakthrough
  is the Siemens SINAMICS V90 servo drive system,
  which provides a reliable solution suited to
  modern industrial requirements. This article
  explores how the SINAMICS V90 not only enhances
  current operational capabilities but also ensures
  businesses are equipped for future challenges,
  setting a new standard in automation excellence.

3
What is SINAMICS V90?

• The SINAMICS V90 is a highly optimized servo
  drive system designed to meet the versatile
  demands of motion control applications. This
  system, comprising the Siemens V90 servo drive
  and the SIMOTICS S-1FL6 servo motor, is
  engineered for a wide range of applications,
  making it a cost-effective solution that enhances
  the competitive edge of businesses by reducing
  time-to-market.
• Performance With features like a 1 MHz pulse
  train setpoint and 20-bit encoder resolution, the
  system achieves high positioning accuracy,
  essential for precision-driven processes. The
  drive and motor offer a 300 overload capacity,
  which, along with fast acceleration and braking
  capabilities, significantly boosts productivity.

4

• Design The robust design of the Siemens V90
  includes PCB coating and high-quality bearings,
  enhancing the system's reliability even in harsh
  environmental conditions. Integrated safety
  functions like STO (Safe Torque Off) provide
  additional security, preventing unexpected motor
  movement and ensuring the safety of both
  machinery and operators.
• Ease of Use Commissioning the SINAMICS V90 is
  straightforward, thanks to the SINAMICS
  V-Assistant, a standalone graphic configuration
  software that simplifies setting parameters,
  jogging, troubleshooting, and monitoring. This
  user-friendly approach ensures quick setup and
  minimal downtime.

5
SINAMICS V90 Servo Drive Capabilities

• The V90 servo drive system, designed for optimal
  performance and easy operation, includes a range
  of features tailored for efficient automation.
  Below is a table highlighting key attributes and
  capabilities of the system

6
Feature Description
Power Range 0.05 to 7.0 kW, accommodating both single and three-phase networks.
Motor Compatibility Specifically paired with SIMOTICS S-1FL6 servo motors for enhanced performance.
Communication Interfaces Multiple options including PTI, PROFINET, USS, or Modbus RTU for versatile integration.
Drive Sizes Available in eight converter frame sizes and seven motor shaft heights to suit various applications.
Cooling Designed to operate without external cooling heat dissipation through the motor surface.
Installation Features quick-release connectors for fast and straightforward installation.
Overload Capability Capable of handling a threefold overload, ensuring robust operation under demanding conditions.
Commissioning Plug-and-play setup with minimal configuration needed for quick commissioning.
Control Compatibility Integrates seamlessly with Siemens SIMATIC PLC control systems for streamlined automation.
7
Application Across Industries

• The Siemens V90 is suitable for diverse
  applications such as pick place, labeling,
  horizontal packaging, and printing. Its ability
  to manage both simple and complex motion control
  tasks makes it a preferred choice for industries
  looking for a reliable and efficient automation
  solution.
• Coupled with the SIMOTICS S-1FL6 servo motor, the
  V90 servo drive system showcases its flexibility
  and efficiency across a broad spectrum of
  industries.
• Manufacturing and Production Control In the
  manufacturing sector, the Siemens V90 drive
  system is frequently utilized for precise
  position and speed control, essential for
  assembly lines and automated production
  processes. The integration with SIMATIC S7-1200
  and S7-1500 PLCs via PROFINET enhances its
  functionality, allowing for seamless
  communication and synchronization of complex
  manufacturing operations .
• Robotics and CNC Machines The adaptability of
  the V90 extends to robotics and computer
  numerical control (CNC) machining. Here, the
  drive system excels in applications requiring
  complex motion sequences and high precision, such
  as in robotic arm positioning and CNC machining
  centers.

8

• Packaging and Assembly For industries focused on
  packaging and assembly, the SINAMICS V90 motor
  provides reliable solutions for conveyor systems
  and automated assembly lines. The drive's ability
  to perform with high dynamic responses ensures
  that operations are not only fast but also
  accurate, which is crucial for maintaining
  throughput and reducing downtime.
• Material Handling The v90 also finds its
  application in material handling systems, where
  smooth and controlled motion is necessary. Its
  robust design supports the demands of
  applications like cranes and lifting equipment,
  providing the necessary control to handle
  materials safely and efficiently.
• Textile and Woodworking These industries require
  precise control for processes like weaving,
  cutting, and engraving. The V90's ability to
  handle complex motion sequences makes it a
  valuable asset, improving productivity and
  product quality.

9
Benefits of the SINAMICS V90

• The SINAMICS V90 servo drive system, integral to
  Siemens' SINAMICS product line, delivers notable
  advantages across a range of industrial
  applications. Here are some key benefits detailed
  through real-world use cases and statistical
  data
• Energy Efficiency and Cost Savings The Siemens
  v90 motor is designed to optimize energy use,
  particularly in applications like pumps, fans,
  and compressors. By transitioning from mechanical
  control systems to variable-speed drives, the V90
  significantly reduces power consumption,
  especially under partial load conditions. This
  shift can result in up to 70 savings on energy
  costs, making a substantial economic impact for
  businesses focused on sustainability and
  efficiency.
• Operational Efficiency The SINAMICS V90 system
  is known for its quick commissioning features and
  high reliability, which significantly reduce
  downtime and maintenance costs. The drive system
  is not only easy to install but also ensures
  continuous, trouble-free operation across diverse
  environmental conditions.

10

• Scalability and Flexibility With a broad
  spectrum of power ratings (0.05 to 7.0 kW) and
  the ability to operate across single and
  three-phase networks, the Siemens V90 offers
  remarkable scalability. This flexibility is
  further enhanced by its compatibility with
  various communication interfaces such as PTI,
  PROFINET, USS, and Modbus RTU, allowing seamless
  integration into existing automation systems.
• Diverse Industrial Applications From
  manufacturing and robotics to packaging and
  material handling, the Siemens V90 motor proves
  its versatility. For example, in manufacturing,
  it facilitates precise control over machinery,
  enhancing product quality and production rates.
  In material handling, it provides the necessary
  control to manage operations smoothly and safely.
• Integration in Automation Systems As part of
  Siemens' Totally Integrated Automation (TIA)
  philosophy, the v90 drive system works cohesively
  within a larger automation framework. This
  integration capability allows for centralized
  control and management of various drive tasks,
  streamlining operations and reducing complexity.

11
Conclusion Your Next Steps with Naksh Technology

• Naksh Technology Solutions LLP is committed to
  driving innovation and efficiency in automation
  through the SINAMICS V90 and its comprehensive
  suite of automation solutions. As industries
  evolve, partnering with a leader like Naksh
  ensures that your automation systems are not only
  up to date but also future-proof. For more
  information or to schedule a consultation,
  explore our website and discover how we can make
  a significant impact on your operational success.
