Sdballs Provide the best Teflon Balls

1
WELCOME TO SDBALLS.COM
2
SDBALL is located in Shandong, China, with easy
access to the port due to its proximity to major
highway intersections. Now has two factories
covering an area of 8,000 square meters, with
more than 200 sets of modern and efficient
production equipment, and the annual production
of steel balls is more than 5,000 tons. The
products are 100 exported and sold in more than
50 countries. They are all proven to be world
brands Made in China at the most competitive
prices and high quality.
3
Plastic Ball
Polyurethane Balls (PUR)
Specification Commercial name PU,PUR
Ball Diameter 1.5mm 100mm Precision Grade I
II III Mechanical Data Hardness (Shore D)
80-100 Density 1.14g/m3 Youngs Modulus
360GPa Tensile Strength 70-140MPa Service
temperatureºC -40/80
Corrosion Protection Polyurethane has good
corrosion resistance to mineral oils, greases,
petroleum products, dilute acids, and alkalis.
Strong acids and bases do not cause the balls to
resist. Poor resistance when exposed to steam,
aromatic hydrocarbons, heated, moist air, and
organic polar solvents. Application Check
valves and pumps both use polyurethane balls as
seals.In the food business, specialized bearings
and safety valves are routinely employed.
4
Plastic Ball
Polyvinyl Chloride Balls (PVC)
Specification Commercial name PVC Ball Diameter
1.5mm 100mm Precision Grade I II
III Mechanical Data Hardness (Shore D)
75-155 Density 1.4g/m3 Youngs Modulus
3250MPa Tensile Strength 55-90Mpa Service
temperatureºC -50/60 ºC
PVC balls are relatively hard and can be polished
to a shine. PVC balls have good chemical and
biological resistance also provide good impact
and abrasion resistance. Corrosion Protection
It is eroded by a variety of organic solvents and
is not recommended to be used above 70ºC. Poor
tolerance to aromatic and halogenated
hydrocarbons, ketones, cyclic ethers and
aldehydes. Application Used for electroplating
industry and petrochemical valves, sealing
valves, industrial equipment valves.
5
Plastic Ball
Silicon Nitride Balls
Specification Commercial name Si3N4 Diameter
1.0mm 200.0mm Precision Grade ISO
3290-2 Mechanical Data Hardness (HV)1400-1600 Den
sity 3.26 g/cm³ Youngs Modulus 300GPa Tensile
Strength 2300-4000MPa Service temperature 0/1200
C
Corrosion Resistance It possesses excellent
corrosion resistance in the majority of
conditions, with the exception of sulfuric
acid-containing solutions and situations with
high alkali concentrations. Applications Special
bearing/high-speed, vacuum pump, compressor,
mechanical centrifugal, shaft/spindle,
recirculating ball screw, flowmeter, measuring
instrument. It is used in the aerospace and
military industry.
6
Contact Information
Shandong SDBALLS Industry Co., Ltd Address Gengc
heng Industrial Zone, Ningyang County,Taian City,
Shandong Province, 271405 China Call/WhatsApp
86-13905383198 Email info_at_sdballs.com Website
https//www.sdballs.com
