Title: Electric Vehicle Battery Supplier in India - Robocraftstore


1
(No Transcript)
2
How are we?
  • We are in the business of Manufacturing, Research
    and development (RD) trading of EV batteries
    Solar batteries, EV kits, Stepper Motors Step
    Servo Motors, 3D Printers, Automation parts, IOT,
    Drone items incl. DIY kits ready to fly drones.
  • We believe in 360 Deg approach for our clients to
    provide hassle free platform for all our services
    and products.
  • Our client includes but not limited to IIT-
    Madars, IIT Kanpur, GNFC, ISRO,DRDO, various
    Govt. organizations, etc.

3
content
  • Types of electric vehicles
  • EV Hybrid Vehicle
  • Regenerative Controller
  • Li ion Battery pack mfg process

4
Types of electric vehicles
  • Battery Operated Electric Vehicle (BEV or EV)
  • Hybrid Electric Vehicle (HEV)
  • Plug-in Hybrid Electric Vehicle (PHEV)
  • Range Extension Electric Vehicles (REx)
  • Fuel Cell Electric Vehicles (FCEVs)

5
Battery Operated Electric Vehicle (BEV or EV)
  • As the name suggests these vehicles are fully
    operated through power generated from a battery
    (Li-ion).
  • This type of vehicle does not come with the
    traditional combustion engine and thus emits zero
    carbon monoxide or pollutants in the atmosphere.

Examples of BEVs Tesla Model 3, BMW i3, Hyundai
ioniq, Ford Focus, etc.
6
Hybrid Electric Vehicle (HEV)
  • This vehicle features both the conventional
    combustion engine battery-powered electric
    motor. But the battery cannot be charged by
    plugging in through an electricity input/
    charging station, instead, it captures energy
    while braking and batteries are charged.

Examples of HEVs Volvo XC90, Toyota Prius
7
Plug-in Hybrid Electric Vehicle (PHEV)
  •  type of EV category from its name. Unlike hybrid
    vehicles, PHEVs battery can be charged through a
    plug-in socket as well as power generated through
    braking and the car operates on the both
    combustion engine and electric powered motor.
    Benefits of PHEVs are the ability to cover
    shorter distances without using the combustion
    engine and increased range from fuel, battery
    charging regenerative braking.

Examples of PHEVs BMW i8, Toyota Prius Prime
8
Range Extension Types of Electric Vehicles (REx)
  • This type of vehicle features both combustion
    engine electric motor but most of the driving
    is done by the electric motor only. The internal
    combustion engine is only there to charge the
    battery if in case it gets low during a journey.

Example of REx BMW i3
9
Fuel Cell Electric Vehicles (FCEVs)
  • This type of vehicle stores hydrogen gas in the
    tank use electric motors like BEV. A fuel cell
    combines hydrogen with oxygen present in the air
    generates electricity which powers the electric
    motor.
  • Like the BEVs, it does not contain tailpipe and
    the byproduct is only water. There is no need to
    plug-in as the fuel cells are recharged by
    refilling the hydrogen.
  • Hydrogen infrastructure is far from reality as of
    now, which is not the case with Charging
    infrastructure as it has gained worldwide
    momentum.

Example of FCEV Toyota FCV concept
10
What is a EV Hybrid Vehicle
  • Hybrid electric vehicles are powered by an
    internal  gasoline-powered motor and one or more
    electric motors to power it.
  • Hybrid cars are designed to switch between using
    gasoline and electric power or using both at the
    same time, depending on whats most efficient at
    the moment.
  • Hybrids come in different types, including those
    that can be plugged in to charge their batteries
    and others that just recharge by running the
    engine or through braking Its called
    Regenerative.

11
Which car is better, EV or hybrid?
  • If one has a spare gas powered car than going for
    an EV is a good idea as once you the hit highway
    for a long drive the range anxiety will kick
    in. If one can have only one car than as far as
    today is concerned getting a hybrid makes more
    sense.

12
what is full and half hybrid
  • Half hybrids have an electric motor that assists
    the gas engine, but always needs the gas engine
    running for it to assist.
  • Full hybrids have an electric motor that can
    move the car without the gas engine running,
    though only with electricity that originally
    comes from the gas engine


13
Series-parallel
hybrid vehicle
parallel hybrid vehicle
Series hybrid vehicle
14
Parallel Hybrid Vehicle
In a PHEV, mechanical and electrical powers are
both connected to the driveline, as shown in
Figure In the case of parallel architectures,
good performance during acceleration is possible
because of the combined power from both engines
. . Different control strategies are used in a
preferred approach. If the power required by the
transmission is higher than the output power of
the ICE, the electric motor is turned on so that
both engines can supply power to the
transmission. If the power required by the
transmission is less than the output power of the
ICE, the remaining power is used to charge the
battery packs . Moreover, mechanical and electric
power could be decoupled, and the system has a
high operating flexibility enabling three modes
of operation purely combustion purely electric
and hybrid. Usually, a PHEVs are managed in
purely electric mode at low speeds, until the
battery charge state reaches a predetermined low
threshold, typically 30.
15
Series hybrid electric vehicles (SHEVs)
  • Series hybrid electric vehicles (SHEVs) involve
    an internal combustion engine (ICE), generator,
    battery packs, capacitors and electric motors .
    SHEVs have no mechanical connections between the
    ICE and the wheels. The ICE is turned off when
    the battery packs feed the system in urban
    driving. A significant amount of energy is
    supplied from the regenerative braking
  • The series hybrid configuration is mostly used in
    heavy vehicles, military vehicles, and buses . An
    advantage of this topology is that the ICE can be
    turned off when the vehicle is driving in a
    zero-emission zone. Moreover, the ICE and the
    electric machine are not mechanically coupled

16
hybrid two wheeler Parts
BIKE Kit 17 Inch
Scooter Kit 10 Inch
17
Bill of Material
  1. BLDC Motor
  2. Regenerative Controller
  3. Throttle
  4. DC-DC converter
  5. Li ion battery pack
  6. Charger
  7. fasteners and tools

18
Regenerative Controller
  • When the vehicle is running, the controller
    supplies the electrical energy from the battery
    to the motor. When the driver presses the brake
    pedal, the controller stops the electric energy
    supply to the motor and starts charging from
    generator to battery.

19
Regenerative Braking
System
  • A regenerative Braking System is a braking system
    that generates electrical energy during braking
    action. This generated energy is used for
    charging the battery, which is used again to
    rotate the motor (to run the vehicle).
  • Working principle
  • This regenerative braking system works on the
    principle of conservation of energy.
    The principle says that, the energy converts from
    one form to another form.
  • In friction braking system, the kinetic energy of
    the wheel is converted into the heat energy,
    which is lost to the atmosphere.
  • But in regenerative system, the kinetic energy of
    wheels is converted into the electrical energy.
  • This system is mostly used in electric or hybrid
    vehicles, which uses a motor to run the vehicle.

20
(No Transcript)
21

Li ion battery pack
  • Parts Required
  • 1. 18650 Battery ( ROBOCRAFT )
  • 2. BMS (ROBOCRAFT)
  • 3. Ni Strips (ROBOCRAFT)
  • 4. Battery Level Indicator (ROBOCRAFT)
  • 5. 18650 Battery Holder (ROBOCRAFT)
  • 6. KAPTON Tape
  • 7. SPOT Welding Kit
  • 8.EPOXY

22
Contact Us
  • Phone 91 9429230946
  • Email robocraft.sales_at_gmail.com
  • ADDRESS B317, 318, 319 3rd-floor SUMEL 6
    BUSINESS PARK Dudheshwar, Ahmedabad, Gujarat
    380004
  • FACEBOOK https//www.facebook.com/ROBOCRAFTSTORE
    /
  • Instagram https//www.instagram.com/robocraftst
    ore/
  • YOUTUBE https//www.youtube.com/watch?vpzr5AG8v
    b6k
