RIP Proteases, small RNA and porins

1
RIP Proteases, small RNA and porins

• bouloc_at_infobiogen.fr
• Signalisation et
• Réseaux de Régulations Bactériens
• Institut de Génétique et Microbiologie,
• Université Paris-Sud - CNRS, UMR8621,
• bâtiment 400, F-91405
• Orsay Cedex France

2
(No Transcript)
3
Membrane associated proteases
4
Regulated intra-membrane proteolysis (RIP)

• Processing of membrane proteins by embedded
  proteases,
• releasing an active fragment.
• Characteristics of S2P-like proteases
• - several trans-membrane domains
• - HExxH motif -gt metalloproteases
• - LDG motif
• Active sites are located within the membrane.
• - Conserved from bacteria to eukaryotes

Enterococcus faecalis Eep cAD1 sex pheromone
Bacillus subtilis SpoIVFB pro-sk
sporulation Caulobacter cresentus MmpA PodJL
polar localization Vibrio cholerae
YaeL TcpP virulence
5
Putative RseP topology
PDZ
periplasm
Signal peptide
LDG
HExxH
cytoplasm
PhoA insertion
LacZ insertion
6
Genetic organizationaround rseP (yaeL)
Porin synthesis
fabZ
uppS
skp
lpxD
lpxA
lpxB
rnhB
LPS
Phospholipids
7
Conditional rseP expression
Km
rseP
tetR lacI
attl
aTc
PLTetRseP
DrsePKm pPLtetRseP
8
RseP is essential
?rseP pPLtetRseP
aTc
- aTc
9
System to test rseP mutations
Km
PLtetRRseP
rseP
aTc
tetR lacI
attl
IPTG arabinose
attHK
Plac/ararseP
Plac/ararseP DrsePKm pPLtetRseP
10
Complementation of RseP depletion
Plac/ararseP DrsePKm pPLtetRseP
Vector
RseP
RseP(E23A)
RseP(E23Q)
RseP(A235E)
RseP(D235A)
RsePDPDZ
RseP(D402A)
RseP(D402N)
RseP(E23A/D402N)
RseP(E23Q/D402N)
IPTG/Ara
aTc
11
RpoE regulon activation
LPS
Porin
OM
Periplasm
DegS
RseP
IM
RseA
sE
12
RpoE regulon activation
LPS
Porin
OM
Periplasm
DegS
RseP
IM
RseA
sE
13
RpoE regulon activation
LPS
Porin
OM
Periplasm
DegS
RseP
IM
RseA
sE
14
RpoE regulon activation
LPS
Porin
OM
PDZ
Periplasm
DegS
PDZ
RseP
IM
RseA
sE
15
Degradation of RseA by RsePDPDZ

16
Expression from a sE regulated promotor
pControl
pRseP
pRseP DPDZ
DrseP
degS pControl
degS pRseP
degS pRseP DPDZ
17
RpoE regulon activation
LPS
Porin
OM
?
PDZ
Periplasm
DegS
PDZ
RseP
IM
RseA
sE
18
Multicopy suppressor of RseP depletion
LPS
Porin
OM
Periplasm
DegS
RseP
IM
RseA
x
sE
sE
x
x
x
X
ori
ori
ori
ori
ori
19
RseX is a suppressor of DdegS
LPS
Porin
OM
Periplasm
DegS
RseP
IM
RseA
x
sE
sE
x
x
x
X
ori
ori
ori
ori
ori
20
Effect on pSUP on sigmaE activity
100
50
Miller Units
0
pUC18
pSUP
DdegS pSUP
DrseP pSUP
21
Suppressor?
4 clones
fabZ
uppS
hlpA
lpxD
lpxA
lpxB
rnhB
8 clones
yedQ
yodC
yedI
yedA
vsr
dcm
yedJ
yedR
yedR
yedJ
22
Suppressor?
yedR
yedJ
yedJ
yedR
yedR
yedJ
23
Suppressor
yedS  ompS1
yedR
170bp
24
 conventional  and  non-conventional  RNAs

• Messenger RNAs ? express proteins
• Ribosomal RNAs ? ribosome components
• transfer RNA ? transfer amino acids for
  protein synthesis
• Small regulatory RNAs (sRNA)
• 100 to 300 nts, secondary structure
• Conditional expression
• Difficult to detect (biocomputing and genetic)

25
E. coli sRNAs before 2000

• Stable and abundant
• 4.5S RNA secretion machinery
• 10Sb RNA RNase P catalytic part
• 10Sa RNA (tmRNA) protein quality control
• 6S RNA modulator of RNA Pol. activity
• Spo42 antisense regulator
• Detected by multi-copy expression
• MicF transcription divergent from ompC, acts
  on ompF mRNA
• DsrA increase in capsule synthesis
• RprA suppressor of dsrA
• Transcriptional analysis
• OxyS divergent transcription from oxyR
• GvcB divergent transcription from gvcA

Pichon C. et al. PNAS 2005
26
Global searches for sRNAs in E. coli
Wassarman KM, Repoila F et al. (2001) Genes Dev
151637-1651
Rivas E, et al. (2001) Curr Biol. 111369-73.
Vogel J. et al. (2003) Nucleic Acids Res. 2003
316435-43
27
Examples of sRNA activities
Storz et al. 2004 Current Opinion in Microbiology
28
E. coli Hfq

• Host factor necessary for the replication of
  RNA phage Qß
• in E. coli.
• 30 00060 000 copies per cell
• Pleiotropic regulator
• Hfq inactivation generates numerous phenotypes
• Reduce growth rate and yield
• Plasmid supercoiling
• Bacterial size
• Osmosensitivity
• UV sensitivity

29
Suppressor

• Physical characterization
• Identification of its targets
• Mode of action

yedS  ompS1
yedR
170bp
RseX RNA suppressor of eXtracytoplasmic stress
protease (RseP)
30
RseX
rseX
ompS1 (yedS)
yedR
zz
91
164
284
Rho-independent terminator
31
rseX trancription is required for DrseP
suppression
Plac/ararseP DrsePKm pPLtetRseX
aTc
-
32
Suppression requires Hfq
Plac/ara-1rseP DrsePKm
33
Specific Hfq-binding to RseX
34
Identification of RseX targets

• In vitro transcription of RseX

35
Identification of RseX targets

• In vitro transcription of RseX
• RseX biotinylation

36
Identification of RseX targets

• In vitro transcription of RseX
• RseX biotinylation
• Association of biotinylated RseX to streptavidin
  beads

37
Identification of RseX targets

• In vitro transcription of RseX
• RseX biotinylation
• Association of biotinylated RseX to streptavidin
  beads
• Incubation of total RNA extracts with
  RseX-biotin-streptavidin complex

38
Identification of RseX targets

• In vitro transcription of RseX
• RseX biotinylation
• Association of biotinylated RseX to streptavidin
  beads
• Incubation of total RNA extracts with
  RseX-biotin-streptavidin complex
• Purification of RNAs associated to the complex
  using a magnet
• Elution of RseX-bound RNAs

39
Identification of RseX targets

• In vitro transcription of RseX
• RseX biotinylation
• Association of biotinylated RseX to streptavidin
  beads
• Incubation of total RNA extracts with
  RseX-biotin-streptavidin complex
• Purification of RNAs associated to the complex
  using a magnet
• Elution of RseX-bound RNAs
• Cy3-labelled cDNA synthesis

40
Identification of RseX targets

• In vitro transcription of RseX
• RseX biotinylation
• Association of biotinylated RseX to streptavidin
  beads
• Incubation of total RNA extracts with
  RseX-biotin-streptavidin complex
• Purification of RNAs associated to the complex
  using a magnet
• Elution of RseX-bound RNAs
• Cy3-labelled cDNA synthesis
• Hybridation on pan-genomic E.coli
  micro-arrays (GODMAP)

41
Hybridation on E. coli micro-array
ompC
ompA
gDNA
gDNA
42
RNA-RNA band-shift
ompA mRNA
RseX-ompA mRNA
RseX
43
Putative pairing of RseX with 5 ompA and ompC
mRNA UTRs
44
Outer membrane protein gel
45
ompA/ompC mRNA northern blot
ompA/ompC mRNA northern blot
pRSEXaTc
pRSEX-aTc
pControl
ompA
ompC
ssrA
rseX
46
RseX degradation is likely RNaseE dependent
rne(ts) pPLtetRseX
30 -aTc
44 -aTc
30 aTc
44 aTc
C
47
DompA DompC is a suppressor of DrseP
Parental strain PLtetO-1rseP DrseP
aTc
-aTc
Parental strain
DompA
DompC
DompF
DompA DompC
DompA DompF
DompC DompF
DompS1
48
DompA DompC is a suppressor of DrseP
49
Absence of porins and sE response
lacZ
sE
250
200
150
Miller Units
100
50
0
WT
DompF
DompA
DompS
DompC
DompCF
DompAC
50
Hfq represses the sE response
lacZ
sE
250
200
150
Miller Units
100
50
0
WT
hfq
Dhfq
DompF
DompA
DompS
DompC
DompCF
DompAC
51
OmpF
OmpA
OmpC
