Mass Wasting

1
Landscapes Fashioned by Water
Running Water
2
Running Water

• Most important agent in modifying the Earths
  land surface
• 97 of Earths water in oceans, but constantly
  recycled by the hydrologic cycle of evaporation,
  transpiration, condensation, and precipitation
• 20 of all precipitation falls on land, with
  precipitation returning annually to the ocean via
  runoff, surface flow in rivers and streams

3
Water Flow

• Water flows from slopes as laminar or turbulent
  flow
• Laminar flow lines of flow parallel one another,
  no mixing of layers, flow primarily in one
  direction, rare

4
Water Flow

• Turbulent flow complex mixing occurs as water
  molecules move in all directions, most water flow
  is turbulent

5
Runoff

• Runoff controlled by infiltration capacity, the
  ability of the surface to absorb water

6
Downhill Flow

• Downhill flow causes erosion as water moves by
  sheet or channel flow-
• Sheet flow continuous sheet of shallow water
  moving over the surface

7
Downhill Flow

• Channel flow flow confined to long, trough-like
  depressions described according to size rill,
  brook, creek, stream, river (fluvial channels)

8

• Some water is supplied to streams and rivers via
  runoff, but most by groundwater, which is
  evidenced by continually running rivers in arid
  regions

9
Measuring Running Water

• Gradient the downhill flow of a stream or river
  over a given distance defines its gradient, or
  vertical drop over horizontal distance (rise over
  run)

10
Measuring Running Water

• Velocity the measurement of downstream water
  travel distance in a given time, expressed in
  m/sec or ft/sec

11
Measuring Running Water

• Discharge a measurement of the amount of water
  passing a given point in a given period of time,
  expressed in cubic meters or feet per second

12
Erosion

• Water modifies the surface via erosion and
  transport of sediments
• Erosion occurs as sediments are put into motion
  by hydraulic action, but also includes the
  abrasion of carried particles against the exposed
  rock
• Eroded particles are transported by running water
  and eventually deposited

13
Particle Transport

• Transported particles are known as the load may
  include these types
• Dissolved load materials taken into solution by
  chemical weathering
• Solid load solid particles, includes
• Suspended load-small particles (clay and silt)
  suspended above the channel bed by turbulence
• Bed load-larger particles (sand and gravel to
  boulders) that cannot be kept in suspension by
  turbulence

14
(No Transcript)
15

• Bed load is transported by saltation, the
  intermittent
• bouncing or skipping of particles along the
  stream
• channel, or traction, particles dragged or rolled

• along the bottom of the channel

16

• Sediments deposited by running water are
  collectively known as alluvium, or alluvial
  deposits

17
Types of Stream/River Channels

• Stream and river channels are characterized as
  meandering or braided
• Meandering stream consists of a single sinuous
  channel with looping curves known as meanders

18
Meandering Stream

• The outside of a stream meander has greater
  velocity and produces a cut bank, while the
  inside of which has a point bar, where sediments
  are dropped by slower moving waters
• Oxbow lakes are produced as meanders are cut-off
  by the main channel

19
Braided Stream

• Braided stream possess an intricate network of
  dividing and rejoining channels separated from
  one another by sand and gravel bars develop when
  sediment supply exceeds transport capacity

20
Depositional Structures

• Floodplains form in flat-lying areas of the
  stream gradient as heavy rains cause the stream
  to overflow its banks these consist primarily of
  fine-grained sediments deposited from the
  suspended load (overbank deposits)
• Natural levees are produced along the edges of
  stream channels by overbank deposits

21
Floodplain
22
Natural Levees
23
Depositional Structures

• Deltas fan shaped sedimentary structures
  produced as moving water flows into a standing
  body of water and drops sediments
• Alluvial fans produced when running water from
  highlands deposits alluvium on the plains below

24
Drainage Basins

• A drainage basin is an area drained by a river or
  stream and all its tributaries
• Topographical highs separating drainage basins
  are know as divides (Continental Divide)

25
Continental Divide
26
Drainage Basins

• Drainage basins develop distinctive patterns
  based upon the composition, relief, and geologic
  structure of underlying rocks include
• Dendritic
• Parallel
• Trellis
• Radial

27
(No Transcript)
28
Base Level

• Streams and rivers flow to base level, the lowest
  point to which they can erode ultimate base
  level is sea level, which can change and affect
  continental erosion rates

29
(No Transcript)
30
Fluvial channels

• Valleys are created as runoff creates erosion and
  channels are incised within drainage basins
  valleys include gullies, canyons, and gorges
• Valleys also grow through headward erosion,
  lengthening at the upstream end of a channel
• Continued headward erosion may connect two
  channels and result in stream piracy, the
  diversion of part of a drainage basin into
  another stream

31
Fluvial Channels

• Stream terraces are sometimes found along the
  margins of floodplains, and represent remnants of
  floodplain deposition during periods of higher
  flow or continued downcutting due to eustatic
  fluctuations
• Incised meanders form as channels cut into solid
  bedrock as underlying rocks are uplifted

32
Stream Terraces
