Magnetism Chapter 2

1
MagnetismChapter 2

• Producing Electric Current Section 2-4

2
Magnetism and Electric Current

• Galvanometer device which measures the
  direction and strength of electric current.
• Galvanometer registers a weak current when a
  magnet is moved inside a coil of wire. (also,
  when the coil is moved)

3
Induced Current

• Induced current is the current produced in a
  conductor by a changing magnetic field.
• Changes mechanical energy into electric energy.

4
Generating Current

• All homes and businesses use induced current when
  they use energy from the power plant.
• Power plants produce energy with electric
  generators.

5
Electric Generator

• Electric Generator changes mechanical energy into
  electric energy.

6
Changing Currents

• Transformer
• used by power companies to make
• High voltage electricity usable to general
  public
• Transformers change energy proportionally

7
Step-Up Transformers

• Step-Up Transformers raises voltage for efficient
  travel
• 3 coils x 3 9 coils
• 10 volts 30 volts x3
• 30
• Draw three coils on right and nine on left.

8
(No Transcript)
9
Step-Down Transformers

• Step-Down Transformers lowers voltage for use

6 coils 2 3 coils
60 volts 2 30 30 volts
10
Step-Down Transformer
11
Changing Current
12
Bibliography

• Aldridge, Bill, Jack Ballinger, and Albert
  Kaskel. Science Interactions Course 3. 3rd ed.
  New York, New York Glencoe, 1995. 65-70.
