Creating Public Websites from Specialized Voyager Data

1
Creating Public Websites from Specialized
Voyager Data

• Sai Deng, Nancy Deyoe, Gemma Blackburn and
  Tse-Min Wang
• Wichita State University Libraries

2
Beyond MARC note fields

• Most of our abilities in the past have been
  limited to notes/local notes in our MARC data.
• We have done local notes for years for donor
  notes and collection information
• While this information was searchable via
  keyword, searchers had to be in our OPAC.

3
Web options wanted!

• Greater exposure
• New audiences
• Publicity for a topic / program
• Can create something new reasonably quickly
• As long as information continues to be added, the
  featured collection can grow

4
Examples of collections we hoped to feature

• Shocker Scholar Festival
• Bestsellers/Current interest books (our Leisure
  Reading collection)
• Featured authors or subjects (to tie in with
  public programming events)
• Also titles from specialized collections (such as
  the Wichita Art Museum Research Library)

5
One featured collection the Shocker Scholars
Festival

• Annual event hosted by the WSU Libraries
• Information is collected from all colleges of
  faculty/departmental scholarly activity
• Colleges are getting better, but this can still
  be challenging!
• Do the Libraries hold copies of the titles? The
  process may begin at Acquisitions

6
Customizing and using the data

• WSU faculty author note is added during the
  cataloging process this helps build the data
• We subscribe to Syndetics, so cover images will
  appear in our catalog and website
• Gemma will now describe how the OPAC data is
  utilized for the web display

7
How to draw the data from the library catalog to
display on the web

• WSU uses
• Ex Libris Voyager 7.0.4 ILS
• Sun Solaris 10 server
• Oracle 10g database
• Two ways that we use to pull data from the
  database
• Using Voyager Analyzer
• Using an ODBC connection

8
How to draw the data from the library catalog to
display on the web

• Voyager Database
• Contains data arranged into tables, each
  containing several related fields
• For example, the Bib_Text table
• There are hundreds of tables in
• the Voyager database

9
How to draw the data from the library catalog to
display on the web

• Data is pulled from the database for various
  reasons
• To prepare reports
• Number of circulations
• Number of items purchased by fund code
• To identify records
• All records with specific donor notes
• Records with multiple 245 fields
• To display records in alternative ways
• Websites like the Faculty Showcase
• RSS feeds
• And many others

10
How to draw the data from the library catalog to
display on the web

• Voyager Analyzer
• Cognos Business Intelligence environment connects
  to Voyager database and allows the creation of
  reports using a web-based, end-user friendly
  environment
• Data is rearranged from the Voyager table
  structure into a new arrangement of layers and
  folders of related fields for easier reporting
  creation
• Data from reports can be prepared in XML format
  and displayed on a website using XSLT stylesheets

11
How to draw the data from the library catalog to
display on the web

• Voyager Analyzer

Web Access to Analyzer
Ex Libris Servers
Solaris Server
Cognos Analyzer Logic
Voyager Oracle Database
Logic
Data
Web Access to Analyzer
Cognos
12
How to draw the data from the library catalog to
display on the web

• ODBC Open Database Connectivity
• A standard API to access data in a database
  remotely using SQL queries
• Requires ODBC drivers to be installed on users
  machine as well as connection information to
  connect to the database
• Data can be used through Microsoft Access or
  other databases
• Data in the secondary database can be displayed
  on the web using a language such as ASP, PHP,
  etc.

13
How to draw the data from the library catalog to
display on the web

• ODBC

Local Machine
Solaris Server
ODBC Drivers
Voyager Oracle Database
Microsoft Access
Voyager Tables
14
How to draw the data from the library catalog to
display on the web

• SQL Structured Query Language
• SQL is the language used to communicate with most
  databases
• SQL queries can be used to pull specified data
  from a database through an ODBC connection
• Data can be identified from specific fields that
  meets defined criteria

15
How to draw the data from the library catalog to
display on the web

• Blob Binary Large Object
• The Voyager database does not contain most MARC
  information. The MARC records are stored
  independently as binary data on the server, so
  many MARC fields (such as 590) cannot be
  extracted with regular SQL queries
• Blob queries can be used to extract MARC fields
  from this binary data using an Access module
  containing Visual Basic code that has been
  written for Voyager

16
Query to identify faculty publications in the
library catalog

• SELECT DISTINCTROW RO_WSUDB_BIB_TEXT.BIB_ID,
  RO_WSUDB_BIB_TEXT.AUTHOR, RO_WSUDB_BIB_TEXT.TITLE,
  RO_WSUDB_BIB_TEXT.EDITION, RO_WSUDB_BIB_TEXT.ISBN
  , RO_WSUDB_BIB_TEXT.PUBLISHER_DATE,
  RO_WSUDB_BIB_TEXT.IMPRINT, RO_WSUDB_BIB_LOCATION.L
  OCATION_ID, GetFieldAll(GetBibBlob(RO_WSUDB_BIB_T
  EXT.BIB_ID),"590") AS Expr1, GetFieldAll(GetBibBl
  ob(RO_WSUDB_BIB_TEXT.BIB_ID),"700") AS Expr2
  INTO query590view
• FROM RO_WSUDB_BIB_TEXT INNER JOIN
  RO_WSUDB_BIB_LOCATION ON RO_WSUDB_BIB_TEXT.BIB_ID
  RO_WSUDB_BIB_LOCATION.BIB_ID
• WHERE ((GetFieldAll(GetBibBlob(RO_WSUDB_BIB_TEXT.
  BIB_ID),"590")) Like "WSU Faculty")

17
Other queries to draw specialized data from
Voyager

• Query to identify Leisure Reading books
• SELECT LOCATION.LOCATION_NAME, BIB_TEXT.TITLE,
  WSUDB_MFHD_MASTER.DISPLAY_CALL_NO,
  BIB_LOCATION.LOCATION_ID, BIB_TEXT.BIB_ID
• FROM WSUDB_MFHD_MASTER INNER JOIN ((BIB_TEXT
  INNER JOIN (BIB_LOCATION INNER JOIN LOCATION ON
  BIB_LOCATION.LOCATION_ID LOCATION.LOCATION_ID)
  ON BIB_TEXT.BIB_ID BIB_LOCATION.BIB_ID) INNER
  JOIN WSUDB_BIB_MFHD ON BIB_TEXT.BIB_ID
  WSUDB_BIB_MFHD.BIB_ID) ON WSUDB_MFHD_MASTER.MFHD_I
  D WSUDB_BIB_MFHD.MFHD_ID
• WHERE (((BIB_LOCATION.LOCATION_ID)"99"))
• Query to identify Goldbarth poems
• SELECT DISTINCTROW RO_WSUDB_BIB_TEXT.BIB_ID,
  RO_WSUDB_BIB_TEXT.AUTHOR, RO_WSUDB_BIB_TEXT.TITLE,
  RO_WSUDB_BIB_TEXT.EDITION, RO_WSUDB_BIB_TEXT.ISBN
  , RO_WSUDB_BIB_TEXT.PUBLISHER_DATE,
  RO_WSUDB_BIB_TEXT.IMPRINT, RO_WSUDB_BIB_LOCATION.L
  OCATION_ID, GetFieldAll(GetBibBlob(RO_WSUDB_BIB_T
  EXT.BIB_ID),730")
• FROM RO_WSUDB_BIB_TEXT INNER JOIN
  RO_WSUDB_BIB_LOCATION ON RO_WSUDB_BIB_TEXT.BIB_ID
  RO_WSUDB_BIB_LOCATION.BIB_ID
• WHERE ((GetFieldAll(GetBibBlob(RO_WSUDB_BIB_TEXT.
  BIB_ID),730")) Like "Albert Goldbarth
  Collection")

18
Other queries to draw specialized data from
Voyager

• Query to identify Wichita Art Museum collections
• SELECT LOCATION.LOCATION_NAME, BIB_TEXT.TITLE,
  WSUDB_MFHD_MASTER.DISPLAY_CALL_NO,
  BIB_LOCATION.LOCATION_ID, BIB_TEXT.BIB_ID
• FROM WSUDB_MFHD_MASTER INNER JOIN ((BIB_TEXT
  INNER JOIN (BIB_LOCATION INNER JOIN LOCATION ON
  BIB_LOCATION.LOCATION_ID LOCATION.LOCATION_ID)
  ON BIB_TEXT.BIB_ID BIB_LOCATION.BIB_ID) INNER
  JOIN WSUDB_BIB_MFHD ON BIB_TEXT.BIB_ID
  WSUDB_BIB_MFHD.BIB_ID) ON WSUDB_MFHD_MASTER.MFHD_I
  D WSUDB_BIB_MFHD.MFHD_ID
• WHERE (((BIB_LOCATION.LOCATION_ID)122"))

19
Website created from query results

• Run blob query to draw faculty author data
  through ODBC (as Gemma discussed)
• Query results saved in an Access table
• Fields BIB_ID, AUTHOR, TITLE, EDITION, ISBN,
  PUBLISHER_DATE, IMPRINT, LOCATION_ID, Expr1,
  Expr2
• Expr 1 590 notes field data
• Expr 2 700 (other author) field data
• Added a localCover field to handle local cover
  images (when ISBN and Syndetic cover are not
  available)
• Website created via web programming.
• http//library.wichita.edu/techserv/WSU_faculty/in
  dex.asp

20
Web delivery and dataflow
Syndetic Cover Images
Web
If available
RSS Feed
If not available
ISBN
Display
ASP
BibID
Local Cover Images
Search
Access (Query Results)
ODBC Blob Query
Voyager Oracle Database
21
Browse

• Browse
• by Name
• by Title
• by Year
• Retrieve data
• SELECT Fields FROM Table ORDER BY

22
Search
23
Issues to consider in web delivery

• What to display? In which format?
• Fields Author/Editor, Title, Publication Year,
  Publisher
• Decide to use Author/Editor (100 field/700
  field) to avoid too many blank fields (no 100)
• Field names were changed from all uppercase to
  make them easy to read
• Added local cover images link.
• Added link to OPAC for original records display.

24
One step further possible data transformation
and web delivery

• Alternatively, we can transform Access table data
  to Dublin Core in XML, and display it online with
  style sheet.
• MARC (in Voyager table) to DC mapping
• Marc field
  Simplified DC Qualified DC
• 001 BIB_ID Not
  mapped
• 020 ISBN
  Identifier
• 100 AUTHOR
  Contributor
• 245 TITLE
  Title
• 250 EDITION
  Description
• 260ab IMPRINT Publisher
• 260c PUBLISHER_DATE Date
  Date.issued
• 852b LOCATION(_ID) Relation
  Relation.ispartof (housing at)
• 590 notes (Expr1 in query) Description
• 700 other author (Expr 2 in query) Contributor

• Additional fields Added
• Link to OPAC/library catalog Relation
  Relation.isbasedon (source)
• Cover image link
  Relation Relation.haspart (contained
  item)

25
Adding Syndetic cover and local cover images

• Added some local covers for books without
  Syndetic covers
• If local covers are available, use local images
  (thumbnail linked to large covers)
• If local covers not available,
• If ISBN available, use Syndetic covers
• Either show Syndetic covers or show blank
• If no ISBN, use a generic local cover

26
Local cover images scanning guideline
Master Access Thumbnail
File Format TIFF JPEG JPEG
Bit Depth 48 bit color 24 bit color 24 bit color
Spatial Resolution 400-600 dpi 300 dpi 144 dpi
Spatial Dimensions 4000 pixels across the long dimension 400 pixels across the long dimension 100 pixels across the long dimension

• Based on BCRs CDP Digital Imaging Best Practices
  and Western States Digital Imaging Best
  Practices
• Dimensions of images were set to be consistent to
  Syndetic covers but with higher resolutions.

27
Local cover images digitization

• Issues to consider in digitizing old cover
  images
• Extra hard drive to save master image files
• Image editing and touch-up erase barcode, image
  clean-up, image repair
• Whats behind the barcode area? Do not make up
  images if a pattern cannot be found.

28
Code to add local and Syndetic cover images

• From browse.asp
• lttd class"image" rowspan"6"gt
• lt If ((Recordset1.Fields.Item("localCove
  r").Value ltgt "") AND (Recordset1.Fields.Item("loca
  lCover").Value ltgt " ")) Then gt
• lta href"localcover\lt(Recordset1.Fields
  .Item("localCover").Value)gtL.jpg"
  target"_blank"gt
• ltimg border0 src"localcover\lt(Reco
  rdset1.Fields.Item("localCover").Value)gt.jpg"
  /gtlt/agt
• lt Else gt
• lt If ((Recordset1.Fields.Item("ISBN").Va
  lue ltgt "") AND (Recordset1.Fields.Item("ISBN").Val
  ue ltgt " ")) Then gt
• lta href"http//syndetics.com/hw7.pl?isb
  nlt(Recordset1.Fields.Item("ISBN").Value)gt/lc.j
  pgclientwichitasu" target"_blank"gt
• ltimg border0 src"http//syndetics.com/
  hw7.pl?isbnlt(Recordset1.Fields.Item("ISBN").Val
  ue)gt/sc.gifclientwichitasu" /gtlt/agt
• lt Else gt
• ltimg alt"book cover" srclocalCover/cov
  er.jpg" /gt
• lt End If gt
• lt End If gt
• lt/tdgt

Add specific large and small local covers
Image link to add Syndetic covers
Add local generic cover
29
Adding RSS feed
RSS feed icon
30
RSS feed display
31
Code to add RSS feed

• lt?xml version"1.0" encoding"UTF-8"?gt
• ltrss version"2.0"gt
• ltchannelgt
• lttitlegtWSU Libraries Faculty Author Published
  Books Updatelt/titlegt
• ltlinkgthttp//library.wichita.edu/techserv/WSU_Fa
  culty/index.asplt/linkgt
• ltdescriptiongtUpdate on published books of
  Faculty Author available at WSU
  Librarieslt/descriptiongt
• ltlanguagegten-uslt/languagegt
• ltpubDategtFri, 6 Mar 2009 040000 GMTlt/pubDategt
• ltlastBuildDategtFri, 6 Mar 2009 040000
  GMTlt/lastBuildDategt
• ltdocsgthttp//library.wichita.edu/RSSlt/docsgt
• ltmanagingEditorgt_at_wichita.edult/managingEditorgt
• ltwebMastergt_at_wichita.edult/webMastergt
• ltitemgt
• lttitlegtIt grows in winter and other poems /
  Chinyere Okafor. lt/titlegt
  ltlinkgthttp//library.wichita.edu/techserv/WSU_facu
  lty/browse.asp?browse_typePUBLISHER_DATElt/linkgt
• ltdescriptiongtGet more information on this
  book and other WSU faculty publications at
  Faculty Research Showcase Website.lt/descriptiongt
• ltpubDategtThu, 5 Mar 2009 040000
  GMTlt/pubDategt
• lt/itemgt
• lt/Channelgt

pubupdate.rss
Required Channel elements title, link,
description
added to the webpage header
ltlink rel"alternate" type"application/rssxml"
title"Faculty Author - Recent Books RSS"
href"http//library.wichita.edu/techserv/WSU_facu
lty/pubupdate.rss"gt
32
Final thoughts

• Other project possibilities for featuring
  specialized Voyager data
• Dynamic websites can be created based on the
  current model
• One step further using Dublin Core metadata
  schema to present data via web to facilitate data
  harvesting
• One more possibility Add local covers to
  Voyager

33
Contact information

• Sai Deng, Metadata Cataloger, Wichita State
  University Libraries, Sai.Deng_at_wichita.edu
• Nancy Deyoe, Assistant Dean for Technical
  Services, Nancy.Deyoe_at_wichita.edu
• Gemma Blackburn, Systems Developer, Wichita State
  University Libraries, Gemma.Blackburn_at_wichita.edu
• Tse-Min Wang, WSU Graduate Student in Computer
  Science, txwang_at_wichita.edu

34

• Thank you!
