Design of Spatial Information Systems

1
DEPARTMENT OF COMPUTER SCIENCE UNIVERSITY OF
JOENSUU JOENSUU, FINLAND

• Design of Spatial Information Systems
• Lecture 2
• Cartography
• Alexander Kolesnikov

2
The Shape of the Earth

• 250 B.C. Eratosthenes measured the Earth using
  basic principles of geometry
• Measuring the angle between Polaris and the
  observers horizon define the astronomic latitude

3
Shape of the Earth Sphere
4
The Earths Shape Ellipsoid

• Ellipsoid The Earth revolves easterly on its
  axis, generating centrifugal force, causing a
  bulge in the middle and flattening at the poles

5
Selected Reference Ellipsoids

6
The Earths Shape Geoid

• Geoid Representation of the Earth as an
  equigravitational surface at mean sea level (MSL)
• Variation is about 100 m, that is far less than
  the ellipsoid varies from the sphere

7
Difference between geoid and ellipsoid
8
Why different ellipsoids?

• Better methods for approximating the surface of
  the Earth
• Developed from different areas of the Earth

9
Datum

• The ellipsoid is a mathematical model that
  describes
• the shape of the Earth.
• A datum
• defines the position of the ellipsoid relative
• to the center of the Earth
• provides a frame of reference for measuring
  locations
• on the surface of the Earth
• aligns its spheroid to closely fit the Earths
  surface
• in a particular area

10
Datum Ellipsoid(a,b) Shift(dX,dY,dZ)
dY
dX
11
Datum Ellipsoid Shift
12
Datum Ellipsoid Shift
Datum Ellipsoid dX
dY dZ Area European
1950 International 1924 -87 -98 -121
Finland Pulkovo 1942 Krassovsky 1940 28
-130 -95 Russia WGS 1984 WGS84
0 0 0
Global ...
Find datum for your homeland http//www.colorado.
edu/geography/gcraft/notes/datum/edlist.html
13
Geographical coordinates
North Pole
South Pole
14
Geocoordinates
Meridians
North pole
Parallels
N
S
E
W
South pole
15
Latitude
N
S

• Latitude is the elevation angle of a point on
  the Earth
• above the equator.
• Northern latitude (N) if north of the equator,
• southern (or negative) latitude (S) if south of
  it.
• Parallel is a ring of the intersection with
  Earths
• surface of a plane parallel to the Equatorial
  plane.

16
Longitude

• MeridianA great circle on the surface of the
  Earth, passing through the geographical poles and
  some third point on the Earth's surface.
• All points on a given meridian have the same
  longitude.

E
W
17
Joensuu in Google Earth
Longitude 632041.64 N Lattitude
284647.62 E
http//www.gorissen.info/Pierre/maps/googleMapLoca
tion.php
18
Projection

• A cartographical map projection is a formal
  process
• which converts maps between a spherical or
  ellipsoidal surface and a projection surface,
  often flat.

19
Map projections
20
Planar Orthographic projection
Normal Transverse Oblique
(Polar) (Equatorial)
21
Planar Stereographic projection
Polar Equatorial
Oblique
22
Planar Gnomonic projection
Polar Equatorial
Oblique
23
Planar polar projections
Orthographic Stereographic
Gnomonic
where (?,?) are Longitude and Latitude, and
(?,?) are polar coordinates on the projected
plane The Earth is a sphere. R is radius of the
Earth.
24
Planar polar projections
North Pole
Equator
For simplicity
25
Cylindrical projections
Normal (regular) Transverse
Oblique
26
Conic projection
Conformal conic map
27
View Earth from Sun (1)
19 January at 16.00 UTC
19 January at 08.00 UTC
UTC Coordinated Universal Time is a time
standard based on International Atomic Time (TAI)
with leap seconds added at irregular intervals
to compensate for the Earth's slowing rotation.
28
View Earth from Sun (2)
March 22 September 20 / 0700 UTC
June 21 0700 UTC
December 21 0700 UTC
1. View today at 0000 UTC? 2. Which projection?
29
View Earth from Sun (2)
March 22 September 20 / 0700 UTC
June 21 0700 UTC
December 21 0700 UTC
Orthographic projection
