Wispry Incorporated Tunable RF Solutions

1
Wispry IncorporatedTunable RF Solutions

• Mark Chapman
• Vice President , Business Development
• mark.chapman_at_wispry.com

2
Wispry Overview

• Fabless Product Company
• Established in October 2002 Spin-Out of Coventor
• 28 Employees, Headquartered in Irvine California
• Raised 8M in Venture Capital (Seed and A Rounds)
• Team has Worked On Wispry Core Technology Since
  1999
• Sampling Customers with RF Switch Module Products
• Tunable RF Filter Development Program with
  Leading Handset Supplier
• Start Production Shipments in 4Q 05

3
What is The Problem

• Integration has largely driven cost out of
  Transceiver
• CMOS Has Driven Path to Single Chip Transceivers
• Yet Critical RF Filters and Duplexers Remains
  Discrete

Antenna
Duplexer
Baseband
Transceiver
Diplexer Switch
Power Amp
Isolator
Duplexer
TX Filter
4
On Chip RF Filters are Key to Further Silicon
Integration of Radio Subsystems

• WiSpry Uses RF MEMS to Create Tunable RF Filters
  Which
• Increase Integration
• Lower Cost and Size
• Reduce Power Consumption While Improving
  Performance
• Simplify RF Design
• Supply Through Successive Levels of Integration
• Initially RF Front End Components and Modules
• RF Subsystem Modules
• Fully Integrated PAs and Single Chip Transceivers

5
New Wireless Technologies Continue to Evolve
IEEE-802.11a IEEE-802.11b IEEE-802.11g IEEE-802.1
1n
1000 500 200 100 50 20 10 5 2 1 .5
IEEE-802.16 IEEE-802.16a IEEE-802.16d IEEE-802.16e
IEEE 802.11 Proprietary
Wireless MAN
Wireless LAN
Mbps
GSM GPRS EDGE CDMA 2000 3G 802.20
Wireless PAN
Bluetooth UWB IEEE-802.15.1 IEEE-802.15.3 IEEE-802
.15.4
Wireless WAN inc Cellular
.1 1 10 100
1,000 10,000
Distance (meters)
.. A Proliferation of Wireless Bands and
Standards
6
Advancing Radio Complexity Means More Filters

• Proliferation of new Standards and new Frequency
  Bands
• Each Additional Band has its own Filter
• Each New Standard has its own Unique Filter
  Requirements
• 3G Phones (CDMA WCDMA) are Full Duplex
• Requires Additional Costly Duplexer
• Increases Insertion Loss, Lowers Sensitivity,
  Lowers Battery Life
• Diversity Receive and MIMO Systems use Multiple
  Radios
• Each with its own RF Chain
• Each Requiring Additional Filters, Switches etc

7
Wisprys Approach.
Standard Design Library
MEMS RF Products
Standard CMOS Compatible Manufacturing Process
.Leverage Existing Semiconductor Infrastructure
and Processes
8
Digital Switch Technology

• Separate Signal and Control Path
• No Coupling of Control Signal into RF Path
• High Isolation Delivers Excellent RF Performance
• Intra Switch Isolation Enables High Device
  Density
• High RF Performance
• Excellent Linearity, Insertion Loss, Isolation,
  Low Power
• Patented Tri-Layer Beam Creates Isolated
  Structures
• Eliminates Charging Effect, Improves
  Reliability, Size

9
wiSpry RF-MEMS Devices in Action

• Actuation of RF-MEMS
• Voltage is applied to the cantilever and
  substrate
• This results in an electro-static field like a
  capacitor
• The field causes the plate to deflect in an
  upward or downward motion
• The switch opens and closes completing a circuit
  path for the RF input

Click on this picture for animation
10
Dual SP2T MEMS Switch
11
MEMS Switch Technology

• Significant Performance advantages over Type III
  IV semiconductors and SOI at 6 GHz
• Lowest insertion loss lt(0.40 dB)
• Best return loss characteristics (gt20 dB)
• Best (on or off) Isolation (gt75 dB)
• Best linearity at Intercept Points (IPs) 2 3
• Easy migration to 10 GHz and beyond.

12
wiSpry Switch Product Evolution
30 V Control
3 V
RF
RF
MEMS Controller DIE
30V
3 V 2-bit Control
RF
RF
30V
30 V Control
RF
RF
High Voltage Version
Low Voltage Version
13
3V Switches with Integrated Chargepump

• Production Low Voltage 3V Packaged Switches
• 3V External, 30V Internal Operation, SP2T, SP4T
  and SP6T Versions
• Two Die Solution,- Chargepump and Switch
• 24 pin 5 x 6 x 1.5mm Ceramic QFN SP2T, SP4T
• 32 Pin 5 x 6 x 1.5mm Ceramic QFN SP6T

14
Switched Capacitor Options

• Continuously variable capacitor
• Two-state capacitor bank

• Switched fixed capacitor arrays

15
Digital Capacitor Overview

• Electrostatically Operated Binary State MEMS
  Capacitor
• Completely Isolated Digital Control
• Up (low) and Down (high) Capacitive States
• Hard Down Stop Provides Precise Control
• Capacitor Value Controlled by Dielectric Type and
  Plate Size
• Each MEMS Capacitor Has a Fixed and a Tunable
  Portion
• Array Formed by Selecting Various Capacitor Types
• Wide Range of Values Achievable, Several Cap
  Structures Developed
• Binary Progression of Capacitor Values provides
  Compact Structure

Binary State MEMS Cap
16
MEMS Capacitor Arrays
Detail Showing Digital MEMS Capacitor Array
MEMS Capacitor Array Offers a unique solution for
precision tuning in RF Devices
17
Layout of Capacitor Die

• Shows 2 Capacitors on Die
• 8 Tuning Bits per Cap
• Central Structure is Fixed Cap
• Top Pins are Drive, Bottom RF

18
CMOS Project Status

• Building RF-MEMS in 8 Inch CMOS
• The basic ingredients for MEMS switched
  capacitors have been demonstrated.

19
Capacitor Overview Cont

• Future Implementation Will add Control and Driver
• 3.3V External operation
• Integrated High Voltage Driver and Control
• Internal Control Multiplexer (e.g. 3/8, 8/64,
  Serial, I2C etc)

20
Overcoming Key MEMS Manufacturing Challenges.
WiSPRY Innovation
Perceived Issue in Handsets
21
Next Generation Applications
RF Transceiver with MEMS Components
22
Next Generation Applications
Smart Antenna with MEMS Components
23
MEMS in Advanced Radio Architectures- Optimized
Antenna Matching

• Impedance variations
• On metal surface impedance / 2
• Open/closed clamshell
• Temperature swings
• 10 power reflection -gt0.5 dB loss
• Band switching
• Match shift and optimization
• Reconfigurable antenna
• Use RF MEMS for variable transformer and/or to
  implement switchable antenna configuration

24
Future MEMS-Driven Applicatons
Dynamic Load Control Tunable Amplifiers

• Power control
• Load matching
• Frequency matching

• Optimum transistor load line at full power
• (3V)2/2 watts 4.5 ohms
• Optimum transistor load line at 10 power
• (3V)2/0.2 watts 45 ohms
• High Q MEMS Capacitors adjust output impedance
  and PA internal matching
• Possibly separate harmonic adjustment
• Maintain efficiency near 50

25
Summary

• Handsets and other Wireless Platforms Require an
  Increasing Number of Complex Filters and Switches
• Filters Limit Level of Integration and Cost
  Reduction
• Only WiSpry Offers High Performance, Tunable
  Filters and Switches That Are Integrated with
  Active Silicon, Optimizing Size, Power, Cost and
  Performance
