Exercises in Remote Calls

1
Exercises in Remote Calls
2
Organizational

• I have located the draft of the birman book. Can
  we make copies and get them bound?
• Design Patterns are you familiar with them?
• (e.g. Doug Schmidt et. Al. Design patterns for
  distributed applications (c but useful for java
  people too)

3
Books HDM needs to order for Distributed Systems

• Doug Lea, Concurrent Java Processing (get a
  handle on threads!)
• Middleware für verteilte Systeme (MIKO ORB,
  CORBA) (deutsch)
• Ken Birman, Building Secure and Reliable Network
  Applications
• Jack Shirazi, Java Performance Tuning
• Adam Bien, Java J2EE Frameworks (deutsch)

Please tell me about others!
4
Looking back at our socket exercises

• Slides on www.kriha.de
• Where have we been cheating?(hardware
  assumptions, protocol)
• What was the Naming Service?
• A natural next step servlets!

5
Newsletters and DMOZ

• Theserverside.com
• Javaworld.com
• www.developers.ibm.com (developers connection of
  IBM
• www.alphaworks.ibm.com (research programs)
• www.jguru.com
• Java delelopers connection (JDC)
• www.dmoz.org Open Directory Project (for the
  non-search type people. Look for distributed
  computing.

6
Exercises (1)

• Design the INTERFACE of a stack class for use in
  a single threaded environment and one for use in
  multi-threaded environments.
• Can it be the same?
• Can the behavior (implementation) be the same?
  Should it be?
• Can you create a remote stack object for use by a
  procedural language (using the RPC model?)

7
Stack API

• Interface Stack
• push(object)
• object pop()
• int count()

A fairly generic stack api.
8
Single-threaded case

• Interface Stack
• push(object)
• object pop() // if stack is empty?
• int count()

The only problem is what we do in case the stack
is empty and pop() is called. Return null or
throw an exception? Null is a surprise to the
caller (the interface does not say anything about
this possibility). An exception would suggest
that the proper use of the interface is to always
check count() before calling pop()
9
Multi-threaded case

• Interface Stack
• push(object)
• object pop() // if stack is empty?
• int count() // how long is the result valid?

Again the problem is what we do in case the stack
is empty and pop() is called. In addition to
returning null or throwing an exception we
could now wait (blocking) for another thread to
call push(object). This would allow the stack to
be used as a work order queue between two
threads. And how useful is count()? Its result
is immediately outdated and cannot be used to
make a save pop() call (other threads might have
emptied the stack in the meantime)
10
Result (1) Interfaces

• The interface for single- and multi-threaded
  stacks should be different, not only the
  implementation. (Waldos point is true)
• We cannot build an interface that is ideal for
  both cases.
• Threading is orthogonal to regular interface
  design!

11
Result (2) Pre-and Postconditions

• How does the problem look if we specify the exact
  pre- and postconditions of every method?
• For a further discussion see Bertrand Meyer,
  Object-Oriented Software Construction. (look at
  his stack example he assumes single-threaded of
  course (-)
• The concept of pre and postconditions
  (invariants) will (hopefully) make it into Java
  as a new feature.

12
Exercises (2)

• Which of the following operations are idempotent?
• Pressing an elevator button?
• Writing data to a file?
• Appending data to a file?

13
Results (1)

• Which of the following operations are idempotent?
• Pressing an elevator button? YES
• Writing data to a file? YES, always starts
  writing from offset 0 and thereby overwriting the
  old content.
• Appending data to a file? NO, each request will
  append its data and the file grows.

14
Exercises (3)

• Which of the following technologies is better
  suited for data schlepping (transfer of large
  volumes of data)?
• Socket based programs
• Remote Procedure Calls
• Remote Method Invocation (RMI, CORBA)

15
Exercises (3)

• Which of the following technologies is better
  suited for data schlepping (transfer of large
  volumes of data)?
• Socket based programs (e.g. ftp)
• Many projects tried to use e.g. CORBA for large
  transfers. Remote procedure calls are NOT made
  for this too many layers between sender and
  receiver (marshaling, reliable request-reply
  etc). Ive even seen the EVENT service used for
  large volume data transmission this is
  nonsense! But it shows the importance of best
  practices which have to be learnt first with all
  new middleware.

16
Exercises (4)

• Two applications exchange some information
  through a file. Design a message format
• Not self-describing
• Self-describing

17
Inter-application data transfer using files

• While simple at the first glance synchronization
  issues pop up quickly
• When does the receiver know that it can read the
  new file (aka sender is done with writing)?
• Who can remove the used files?
• When can someone remove the used files?
• Add a new field. What needs to change in both
  cases?

18
Non-self-describing format
Walter Kriha 79424711
Reader Parser Read(0,29,firstName) Read(30,10,las
tName) Read(40,4, zipCode) Read(44,4,account)
Writer Write(firstName, 0) Write
(lastName,30) WriteZipcode(zip,40) WriteAccnt(accn
t,44)
Both reader and writer know the byte position and
order of the elements. If an element changes (5
number zipcode) the reader parser breaks (it has
an extra character at the end) and (error prone)
code on both sides needs to change
19
Self-describing format
ltsomeformatgt ltfirstnamegtWalterlt/firstnamegt ltlast
namegtKrihalt/lastnamegt ltzipcode typenumeric
len4gt7942lt/zipcodegt ltaccountgt7411lt/accountgt lt/so
meformatgt
This structure allows the receiver parser not
only to check the validity of each message
against a common schema or dtd (document type
description). It also allows the construction of
a small framework that deals with new elements
automatically.
20
Writer adds a new element

• Receiver can fail the transaction and cry foul
  validation error against schema!
• Alternatively, the receiver can deal only with
  known elements and ignore the new ones that it
  has no code (behavior) for.
• Alternatively, the receiver can ask a factory for
  a class that can deal with each new element. New
  classes are loaded dynamically from a directory.
  The addition of new elements is now very easy and
  does NOT need ANY code changes, just a new class
  per new element. No parser changes either!

21
Use of factory pattern to supply classes for new
elements
startElementEvent(newelement)
DOM Factory contains different node types
XML App
createElement(newelement,)
Element Node
Tree of DOM nodes
22
More interesting questions on flexibility

• How does the factory know which class to return
  for which element? Either the classes are started
  automatically after load and register themselves
  with the factory, telling it which element will
  be handled or a configuration info will map
  classes and elements.
• When does the factory know to look for new
  classes?

For applications of dynamic class loading see
Ted Neward, server side java programming
23
Projects

• Can we make groups already?
• Servlets are also OK.

24
Web-Services
25
Enterprise Java Beans
Start with Java Reference Implementation. Solve
Infrastructure Problems for other EJB Server
(Database, Installation etc.) www.theserverside.co
m (book an EJBs etc.)
26
Message Oriented Middleware
Look at MQSeries, SwiftMQ, SonicMQ, iBus
27
Peer-to-Peer
www.openp2p.com (portal for p2p), Andy Oram
book. www.jxta.org (SUNs new p2p layer)
28
RMI
www.javaskyline.com (portal for RMI and other
java technologies)
29
Hints

• When you start searching for technology or
  installing middleware take notes about the steps
  youve chosen and why you did things the way you
  did.
• Write down your installation decisions.
• Write down your questions (e.g. what is
  middleware XXX good for?)

30
Next Exercises

• RMI (possibly some CORBA stuff)
• Prepare javaskyline.com/learnrmi.html
• Has many links to demos and tutorials
