Cluster Analysis

1
Cluster Analysis

• Craig A. Struble
• Department of Mathematics, Statistics, and
  Computer Science
• Marquette University

2
Overview

• Background
• Example K-Means
• Dissimilarity
• Tangent K-Nearest Neighbor
• Partitioning Methods
• Hierarchical Methods
• Probability Based Methods
• Interpreting Clusters

3
Goals

• Explore different clustering techniques
• Understand distance measures
• Define new distance measures
• K-nearest neighbor classification and data
  imputation
• Interpret clustering results
• Applications of clustering

4
Background

• Clustering is the process of identifying natural
  groupings in the data
• Unsupervised learning technique
• No predefined class labels
• Classic text is Finding Groups in Data by Kaufman
  and Rousseeuw, 1990
• Several implementations
• R and Weka

5
Clustering
6
Visualizations
7
Example K-Means
Algorithm Kmeans Input k number
of clusters t number of
iterations data the
data Output C a set of k
clusters cent arbitrarily select k objects as
initial centers for i 1 to t do for each d
in data do assign label x to d such that
dist(d, centx) is minimized for
x 1 to k do centx mean value of all
data with label x
8
K-Means Example

• Use Euclidean distance (l is number of
  dimensions)
• Select 10,4 and 5,4 as initial points

9
K-Means Clustering
3 clusters
2 clusters
10
Cluster Centers
11
K-Means Summary

• Very simple algorithm
• Only works on data for which means can be
  calculated
• Continuous data
• O(knt) time complexity
• Circular cluster shape only
• Outliers can have very negative impact

12
Outliers
13
Calculating Dissimilarity

• Many clustering algorithms use a dissimilarity
  matrix as input
• Instance x Instance

14
Continuous (Interval-scaled)

• Euclidean distance
• Manhattan (or city block) distance
• Minkowski distance

15
Boolean Attributes

• Contingency Table
• Symmetric (trues and falses carry equal
  information)

Object j
Object i
16
Boolean Attributes

• Assymmetric, true and false differ in importance
• Test for HIV positive
• Number of matches on false, t, not important
• Jaccard coefficient

17
Boolean Example
18
Nominal Attributes

• Count the number of matches m
• The total number of attributes is p

19
Nominal Example
20
Ordinal Attributes

• Use ordering to rank the attribute
• none/1, some/2, full/3
• Replace rank with standardized value 0,1
• Calculate using interval dissimilarity value

21
Ratio Attributes

• Recall Meaningful zero point
• Generally, only positive values on non-linear
  scale
• Often follow exponential laws in time
• Decay of radiation intensity
• for some constants A and B

22
Options for Ratio Attributes

• Treat them as interval values
• Perform a log transformation
• Treat as an ordinal value, transforming the
  values into rankings.

23
Example

• Suppose we had calculated the radiation
  intensities of two samples after 10 seconds.
• x1 8.0 x210.0
• Option 1 (Euclidean Distance)
• diss(x1,x2) 2.0
• Option 2 (log2 transformation)
• y1log28.03 y2log210.03.32
• diss(x1,x2)0.32

24
Example (cont.)

• Option 3 (Ordinal transformation)
• Assume that 8 is the 4th highest, 10 is the 8th
  higest, and there are 10 total values
• y1 (4-1)/(10-1) 0.33
• y2(8-1)/(10-1)0.78
• diss(x1,x2)0.45

25
Combining Multiple Types

• Let xi be the ith instance
• Let xif be the fth attribute of xi
• Let ?ij(f)0 if xif or xjf are missing, 1
  otherwise
• Let dij(f) be the distance measure for feature f
  of xi and xj

26
Combining Multiple Types

• If f is binary or nominal
• dij(f)0 if xifxjf or 1 otherwise
• If f is interval-based
• where h runs over instances not missing f
• If f is ordinal or ratio-scaled, calculate ranks
  and z score, then treat as interval.

27
Example
28
Standardization

• When working with interval-scaled variables only,
  its often necessary to standardize the values
• Avoid bias towards one attribute
• Calculate mean mf of attribute f
• Calculate mean absolute deviation
• Calculate z score for the attribute for each
  instance

29
Tangent K-Nearest Neighbor (KNN)

• Simple classification technique
• Let y be a new instance to classify
• Find the K nearest instances (with labels) to y
• Classify y with the label appearing most
  frequently

30
Data imputation with KNN

• Use KNN technique with instance missing a value
  as described previously
• Take the mean (median, mode, etc.) of the K
  nearest neighbors
• Use the value to fill in for the missing value

31
Example (Data Imputation)
32
Assessing Data Imputation

• Use the data imputation technique of choice
• Calculate the mean squared error
• Use a statistical test to identify confidence
  range of error
• Need to identify distribution of error (e.g.
  normal, etc.)

33
Partitioning Methods

• K-Means (already done)
• K-Medoids (PAM)
• CLARA
• Fuzzy Clustering

34
Clustering
35
K-Medoids

• K-Means is restricted to numeric attributes
• Have to calculate the average object
• A medoid is a representative object in a cluster.
• The algorithm searches for K medoids in the set
  of objects.

36
K-Medoids
37
PAM Algorithm

• PAM consists of two phases
• BUILD - constructs an initial clustering
• SWAP - refines the clustering
• Goal Minimize the sum of dissimilarities to K
  representative objects.
• Mathematically equivalent to minimizing average
  dissimilarity

38
PAM Algorithm (BUILD Phase)

• Algorithm PAM (BUILD Phase)
• // Select k representative objects that appear to
  minimize
• // dissimilarities
• selected // empty set
• for x 1 to k do
• maxgain 0
• for each i in data - selected do
• for each j in data - selected do
• // See if j is closer to i than some
  other
• // previous selected object
• let Dj min(diss(j,k) for each k in
  selected)
• let Cji max(Dj - diss(j,i), 0)
• gain gain Cji // total up
  improvements from i
• if gain gt maxgain then
• maxgain gain
• best i
• selected selected best // best
  representative object chosen

39
PAM Algorithm (SWAP Phase)

• Algorithm PAM (SWAP Phase)
• // Improve the partitioning, selected comes from
  BUILD phase
• besti besth first element in selected
• repeat
• selected selected - besti besth // swap i
  and h
• minswap 0
• for each i in selected do
• for each h in data - selected do
• swap 0
• for each j in data - selected do
• let Dj min(diss(j,k) for each k
  in selected)
• if Djltdiss(j,i) and Djltdiss(j,h)
  then
• // closer to something else
• swap swap 0 // do
  nothing
• else if diss(j,i) Dj then //
  closest to i
• let Ej be min(diss(j,k) for
  each k in selected - i)
• if diss(j,h) lt Ej then
• swap swap diss(j,h) -
  Dj
• else

40
PAM Output (from R)
41
PAM Output (from R)
42
Silhouettes

• These plots give an intuitive sense of how good
  the clustering is
• Let diss(i,C) be the average dissimilarity
  between i and each element in cluster C
• Let A be the cluster instance i is in
• a(i) diss(i,A)
• Let B ltgt A be the cluster such that diss(i,B) is
  minimized
• b(i) diss(i,B)
• The silhouette number s(i) is

43
Silhouettes

• Let s(k) be the average silhouette width for k
  clusters.
• The silhoutte coefficient of a data set is
• The k that maximizes this value is generally the
  best of clusters to use

44
CLARA

• Clustering LARge Applications
• Modification of PAM
• Draw a sample from large data set
• Size is typically 402k
• Use PAM to find medoids of sample
• Use medoids to assign clusters to entire data
• Can take multiple samples and choose best
  resulting clustering

45
Fuzzy Clustering (FANNY)

• Previous partitioning methods are hard
• Data can be in one and only one cluster
• Instead of saying in or out, give a percent of
  membership
• This is basis for fuzzy logic

46
Fuzzy Clustering (FANNY)

• Algorithm is a bit too complex to cover
• Idea Minimize the objective function
• where uiv is the unknown membership of object i
  to cluster v

47
FANNY Results
48
FANNY Results
49
Huh?
50
Whoa!
51
Hierarchical Methods

• Top-down vs. bottom-up
• Agglomerative Nesting (AGNES)
• Divisive Analysis (DIANA)
• BIRCH

52
Top-Down vs. Bottom-Up

• Top-down or divisive approaches split the whole
  data set into smaller pieces
• Bottom-up or agglomerative approaches combine
  individual elements

53
Agglomerative Nesting

• Combine clusters until one cluster is obtained
• Initially each cluster contains one object
• At each step, select the two most similar
  clusters

54
Cluster Dissimilarities
diss(i,j)
R
Q
55
AGNES Results
56
AGNES Results
57
AGNES Modifications

• The dissimilarity between clusters can be defined
  differently
• Maximum dissimilarity between two objects
• Complete linkage
• Minimum dissimilarity between two objects
• Single linkage
• Centroid method
• Interval scaled attributes
• Wards method
• Interval scaled attributes
• Error sum of squares of a cluster

58
Divisive Analysis (DIANA)

• Calculate the diameter of each cluster Q
• Select the cluster Q with the largest diameter
• Split into A and B
• Select object i that maximizes
• Move i from A to B if max value gt 0

59
DIANA Results
60
DIANA Results
61
BIRCH

• Balanced Iterative Reducing and Clustering Using
  Hierarchies
• Mixes hierarchical clustering with other
  techniques
• Useful for large data sets, because entire data
  is not kept in memory
• Identifies and removes outliers from clustering
• Due to differing distribution of data
• Presentation assumes continuous data

62
Two central concepts

• A cluster feature (CF) is a triple summarizing
  information about a cluster
• where N is the number of points in the cluster,
  LS is the linear sum of the data points, SS is
  the square sum of data points.

63
Two central concepts

• Contain enough information to calculate a variety
  of distance measures
• Addition of CFs accurately represents CF for
  merged clusters
• Memory and time efficient to maintain

64
Two Central Concepts

• A CF tree is a height balanced tree with two
  parameters, branching factor B, and threshold T.

Root
CF1
CF2
CF3
CFn
CF11
CF12
CF13
Level 1
CF1n
Clusters
65
Phase 1 Build CF tree

• CF tree is contained in memory and created
  dynamically
• Identify appropriate leaf Recursively descend
  tree following closest child node.
• Modify leaf When leaf is reached, add new data
  item x to leaf. If leaf contains more than L
  entries, split the leaf. (Must also satisfy T.)

66
Phase 1 Build CF tree

• Steps continued
• Modify path to leaf Update CF of parent. If leaf
  split, add new entry to parent. If parent
  violates B, split parent node. Update parent
  nodes recursively.
• Merging refinement Find some non-leaf node Nj
  corresponding to a split stoppage. Find two
  closest entries in Nj. If they are not due to the
  split, merge the two entries.

67
Phase 1 Comments

• The parameters B and L are a function of the page
  size P
• Splits are caused by P, not by data distribution
• Hence, refinement step
• Increasing T makes a smaller tree, but can hide
  outliers
• Change T if memory runs out. (Phase 2)

68
Phase 3 Global Clustering

• Apply some global clustering technique to the
  leaf clusters in the CF tree
• Fast, because everything is in memory
• Accurate, because outliers removed, data
  represented at a level allowable by memory
• Less order dependent, because leaves have data
  locality

69
Phase 4 Cluster Refinement

• Use centroids of the clusters found in Phase 3
• Identify centroid C closest to data point
• Place data point in cluster represented by C

70
Probabilistic Methods

• These will be delayed until we cover
  probabilistic methods in general
• Mixture Models
• COBWEB

71
Applications of Clustering

• Gene function identification
• Document clustering
• Modeling economic data

72
Gene Function Identification

• Genome is the blueprint defining an organism
  (DNA)
• Genes are inherited portions of the genome
  related to biological functions
• Proteins, non-coding RNA
• Given the collection of biological information,
  try to predict or identify the function of genes
  with unknown function

73
Gene Expression

• A gene is expressed if it is actively being
  transcribed (copied into RNA)
• Rate of expression is related to the rate of
  transcription
• Microarray experiments

74
Gene Expression Data
Experiments
Clones
75
Clustering Gene Expression Data

• Identify genes with similar expression profiles
• Use clustering
• Identify function of known genes in a cluster
• Assign that function to genes of unknown function
  in the same cluster

76
Clustering Gene Expression Data
Yeast Genome
77
Document Classification

• Represent documents as vectors in a vector space
• Latent Semantic Indexing
• Cluster documents in this representation
• Describe/summarize/evaluate the clusters
• Label clusters with meaningful descriptions

78
Document transformation

• Convert document into table form
• Attributes are important words
• Value is number of times word appears

79
Document classification

• Could select a word as classification label
• Identify after clustering
• Look at medoid or centroid and examine
  characteristics
• Look at of times certain words appear
• Look at which words appear together
• Look at words that dont appear at all

80
Document Classification

• Once clusters identified, label each document
  with a cluster label
• Use a classification technique to identify
  cluster relationships
• Decision trees for example
• Other kinds of rule induction

81
Economic Modelling

• Nettleton et al. (2000)
• Objective is to identify how to make the Port of
  Barcelona the principal port of entry for
  merchandise.
• Statistics, clustering, outlier analysis,
  categorization of continuous values

82
Data

• Vessel specific
• Date, type, origin, destination, metric tons
  loaded/unloaded, amount invoiced, quality
  measure, etc.
• Economic indicators
• Consumer price index, date (monthly), Industrial
  production index, etc.

83
Data Transformation

• Data aggregated into 4 relational tables
• Total monthly visits, etc.
• Joined based on date
• Separated into training (1997-1998) and test sets
  (1999)

84
Data Exploration

• Used clustering with Condorcet criterion
• IBM Intelligent Miner
• Identified relevant features
• Production import volume gt 400,000 MT for product
  1
• Area import volume gt 250,000 MT for area 10
• Then used rule induction to characterize clusters

85
Cluster Analysis Summarization

• Unsupervised technique
• Similarity-based
• Can modify definition of similarity to meet needs
• Usually combined with some other descriptive
  technique
• Decision trees, rule induction, etc.
