Title: MachineDetector Interface


1
Machine-Detector Interface
  • David Urner
  • JAI / Oxford University

2
Topics
  • ILC energy spectrometer
  • Force-neutral Anti-Solenoid
  • QD0-Service Cryostat Prototype
  • Luminosity Optimization
  • Push-Pull
  • Background-Driven SiD Design Decisions
  • Extraction Line
  • Radiation Shielding

3
Proposed ILC energy spectrometer
Bino Maiheu
  • Precision measurement dE/E 10-4
  • Minimal impact on beam itself allowed emittance
    growth from SR
  • Limited space budget in BDS 60 m
  • Minimal impact on physics data taking for e.g.
    calibration runs
  • Magnetic chicane with high resolution beam
    position monitors cavity BPM
  • Max 5 mm dispersion at center chicane
    determines resolution
  • Emittance growth determines chicane layout
  • Diagnostics needed
  • Gain drifts temperature
  • Mechanical stability interferometer
  • Magnetic fields (?B.dl ) NMR, Hall, fluxgate
    magnetometers

4
T474 test experiment at ESA, SLAC
  • ESA comparable repetition rate, bunch charge,
    energy spread as ILC
  • Possibility to vary bunch length, energy, charge
  • Easy steering with feedback system
  • Build an energy spectrometer prototype, using a 4
    magnet chicane
  • Goal is to demonstrate the stability of this type
    of energy measurement at 10-4 level, and
    investigate how such a magnetic chicane can be
    operated most efficiently at the ILC
  • Operate at 5 mm ?X at centre chicane as in
    current ILC design
  • Need lt 1mm resolution on position measurement
    (BPM) with position measurement stability over
    multiple hours of 100 nm

5
(No Transcript)
6
(No Transcript)
7
QD0-Service Cryostat Prototype
  • BDS RD plan stresses importance of integrated
    systems testing of an engineering prototype (QD0
    with connection to service cryostat)
  • to establish the degree of coupling of external
    vibration sources to the QD0 cold mass.
  • What noise is expected from technical systems?
  • How well can the QD0 cold mass be isolated?
  • What about bellows?
  • Are there any internal modes to worry about?
  • How well can QD0 be supported in the detector?
  • How do we isolate the QD0 cryostat from external
    vibration sources?
  • Particular attention is needed in this regard to
    the design of the cryogenic transfer line between
    the service and QD0 cryostats.

8
Luminosity Optimization
  • GuineaPig (beam-beam interactions)
  • New features
  • beam-beam effects on bhabhas
  • C
  • all keywords of guinea-pig are now available
  • hadrons (do_hadrons)
  • minijets (do_jets)
  • pairs (do_pairs)
  • abstract I/O interface
  • separate algorithms and I/O
  • plugging different format (ascii)
  • plugging graphical interface
  • FONT Simulation
  • Fast feedback using bunch kick-angle to correct
    for y and y.
  • Simulation of fast feed-back using PLACET (beam
    transport), GuineaPig (beam-beam interactions)
    and Matlab (fast feed-back)
  • Simulation based on Glen Whites code
    incorporating
  • Newest Lattice
  • Smaller wake fields
  • Similar results as
  • with old code
  • Ready to incorporate
  • additional effects and
  • other feedback loops.
  • Likely Result A much worse behaviour

9
Luminosity Optimization
  • MONALISA
  • Relative position measurement of two QD0 magnets
    with respect to each other using interferometers
  • Position changes few nm (requires continuous
    uninterupted measurements)
  • Absolute distance below 1mm (can be done at any
    time)
  • Use as input for FONT
  • Test on FONT simulation how effective this is in
    reducing convergence time particularly under bad
    beam conditions (as one would expect for startup
    or after a longer period with no beams).
  • Requires light path (half inch pipe) through SiD
    yoke from QD0 to the ground.

10
Luminosity Optimization
  • Luminosity feedback
  • Luminosity sensitive to bunch shape ? optimum at
    y?0
  • After IP position and angle feedbacks (based on
    kick-angle monitor) have converged maximise
    luminosity directly using luminosity monitor
    based on BeamCal and GamCal
  • BeamCal Detector
  • .003 lt ? lt .02 rad
  • ?3.5m from IR
  • Pairs curl in the magnetic field
  • Measure the ?104 beam-strahlung ee- pairs/bunch
  • GamCal Detector (B Morse)
  • ?180m from IR integrated into polarimeter chicane
  • ?10-4 X0 to convert beam-strahlung gammas into
    ee- pairs
  • Converter could be gas jet or a thin solid
    converter
  • Dipole magnet with PT kick 0.25 GeV/c separates
    the pairs from beam electrons
  • Calorimeters outside vacuum after magnet measure
    the 1-10 GeV positrons

11
Luminosity OptimizationVertical Offset
M.Ohlerich
  • complementary information from
  • total photon energy vs offset_y
  • BeamCal pair energy vs offset_y

ratio of E_pairs/E_gam vs offset_y is
proportional to the luminosity similar behaviour
for angle_y, waist_y
see also EUROTeV-Memo-2006-011
12
Statistical Error for BX
  • If at startup less than 10 nominal luminosity
  • beamcal might not give much of a luminosity
    measurement from a single bunch.
  • Conclusion BeamCal and GamCal provide robust
    complimentary information.

13
Push pull
  • Assertions - Superconducting magnet (detector
    final focus) warm-up/cool-down time scales are
    long enough that these magnets have to be moved
    while cold?
  • But they may be de-energized?
  • If true, this drives a need for long umbilical
    connections to each of the experiments that are
    able to accommodate 20 m motion while cold.
  • In last few weeks lots of discussions about
    possible layouts

14
Push Pull
  • Separate cryostats for QD and QF magnets
  • QD0 carried by detector at optimized L
  • Cantilevered support tube concept dead
  • QF never moves and z-position of QF same for
    all detectors
  • Distance between the 1st and 2nd SC quads after
    IP is increased to provide sufficiently long warm
    section for push-pull design.
  • For three options of L 3.51 m, 4.0 m, 4.5 m,
    the SC extraction quad QDEX1 is placed at 5.5 m,
    5.95 m and 6.3 m. The 2nd SC quad QFEX2A is at
    fixed position, 9.6 m from IP.
  • A long drift after QFEX2A provides transverse
    space for crab-cavity.

15
Push-Pull Alignment after Move
  • Assume repositioning accuracy of detector 1mm.
  • Use MONALISA system to measure remaining
    difference to O(mm)
  • Realign QD0 using MONALISA information
  • Unclear yet how QD0 is supported
  • Use y and y kickers to steer beam correctly into
    QD0 based on MONALISA data
  • From here FONT should do the trick.
  • Would expect that silicon Tracker and VXD have to
    be realigned as well.
  • Is some method of position monitoring for the
    tracking detectors foreseen?

16
Background-Driven SiD Design Decisions
Takashi Maruyama
17
Background-Driven SiD Design Decisions Current
Beam pipe is not compatible with the Low P or
High Lumi options.
R 1.2 cm ? 1.5 cm (Low P), and R 1.2 cm ? 1.8
cm (High Lumi).
18
Background-Driven SiD Design Decisions New SiD
Geometry
  • LumiCal
  • Z156.75 168 cm
  • Rinside6cm
  • compatible with
  • Nominal 5 Tesla
  • Nominal 4 Tesla
  • Low P 5 Tesla
  • Beampipe
  • Original 43 mrad cone cylinder
  • BeamCal
  • Study background as a function of BeamCal
    z-position

LumiCal
43 mrad
Move BeamCal
Cylinder
19
Tracker Hits vs. BeamCal DZ
Si Tracker photons
Barrel VXD e/e- hits
Barrel
  • VXD hits
  • No effects from LumiCal/BeamCal changes
  • Si Tracker hits
  • Less photons (20) due to smaller radius LumiCal
  • photons increases by moving the BeamCal
    forward.
  • But the rate is acceptable if ?Z lt 30 cm.

Endcap
20
Extraction Line
  • The quads focus the beam to the 2nd focus at
    Compton IP with R22 -0.5 transformation.
  • The diagnostic contains energy and polarimeter
    chicanes, two proposed GAMCAL bends and the fast
    kickers for sweeping the beam on 3 cm circle at
    the dump window.
  • Two collimators are included in the energy and
    polarimeter chicanes, and three collimators are
    in the final 100 m drift to protect the kickers
    and limit the beamsize to within the R 15cm
    dump window.

21
Extraction Line
  • The original 4-bend symmetric polarimeter chicane
    is modified to increase the strengths of the 3rd
    and 4th bends by 50 which improve acceptance of
    Compton backscattered electrons in the Cherenkov
    detector.
  • The 5th and 6th bends are added to the
    polarimeter chicane which close the orbit bump
    and can be used by the proposed Gamma Calorimeter
    (B. Morse).
  • Fast sweeping kickers
  • Without beam collision, the undisrupted nominal
    beam size is too small (2.42 x 0.29 mm2) at the
    dump window.
  • A system of 5 horizontal and 5 vertical fast
    kickers is included 90 m before the dump. The
    rapidly oscillating x and y kicker field (1 kHz)
    sweep the beam on 3 sm circle at the dump window.
    This was shown to be sufficient to protect the
    dump window and prevent water boiling in the dump
    vessel (L. Keller).

22
Neutrons from the Beam Dump
New FLUKA simulation (Darbha)
x (cm)
Quadrupole aperture
2.4 cm
3.7?1010 ns/cm2/y
2.4 cm
7 mrad
n
3.0 cm
VXD Layer 1 fluence (one beam) 1.8?1010
ns/cm2/y w/o BeamCal 4.3?108 ns/cm2/y w BeamCal
Be
Si VXD
W BeamCal
z (cm)
23
Neutrons in VXD (FLUKA)
Neutrons from pairs
Neutron origins
BeamCal
Neutrons from radiative Bhabhas
Beampipe
M1
Z (cm)
  • Neutrons that reach the vertex detector are
    mostly generated in the BeamCal.
  • Anti-DID can reduce the neutron flux.
  • Different L design should not affect the neutron
    flux.

24
Modelling of spent beam
(Nosochkov)
  • 5T post-IP solenoid including anti-DID field with
    orbit and focusing correction have been modelled.
  • Disrupted beam loss on magnets small in nominal
    option
  • Manageable in a large energy spread option
  • High loss at diagnostic collimators if at IP
  • Large y-offset
  • Non-zero y-angle
  • Particularly in large energy spread option
  • Driven by nonlinear dispersion from dipole
    correctors
  • To reduce this effect
  • a) the design IP y-angle is minimized,
  • b) anti-DID field is increased,
  • c) dipole corrector field is brought closer to
    IP.
  • In machine operation, the beam running with large
    y-offsets at IP should be efficiently detected
    and prevented.

25
Radiation Shielding
  • Shaft and wall between detectors
  • Shielding capability of a SID
  • Effects of gaps for cables and tubes
  • Pacman thickness
  • Inner diameter
  • Requirement of penetration
  • Effects from upstream part (muon etc)
  • 3D Monte-Carlo simulation ? MARS15-MCNP code is
    used

26
Other Topics
  • Intensive discussions particularly in preparation
    of the ILC Interaction Region Engineering Design
    Workshop at SLAC 17-21 Sept.
  • 4 workgroups
  • WG-A Overall detector design, assembly, detector
    moving, shielding.
  • WG-B IR magnets design and cryogenics system
    design.
  • WG-C Conventional construction of IR hall and
    external systems.
  • WG-D Accelerator and particle physics
    requirements

27
The End
28
Backup slides
29
Preliminary spectrometer results
  • Taking into account Taking into account ?B.dl and
    deflection at center of chicane, can B.dl and
    deflection at center of chicane, can
  • compute correct beam energy compute correct beam
    energy
  • Have to Have to subtract incoming orbit subtract
    incoming orbit in each event prove we measure
    just energy ! in each event prove we measure
    just energy !
  • Further detailed analysis, Further detailed
    analysis, spectrometer stability studies
    spectrometer stability studies underway...
    underway...
  • More and better data to come in July...

30
Power loss for L 3.51 m with 5T solenoid
  • Loss on magnets is still small or modest, but
    loss on diagnostic collimators may become high
    when both y-offset and y-angle at IP are large,
    particularly in high disruption options c14
    (c15).
  • Therefore, large IP orbit offsets need to be
    efficiently controlled. Further improvement of
    diagnostic collimation system should be studied.
  • The source of the higher loss is the non-linear
    dispersion created by the corrector field. It
    increases the orbits of low energy electrons
    which may be consequently lost.
  • In order to reduce the non-linear dispersion, the
    corrector fields need to be lowered and,
    possibly, brought closer to IP for more local
    correction. The following may be considered
  • The uncorrected IP y-angle is minimized.
  • The anti-DID field is increased, so the
    correcting fields on the SC quads are reduced.

31
(No Transcript)
32
Current SiD layout
33
(No Transcript)
Write a Comment
User Comments (0)
About PowerShow.com
