Experience from DECT Wireless Office Solutions

1
Experience fromDECT Wireless Office Solutions

• Dr. Heinz Ochsner, Secretary
• DECT Forum
• http//www.dect.ch

2
Marketing Hypes
This technologyis suitable for everything!

Understand thatIt is not suitable for
everything!
Recognise thatmain applications from technical
and market perspectiveare X and Y
A technology for product applications X and Y
Marketing Hype
Development Excitement
Maturity
The Idea
History
3
Agenda

• What is DECT?
• Office Applications
• Recent Developments
• Other Technologies
• Lessons for the Future
• Conclusions

4
DECT What is it at all?
Digital EnhancedCordless Telecommunications

• Unlicensed use
• Optimised for
• Inhouse communications
• Cellular structures to cover large complexes
• Uncoordinated applications
• Integrated voice-/data-applications
• Current data concepts had been included from the
  very beginning
• Most popular technology for private (as opposed
  to provided) services and applications

5
DECT A worldwide standard

• ... Adopted in more than 110 countries

Source DECT Forum
6
Cumulative Sales by Application
Source DECT Forum
7
DECT Key Parameters
See also the Technical Documentat
http//www.dect.ch

• TDMA/MC/TDD Access Method
• Original band 1880 to 1900 MHz, 10 carriers
• 1.152 Mbit/s gross modulated bit rate per carrier
  with standard modulation
• 3.456 Mbit/s gross modulated bit rate per carrier
  with enhanced p/8 D8PSK modulation
• 10 ms frames providing 24 time-slots
• 250 mW peak TX power
• Dynamic Channel Selection/Allocation
• Terminal-directed seamless handover
• High level of security

8
Two Focus Areas

• Network Termination for Service Provider
• xDSL
• Cable
• WLL
• 3G (radio or Iu)
• Home and Office Networking
• Voice Communications
• Data Communications
• Unified Communications (CTI, UMS)
• Building Automation
• Entertainment

9
Network Termination
Service
xDSL
Provider
Cable
twisted pair
WLL
3G
10
Home/SOHO Scenario
DPRS
ISDN-Basic Rate Access
11
Wireless LAN/Internet Access
12
Increasing Data Traffic
13
High speed data

• Speeds between 24 kbit/s and 2098 kbit/s per
  direction available for packet and circuit
  switched use
• Wide variety of products from various suppliers
  already available commercially, more to be
  launched in 2002

14
Connection Oriented Data Standards

• D2 profile
• 32 kbit/s unrestricted isochronous data
• E2 profile
• 1.2 kbit/s messaging services
• Application Specific Profiles CTM-FP2 (DECT-SMS)

15
Packet Oriented Data Standards

• DECT Packet Radio System (DPRS)
• Up to 552 kbit/s
• Migration to 2 Mbit/s
• Asynchronous Connections
• V.24 and Ethernet Interworking
• Application Specific Profiles DMAP for
  Multimedia Applications

16
DECT Data Products
17
DECT Conformance Certification

• Device under Test is tested against
  specification

• Device under Test is tested against commercial
  products
• Device under Test may bear a quality mark

18
High Lights

• High System Bandwidth
• up to 34.56 Mbit/s gross
• up to 21.88 Mbit/s net (error protected)
• Protected exclusive frequency band
• Intelligent frequency escape mechanism
• Controllable quality of service
• Support for latest service developments
• Fixed SMS, EMS, MMS
• WAP

19
Positioning of DECT

• Functionality
• Security and reliability
• Service level
• Cost of investment
• Cost of ownership

20
Wireless Technologies
Source DECT Forum
21
Potential of DECT data services
End-to-End services
Wide Area
Local Area
The first feet
Bluetooth WLAN/DECT 2G 3G
mobile
IP services to mobile devices
22
Future Outlook DECT Migration Path
y
t
i
l
a
n
o
i
t
c
n
u
F
IMT 2000
High Level
(IMT/FT)
Modulation
DPRS
up to 2098 kbit/s
GAP
Data Communication
24 to 552 kbit/s
Time
23
DECT is 3G
IMT-DS
IMT-MC
IMT-SC
IMT-TC
Direct
Multi
Single
Time-Code
Spread
Carrier
Carrier
TDMA
FDMA
CDMA
24
DECT UMTS Scenario
UMTS Core
USIM
I
u
DECT
Base Station

• IMT-FT (DECT) base stations are connected to
  the UMTS core network via Iu Interface
• USIM-enabled IMT-FT (DECT) terminals offer
  access to the full set of 3G services

25
The Lessons to Learn

• There is a difference between mobile and wireless
  (locally mobile) solutions
• Most solutions require data and voice
• There is a market for privately owned systems
• Service providers need to focus on variety,
  flexibility, quality of service, and support
• There is no technology that makes it all
• Involve all the drivers in the industry
• Dont talk about it, deliver it !!
• Dont advertise the technology limits

26
