Dengue Fever

1
Dengue Fever

• Epidemiology and the Viruses
• Dr Wilson Lam
• Division of Infectious Diseases
• Department of Medicine QEH
• 3 June 2003

2
Dengue fever

• Dengue history
• The viruses and the vector
• Transmission of viruses
• Epidemiology
• Global
• Southeast Asia
• Hong Kong
• Epidemiological features
• DF
• DHF/DSS
• Reimmergence of dengue fever

3
Historical background

• Dengue like illness date back to more than 200
  years ago
• 1779-1780 in Asia, Africa and North America
• Viral etiology established by the 1940s
• Global pandemic in Southeast Asia after World War
  II

4
Dengue viruses

• SS-RNA arbovirus (Flavivirus)
• 4 serotypes (DEN-1, 2, 3, 4)
• Based on envelop glycoprotein
• DEN-1 and 3 are more closely related
• DEN-4 less closely related to others
• Virulent variants (genotypes) within serotype
• Infection with any serotype confers specific
  lifelong immunity
• Transient cross-protection to other serotypes
• Any serotype can cause severe / fatal disease

5
Mosquito vectors

• All known vectors belong to genus Aedes
• Vector competence and vectorial capacity of
  different species vary
• Different species
• Different geographic populations of the same
  species
• No correlation between clinical features of
  subsequent disease

6
Mosquito vectors

• Subgenus Stegomyia contains the most important
  vectors of dengue viruses
• Ae. aegypti, Ae. albopictus and Ae. polynesiensis
• Ae. aegypti
• African origin
• Not found in Hong Kong
• Most important vectors worldwide
• Linked with human activities such as uncontrolled
  urbanization, deterioration of urban environment
  and decreasing standard of sanitation

7
Ae. Albopictus (1)

• Asian species
• South-East Asia, China, Japan, Indonesia, islands
  in the Indian Ocean, Hawaii
• Spreading to the United States, South America,
  Africa, the Pacific and south of europe
• Originally a forest mosquito feeding on a variety
  of animals and breeding in tree holes
• Become adapted to human environment
• Natural containers such as tree holes, plant
  axils, cut bamboo stumps and opened coconuts
• Outdoor artificial containers such as water
  storage barrels and trash receptacles

8
Ae. Albopictus (2)

• Can persist as far north as Beijing or Chicago
  (average isotherm of 0ºC)
• Optimal growth at 25 C to 30C
• Eggs can resist desiccation for several months
• 10 days for egg-larva-purpa-adult cycle
• Ae. albopictus females known to survive for up to
  122 days (daily mortalities 8-15)

9
Ae. Albopictus (3)

• Density much influenced by rainfall
• Feed outdoors during daytime
• Peak at 8-9 a.m. 5-6 p.m.
• Multiple bites per feed
• Active maximum dispersal range of females about
  400 to 600m
• Passive dispersal less important

10
Transmission of viruses
Extrinsic Incubation Period 1-2 weeks
Vector Humidity Rainfall Temp.
Incubation Period 3-14 days
Susceptible hosts, (population) Source patients
Viraemia Fever 5-7 days
11
(No Transcript)
12
Transmission of viruses

• Extrinsic incubation period
• 10 to 14 days
• Depends on
• Ambient temperature
• Humidity
• Viraemic level in the human host
• Virus strains
• Intrinsic incubation period
• 4 to 7 days (Range 3-14 days)
• Viraemia may exist for 6 to 18 hours before onset
  of symptoms
• Symptomatic viraemic period is 4 to 5 days (up to
  12 days)

13
Dengue fever endemic regions
At Risk Population 2500 million Dengue cases /
Yr. 50 million (DHF 500 000) Brazil
2001 390,000 cases (670 DHF)
14
Dengue in Southeast Asia
WHO 2001
15
Stratification of DF/DHF in South-East Asia Region

• Category B (Bangladesh, India, Maldives, Sri
  Lanka)
• DHF is an emergent disease
• Cyclical epidemics are becoming more frequent
• Multiple virus serotypes circulating
• Expanding geographically within countries
• Aedes aegypti is the principal epidemic vector
• Role of Aedes albopictus is uncertain

• Category A (Indonesia, Myanmar, Thailand)
• Major public health problem
• Leading cause of hospitalization and death among
  children
• Cyclical epidemics in urban centres with 3-5 year
  periodicity
• Spreading to rural areas
• Multiple virus serotypes circulating
• Aedes aegypti is the principal epidemic vector
• Role of Aedes albopictus is uncertain

16
DF Macau

• 1,502 cases in 2001 mostly indigenous
• First 14 cases reported in late August 2001
• Last case in December
• All were minor cases without complications
• Origin and cause unknown
• Mostly serotype DEN-2 (2 cases of DEN-1)
• Up to end September 2002
• Only 1 imported case (Thailand)

17
DF Hong Kong 2002
18
DF Hong Kong 2002
19
Dengue in Hong Kong

• From 1994 to 2001, inclusive
• Cases DF (68), DHF (4)
• All were imported cases
• Peak incidence at September (?return from travel)
• 2002 (up to 19 October)
• 20 indigenous cases
• all DF, aged 20 to 72 yrs., Male 13
• 16 cases related to Ma Wan (6 residents, 10 CSW)
• onset early July to 25 September
• All except one, were DEN-1
• index case was suspected on 19 Sep. 2002
• HK strains were different phylogenetically from
  Macau strains.

20
DF Hong Kong 2003
21
Epidemiological features

• Dengue fever (DF)
• Dengue haemorrhagic fever (DHF) and dengue shock
  syndrome (DSS)
• DHF is not DF with haemorrhagic features

22
DF epidemiology

• Spread
• Endemic or epidemic
• Travel along transportation routes
• First appears in seaport and airport cities

23
DF epidemiology

• Seasonality
• Usually rainy seasons
• Vectors, such as Ae. albopictus, that have
  outdoor larval habitats more affected by rainfall
• High humidity
• Longer mosquito survival
• High temperature
• Vector distribution
• Adult longevity
• Shorter extrinsic incubation period
• Smaller females more blood meals
• Water cooler recirculation troughs during dry
  seasons

24
DF epidemiology

• Severity
• Vary in rate of transmission, percentage of
  population involved and clinical severity
• Age
• Pre-adolescent children less severe
• Nearly all adults overt illness
• Immune status
• Highly immune population less reported disease

25
DF epidemiology

• Severity
• Ethnicity
• Strain variation
• Disease severity and haemorrhagic phenomenon vary
  from outbreak to outbreak
• Unique serotype or viral strain-specific factors
• Level of circulating viruses

26
DF epidemiology

• Age/sex
• Mostly adults
• Adult women and pre-school children in some
  outbreaks
• Transmission by daytime-biting

27
Dengue Hemorrhagic Fever (DHF)
4 Necessary Criteria (WHO)

• Fever, or recent history of acute fever
• Hemorrhagic manifestations (grade I II)
• Low platelet count (?100,000/mm3)
• Objective evidence of leaky capillaries
• elevated hematocrit (?20 over baseline)
• low albumin / hypoproteinaemia
• pleural or other effusions

First recognized in the Philippines in 1953
28
Dengue Shock Syndrome (DSS)

• 4 criteria for DHF
• Evidence of circulatory failure
• Rapid and weak pulse
• Narrow pulse pressure (? 20 mm Hg) OR hypotension
  for age
• Cold, clammy skin/altered mental status (grade
  III)
• or profound Shock (grade IV)

29
DHF/DSS epidemiology

• Early reports
• 1897 Northern Australia
• 1928 Greece
• 1935 Taiwan
• 1950 Thailand
• mid-1980s Southern China and Hainan Island
• Asian DHF/DSS epidemics
• Multiple types of dengue viruses simultaneously
  or sequentially endemic
• Secondary-type antibody responses observed
• Only during secondary dengue infections

30
DHF/DSS epidemiology

• Infection parity and enhancing antibodies
• Secondary-type dengue infections
• Primary in infants born to dengue-immune mothers
• Antigens shared between first and second
  infecting serotypes
• Shift the spectrum towards more severe disease

31
DHF/DSS epidemiology

• Pathogenesis of antibody dependent enhancement
• Serum antibodies developed can neutralize dengue
  virus of that same serotype (homologous)
• Pre-existing heterologous antibodies form
  complexes but no neutralization
• Infected monocytes release vasoactive mediators
• Increased vascular permeability
• Haemorrhagic manifestations

32
(No Transcript)
33
(No Transcript)
34
(No Transcript)
35
DHF/DSS epidemiology

• Protective antibodies
• Low levels of cross-reactvie neutralizing
  antibody protect against DHF/DSS
• Different viral antigens?
• Epitopes closely similar to serotype-specific
  neutralizing epitopes of another virus
• Different host response?
• Human immune system responds differently to a
  single specific repertoire

36
DHF/DSS epidemiology

• Viral strain
• Severity
• Viruses which causes mild and severe disease
  appear genetically identical
• Occurrence or non-occurrence
• Only dengue viruses of Asian origins at epidemic
  proportion
• Distribution of heterotypic and non-heterotypic
  antigens

37
DHF/DSS epidemiology

• Age
• Greatest susceptibility to shock is 8 to 10 years
• ? Capillaries of of children more prone to
  cytokine-mediated increased permeability
• Sex
• Shock cases and deaths more frequently in female
  than in male children
• ? Immune responses of females more competent
• ? Capillary bed of females more prone to
  increased capillary permeability

38
DHF/DSS epidemiology

• Nutritional status
• Moderate to severe protein-calorie malnutrition
  reduces risk to DHF/DSS in dengue infected
  children
• Malnutrition suppresses cellular immune responses
• Preceding host conditions
• Peptic ulcer and menstrual periods risk factors
  for severe bleeding

39
Reemergence of DF/DHF

• Unprecedented human population growth
• Unplanned and uncontrolled urbanization
• Inadequate waste management and water supply
• Increased distribution and densities of vector
  mosquitoes
• Lack of effective mosquito control
• Increased movement and spread of dengue viruses

40
Thank you!
41
Dengue Fever Case Definition

• For Epidemiological Purposes
• Suspected case
• An acute febrile illness characterized by intense
  headache, retro-orbital pain, myalgia,
  arthralgia, rash, leucopenia or haemorrhagic
  manifestations.
• Probable case A clinically compatible case with
  supportive serology.
• Confirmed case A clinically compatible case with
  laboratory confirmation.

42
Laboratory support for case definition

• Supportive serologic findings
• An antibody titer of ?1280 or
• a positive IgM antibody test
• on a single serum sample to Dengue antigen.
• Criteria for laboratory confirmation (? one)
• Isolation of Dengue virus from patient samples
• A ?4x change in antibody titers to Dengue
  antigens in paired serum samples
• Detection of Dengue virus genomic sequences
  patient samples by PCR.

43
Serological Profile
Primary Infection IgMgtIgG Secondary Infection
IgGgtIgM
39.5
39.0
38.5
Temperature (degrees Celsius)
Dengue IgM (EIA units)
Percent Virus Positive
38.0
viraemia
37.5
37.0
-4
-3
-2
-1
0
1
2
3
4
5
6
Fever Day
Dengue IgM
Mean Max. Temperature
Virus
Vaughn et al., J Infect Dis, 1997 176322-30.
44
Virological Diagnosis

• Dengue-specific tests
• Virus isolation
• Serology
• HAI
• IgM Immunochromatographic
• IgM EIA
• Real Time - PCR

45
Rapid Strip Test False Positives
Sequential testing or confirmation is required.
BOOK K M EBV IgM ve
46
Rapid Strip Test False Positives

• Fever for 2 weeks
• Live in Sai Kung area
• Cleaning work
• headache, skin rash,

• myalgia, hearing impairment
• Fundi haemorrhage
• ALT 561,
• Chest basal crepitations
• prolonged PT/APTT
• Weil-Felix OX-K 1640

47
Ovitrap index

• Ovitrap
• black container, with rough surface, water
• placed 1m above the ground, 100m apart
• 50 traps in an area of 0.5 km2
• incubate for 1 week at 25C
• Index
• the of trap showing Aedes albopictus larva
• reflects the extent (but not the density) of
  infestation.

48
Ovitrap in hospital area
49
Ovitrap index in Hong Kong
Sing Pao 20 Oct 2002 Press Release FEHD December
21, 2002
50
Control of Dengue Fever

• Statutory Notification since 1994
• Laboratory surveillance
• Active case finding
• Self-reporting (DH hotline [phone])
• Global surveillance
• Case investigation
• Information dissemination

51
Control of Dengue Fever

• Case investigation
• confirm diagnosis
• travel history
• local movement
• potential mosquito breeding sites
• S/S among travel local collaterals
• medical surveillance of collaterals

52
Blood Transfusion transmitted DF

• Donor M/17 lives in Ma Wan.
• Date of donation 17/07/2002 well and
  asymptomatic
• attended YCH AED on 24 July, DX Viral rash
• ? DF during case finding exercise in Ma Wan in
  October
• blood tested positive for Dengue
• his serum sample in BTS archive was PCR ve
• Recipient F/72, QMH anaemia
• received RBC on 24/8/2002 (D7 post-donation)
• fever on 27/8/2002 (D3 post-transfusion)
• No travel history
• fever resolved after 4 days
• blood taken on 7/10/2002 was IgM ve and IgG HAI
  titre of 12560
