ThickFilm Multilayer Microwave Circuits for Wireless Applications

1
Thick-Film Multilayer Microwave Circuits for
Wireless Applications

• Charles Free
• Advanced Technology Institute
• University of Surrey, UK
• and
• Zhengrong Tian
• Formely with Middlesex University
• Now with NPL

1
2
University of Surrey ? Located in Guildford ?
30km south of London ? Approx. 5000 students ?
Single campus - lot of student accommodation
on-site ? Technological university ? Research-led
university ? Top of UK research ratings in
Electronic Engineering
3
School of Electronics Research Groups ? Surrey
Space Centre Small satellites design
construction control ? Advanced Technology
Institute Semiconductors ion beam applications
microwave systems ? Centre for Communication
Systems Research Mobile satellite
communications ? Centre for Vision, Speech and
Signal Processing Medical Multimedia
Robotics
4
Advanced Technology Institute Microwave
Systems - MMIC design - RF and Microwave
MCMs - Microwave circuits and antennas -
thick-film (including photoimageable)
processing - access to clean rooms (class 1000
and class 100) - measurement capability to
220GHz
5
Thick-Film Multilayer Microwave Circuits for
Wireless Applications
6
CONTENTS ? Introduction ? Thick-film
technology ? Significance of line losses ?
Single layer microwave circuits ? Multilayer
microwave circuits ? Summary
3
7
INTRODUCTON
8
Typical frequencies for wireless
applications Current mobile 0.9GHz -
2GHz 3G systems 2.5GHz Bluetooth
2.5GHz GPS 12.6GHz LMDS 24GHz and
40GHz Automotive 77GHz
9
Driving forces created by the wireless
market ? lower cost ? higher
performance ? greater functionality ?
increased packing density
10
Microstrip basic microwave interconnection
structure
11
Summary of key material requirements at
RF Conductors - low bulk resistivity - good
surface finish (low surface roughness) - high
line/space resolution - good temperature
stability Dielectrics - low loss tangent
(lt10-2) - good surface finish - precisely
defined ??r (stable with frequency) - isotropic
??r - consistent substrate thickness - low
Tf (lt 50 ppm/oC)
28
12
RF Transceiver Architecture
13
Features of an RF MCM
9
14
THICK-FILM TECHNOLOGY
15
Thick-Film Technology Advantages Low
Cost Feasibility for mass production Adequate
quality at microwave frequencies Potential for
multi-layer circuit structures Difficulty Fabri
cation of fine line and gaps limited quality
by direct screen printing
16
Standard range of materials is
used CONDUCTORS - gold - silver -
copper DIELECTRICS - ceramic (alumina) -
green tape (LTCC) - thick-film pastes -
laminates Plus photoimageable conductors and
dielectrics
23
17
Fine lines lt 25 micron with 1 micron
precision High density, 4 micron thick
conductor High conductivity - 95 of bulk
96 Al
50?m lines
Photodefined conductors
18
MICROSTRIP RESONANT RING TEST STRUCTURE
19
Microstrip Resonant Ring
can be used to measure total line loss and vp
(measure Q ? loss, measure fo ? vp ) does not
separate conductor and dielectric loss ring is
loaded by input and output ports - source of
measurement error
20
Meander-line test structure
can be used to measure total line loss and vp
(measure Q ? loss, measure fo ? vp ) does not
separate conductor and dielectric loss ring is
loaded by input and output ports - source of
measurement error
21
Chamfering of the corners is a necessary
precaution in microstrip to avoid reflections
22
Comparison of measured and simulated loss in a
50? line fabricated on 99.6 alumina. substrate
thickness 254?m and line width 255?m
23
Measured line loss 50? thick-film microstrip line
24
Typical microstrip line losses
29
25
Skin effect at RF and microwave frequencies
current tends to flow only in the surface of a
conductor Skin depth (?) depth of penetration
at which the magnitude of the current has
decreased to 1/e of the surface value
Significance surface of conductors must be
smooth and the edges well defined to minimise
losses
27
26
Effect of surface roughness on the loss in a
microstrip line
30
27
Effect of loss tangent on line loss
31
28
32
29
33
30

• LTCC TECHNOLOGY
• LTCC technology is a well-established
  technology
• Reliability established in the automotive
  market
• Advantages for high frequency applications
• parallel processing (? high yield, fast
  turnaround, reduced cost)
• precisely defined parameters
• high performance conductors
• potential for multi-layer structures
• high interconnect density

31

• LTCC TECHNOLOGY
• Microwave applications
• ?? LTCC can meet the physical and electrical
  performance demanded at frequencies above 1GHz
• ? Increases in material and circuit production
  are reflected in lower costs LTCC is now
  comparable to FR4
• ? Significant space savings when compared to
  other technologies, such as FR4

32
SIGNIFICANCE OF LINE LOSSES
33
MICROWAVE RECEIVER
LNA
Feeder
BPF1
BPF2
Mixer
Schematic of front-end of a microwave receiver
34
RECEIVER NOISE PERFORMANCE
Feeder
BPF1
BPF2
LNA
Mixer
System noise temperature (Tsys)
35
RECEIVER NOISE PERFORMANCE

• Significance of expression for Tsys
• noise performance dominated by first stage
• a lossy first stage introduces noise
• Tfeeder (L -1) 290
• a lossy first stage magnified noise from
• succeeding stages Gfeeder lt 1

36
Dielectric Properties _at_ 9GHz Material ?r Tan ? x
10-3 99.5 AL 9.98 0.1 LTCC1 7.33 3.0 LTCC2 6.
27 0.4 LTCC3 7.2 0.6 LTCC4 7.44 1.2 LTCC5 6.
84 1.3 LTCC6 8.89 1.4
Published material data
37
CALCULATED RESULTS Noise figure variation
38
SINGLE-LAYER MICROWAVE CIRCUITS
39
Single-layer microstrip circuits ? all
conductors in a single layer ? coupling between
conductors achieved through edge or end
proximity (across narrow gaps) Problem ?
difficult to fabricate (cheaply in production)
fine gaps, possibly ? 10?m
40
End-coupled filter
Directional coupler
Examples of single-layer microstrip circuits
41
DC break
Edge-coupled filter
Examples of single-layer microstrip circuits
42
MULTI-LAYER MICROWAVE CIRCUITS
43
Multilayer microwave circuits ? conductors
stacked on different layers ? conductors
separated by dielectric layers ? allows for
(strong) broadside coupling ? eliminated need for
fine gaps ? registration between layers not as
difficult to achieve as narrow gaps ?
technique well-suited to thick-film print
technology ? also suitable for LTCC technology
44
Multilayer configuration
45
Thick-film technology is particularly suitable
for the implementation of multilayer circuits ?
higher packing density ? integration of
antenna ? close coupling between
conductors Circuit examples ? DC
block ? Directional coupler
46
Directional Coupler
Multilayer Concept
Single Layer Structure
47
2dB Directional Coupler - Measured Results
48
3dB Directional Coupler - Measured Results
49
?/4
Microstrip DC block
50
Multilayer DC block
51
Measured performance of multilayer DC block
52
Measured performance of multilayer DC block
53
SUMMARY
54
SUMMARY ?? Thick-film technology provides a
viable fabrication process for wireless
circuits at microwave frequencies ? Multilayer
microwave circuits can offer enhanced
performance for coupled-line circuits ? Photoima
geable thick-film materials extend the usable
frequency range to mm-wavelengths
