IT1202Fundamentals Of Programming Object Oriented Concepts and Techniques

1
IT1202-Fundamentals Of ProgrammingObject
Oriented Concepts and Techniques
2
Introduction to Object Oriented Programming

• The idea of Object Oriented
• Programming is
• organize your programs in a way
• that mirrors the way objects are
• organized in the real world

3
Thinking in terms of Objects

• This is a way to look at a program as a set of
  objects that work together in predefined ways to
  accomplish tasks
• Using OOP, your overall program is made up of
  different components called objects

4
An Object ?

• An object is a self-contained element of a
  computer program that represents a related group
  of features and is designed to accomplish
  specific tasks
• Also known as instances
• Each object has a specific role in a program, and
  all objects can work with other objects in
  defined ways

5
Object

• An Employee object (say employee1)
• will have the following
• attributes (what it knows)
• Name
• age
• salary
• It will have the following
• behavior (what it can do)
• set salary
• get salary
• set name
• set age

6
A Class

• Definition A template used to create
• multiple objects with
  similar
• features.
• Classes embody all features (attributes
  behaviour) of a particular set of objects
• When writing a program in an OO language, you do
  not need to define individual objects
• Instead, define classes of objects (template)

7
A Class

• eg A Tree that describes the features of all
  trees
• Has leaves roots
• Grows
• Creates chlorophyll
• The Tree class serves as an abstract model for
  the concept of a tree

8
Class.

• Some objects that
• will be in tree class

9
Class..
WashingMachine
Attributes
brandName modelName serialNumber capacity
Objects
A Class
addClothes() addDetergent() removeClothes()
methods
10
Attributes and Behavior

• Every class written in java is made up of two
  components
• Attributes and Behavior
• Attributes
• Individual things that differentiate one class
  of objects from another
• Determine the appearance, state and other
  qualities of that class
• eg Color orange, raw amber, lemon yellow, maize

11
Attributes and Behavior.

• Behavior of a Class of Objects
• Behavior is the way that a class of objects can
  act to change their attributes

12
Behavior.

• Examples for behavior
• Get angry
• Calm down
• Eat an ice cream
• Behavior for a class of objects is done by
• using methods

13
Example of a class (template for an object)

• public class Employee
• private String name
• private int age
• private float salary
• public void setName(String tName)
• Name tName
• public void setSalary (float tSalary)
• salary tSalary
• public float getSalary ()
• return salary

Attributes
Methods
14
Creating a Class..

• Open the text editor to create Java programs.
• Start with class definition
• eg
• class Jabberwock
• Then create instance variables
• eg
• String color
• boolean hungry

15
Creating a Class.

• After that the programmer can add behavior to the
  class by adding methods
• eg
• void feedJabberwock()
• if (hungry true)
• System.out.println(yum an ice
  cream)
• hungry false
• else
• System.out.println(No, thanks I
  have already eaten)

16
Creating Objects

• Objects are created by instantiating
• classes
• To use a class in a program, you must first
  create an instance of it
• Objects of a class can be created using the new
  operator

17
Creating objects..

• Example
• Employee newEmp new Employee()

Constructor
Variable containing an Object reference
Class Name
18
Methods

• Methods are group of related statements in a
  class of objects that act on themselves and on
  other classes of objects
• Used to accomplish specific tasks
• Objects communicate with each other using methods

19
Defining methods
Can be any primitive type or a class Name or void
(no return statement)
Optional
modifier returnType MethodName (parameter List)
statement(s)
20
Methods..

• The return Type, Method Name, and the
  parameter list defines the Signature of the
  method
• It is possible to define two or more methods
  with the same name within the same class (Method
  Overloading) with different signatures
• Methods are two types - instance methods and
  class methods

21
Methods..
1.public void CreatePoint( ) 2.public void
CreatePoint(int x , int y)
22
Methods..

• Accessing methods

An instance method can be accessed using the
dot(.) operator as shown below.
ObjectName.method()
A class method can be accessed by using the class
name followed by a period and then the method
name
Integer.parseInt(25)
23
What is a constructor?

• Constructor is also a method
• It is a special method
• Method name same as the class name
• No return type
• It allocates memory for the instance object
• called automatically when an instance is
  created/constructed
• If not defined still and object will be created
• If defined variables can be initialized in your
  own way

24
this and super keywords

• this keyword
• this keyword is used to refer to the current
  object

• It can be used to
• Refer to the current objects member variables
• Refer to current objects methods
• Pass a reference to a method of the current
  object
• Return a reference from the current object

25
this keyword
Refers to the member variable x in this object
tthis.x this.myMethod(this) return this
Calls the myMethod defined in this class and
pass it to this Object
Return this Object
26
super keyword

• super keyword is used to refer to the
• Super or parent class

Invokes super class Constructor
super( ) super(x,y) super.f( )
Invokes super class Constructor with x and y
arguments
Calls the super class function called f( )
27
Object Oriented Concepts

• Three basic concepts underlining Object Oriented
  Programming
• Data Abstraction with Encapsulation
• Inheritance
• Polymorphism

28
Encapsulation

• Enables you to hide, inside the object, both the
  data fields and the methods that act on that data

29
Encapsulation..

• Object CAR
• Attributes
• speed,direction
• Number of people it can carry
• Methods
• Steer() ,
• PressGasPedal(),
• PressBreak()
• Loadpeople()

30
Encapsulation..

• Encapsulation is achieved by using Modifiers
• Modifiers are Language Keywords that modify the
  definition of a Class, Method or a Variable
• Access to variables and methods in Java classes
  is accomplished through Access Modifiers
• Access modifiers define varying levels of access
  between class members and the outside world
  (other objects)

31
Encapsulation..

• Access modifiers are declared immediately before
  the type of a member variable or the return type
  of a method
• modifier returnType MethodName (parameter List)
• There are four access modifiers
• Default (package access)
• Public
• Protected
• Private

32
Inheritance

• One class of objects inheriting the data and
  behavior from another class of objects

33
Inheritance

• class for a regular car.

Class Car direction
position speed
Steer() PressGasPedal()
PressBreak()
Data members/ Attributes
Methods
34
Inheritance
Suppose you want to create a new car which has a
special passing gear
Class PassingCar inherits from Car
Pass()
Pass() is a method that implements the new
functionality
35
Inheritance

• Through inheritance you can express the
  differences among related classes
• You share the functions and member variables that
  implement the common features
• Inheritance also helps you to reuse existing code
  from one or more classes by simply deriving a new
  class from them

36
Inheritance

• Inheritance is the creation of one class by
  extending another class so that instances of the
  new class automatically inherit the fields and
  methods of its parent class
• Inheritance promotes the class Reusability
• It is because an existing class can be sub
  classed through inheritance and any modifications
  necessary could be applied to the sub class
  (Overriding)

37
Inheritance

• In Java the extends Keyword is used to achieve
  Inheritance

public class threeDPoint extends twoDPoint
sub class
super class
Java does not Support Multiple Inheritance
38
Inheritance

• A class that cannot be instantiated is known as
  an Abstract Class
• An Abstract Class
• is defined to be extended to sub classes
• uses abstract Keyword in the Definition

39
Inheritance
abstract class Shape abstract Point Center(
) abstract double Diameter( ) abstract double
Area( )
Can be used to create any shape Such as Circle
or Square
40
Polymorphism

• Combines Greek Words
• Poly , Morphism
• Poly Many
• Morphism Forms
• The quality of having more than one form

41
Polymorphism

• In the context of Object Oriented Programming,
  polymorphism refers to the fact
• A single operation can have different behavior in
  different objects

42
Polymorphism

• It allows different forms of the same service to
  be defined
• There are two common ways of implementing
  Polymorphism. Overloading, Overriding
• Overloading - Using the same method name with
  different parameter type lists within the same
  class
• Overriding - Using different implementations of
  the same method in sub classes

43
Lets consider some examples which are
illustrating some of the concepts of object
Orientation
44
Lets simulate a box in Java
Depth
Height
Width
45
Lets simulate a box in Java
Introduce the class
class Box
46
Lets simulate a box in Java
Introduce instance variable
class Box double width double height double
depth
47
Lets simulate a box in Java
Save and compile
class Box double width double height double
depth
48
Lets simulate a box in Java
Some important notes

• In the class the main() method is not written
• Class is just a template
• During designing one creates a class
• During Run time objects are created

49
Lets simulate a box in Java
Using the class Box

• Create a class which is having the main() method
  (our program)
• Declare a variable of the class Box
• Use them in the program

50
Lets simulate a box in Java
Using the class Box
class BoxDemo public static void main(String
args)


51
Lets simulate a box in Java
Declare a variable of Box with values
class BoxDemo public static void main(String
args)
Box myBox new
Box() myBox.width3 myBox.height5 myBox.depth
4

52
Lets simulate a box in Java
Using the class Box
class BoxDemo public static void main(String
args)
Box myBox new
Box() myBox.width3 myBox.height5 myBox.depth
4

myBox
53
Lets simulate a box in Java
Lets calculate the volume of the myBox
class BoxDemo public static void main(String
args)
Box myBox new Box() myBox.width3 myB
ox.height5 myBox.depth4 System.out.println(myB
ox.width myBox.heightmyBox.depth)


54
Lets simulate a box in Java
new keyword

• Box myBox new Box()
• Java does three things when new is used
• Allocate memory for the object
• Initialize that objects instance variables,
  either to initial values or to a default(0 for
  numbers,null for objects, false for Booleans
  ,\0 for characters)
• Calls the constructor method of the class which
  might be one of several methods

55
Lets simulate a box in Java
Initialization

• myBox.width3
• myBox.height5
• myBox.depth4
• When the variables are initialized of the myBox
  instance object
• width 3, height 5, depth 4

56
Lets simulate a box in Java
The output

• System.out.println(myBox.width
  myBox.heightmyBox.depth)
• When this statement is executed the volume of my
  box will be calculated and will output to the
  screen

57
Lets simulate a box in Java
When the program executed
58
Lets simulate a box in Java
Methods

• Methods written to manipulate data
• Methods written to allocate memory(constructors)

59
Lets simulate a box in Java
Add a method to the class Box

• To calculate the volume lets create a method
• Name of the method is calcVol()
• No parameters are used
• No returning values

60
Lets simulate a box in Java
Add a method to the class Box
How do we write a method? Return type
methodName(Parameter list) Body of the method
61
Lets simulate a box in Java
Add a method to the class Box
void CalcVol( ) System.out.println( width
height depth)
resultant value will be out put to the screen
62
Lets simulate a box in Java
Add a method to the class Box
class Box double width double height double
depth void CalcVol() System.out.println( width
height depth)

63
Lets simulate a box in Java
Add a method to the class Box

• Save the file Box.java
• Compile the file
• But you can not execute the file
• because this is a class file( no main())

64
Lets simulate a box in Java
Add a method to the class Box

• How do we use methods(call methods)
• We have to call methods from our program
• Our program name is BoxDemo
• When we call the method we have to refer to the
  method using the instance name and dot operator

65
Lets simulate a box in Java
Use a method in the BoxDemo
66
Lets simulate a box in Java
What is a constructor?

• Constructor is also a method
• It is a special method
• Method name same as the class name
• No return type
• It allocates memory for the instance object
• Called automatically when an instance is
  created/constructed
• If not defined an object will be created
• If defined, variables can be initialized
  according to your requirements

67
Lets simulate a box in Java
Add a constructor to the class Box
class Box double width double heightdouble
depth void CalcVol() System.out.println( width
height depth ) Box() Width
4 Height 2 Depth 3
68
Lets simulate a box in Java
Then our program?
69
Lets simulate a box in Java
Add a constructor to the class Box
How do we create our own box with our own
dimension ?
70
Lets simulate a box in Java
constructor to the class Box
class Box double width double heightdouble
depth void CalcVol() System.out.println( width
height depth) Box(double w, double h,
double d) Width w Height h
Depth d
71
Lets simulate a box in Java
Then our program?
72
Lets simulate a box in Java
Inheritance
Box
Box
There are two boxes having different colours
73
Lets simulate a box in Java
Inheritance
Box
Box
Other than dimensions the colour is changed
74
Lets simulate a box in Java
Template of the class Box
class Box double width double heightdouble
depth double CalcVol() return width height
depth Box(double w, double h, double d)
Width w Height h Depth d

75
Lets simulate a box in Java
Template of the class ColorBox
class ColorBox extends Box int
colour ColorBox(double w, double h, double d,
int c) Super(w,h,d) Color c

76
Lets simulate a box in Java
Inheritance
height width depth
w , h , d
colour
Box
c
77
Lets simulate a box in Java
Template of the class ColorBox
class ColorBox extends Box int
colour ColorBox(double w, double h, double d,
int c) Super(w,h,d) Color c

78
Lets simulate a box in Java
Then our program?
class BoxDemo public static void main(String
args) ColorBox myBox new ColorBox(2,4,5,255)
System.out.println(myBox.CalcVol())


79
Polymorphism
80
Lets simulate a box in Java
Template of the class Box
class Box double width double heightdouble
depth double CalcVol() return width height
depth Box() Box(double w, double h, double
d) Width w Height h Depth
d
81
Some URLs

•   Definition of a class
• http//java.sun.com/docs/books/tutorial/java/conce
  pts/class.html
• Creating objects
• http//java.sun.com/docs/books/tutorial/java/data/
  objectcreation.html
•   Defining methods
• http//www.cs.brown.edu/courses/cs015/2002/Referen
  ceGuides/JavaRefGuide/definemethod.html
