SEASA hur funkar det

1
SEASA - hur funkar det?
Mark Pearce KTH Fysik
SEASA _at_ Vetenskapens Hus 8 oktober 2007
2
Overview

• Part 1 How SEASA works
• Demonstration The cosmic ray telescope
• BREAK
• Part 2 SEASA data analysis

3
Cosmic ray air shower
Top of atmosphere
Short-lived
40 km
Long-lived
Stable
Ground
4
Rymden
Jordens atmosfären
Scintillatorer
5
t1 t2 t3 ?
High-schools
6
(No Transcript)
7
Enskilda
1 km
8
Detector stations

• AlbaNova Universitetscentrum
• 3 stations. 2 on main buliding, clear view of sky
  (1 station not operational). One station in the
  attic of house 1 near the bus stop.
• Enskilda gymnasium
• On balcony partial view of sky
• Nacka gymnasium
• On roof, clear view of sky
• Norra Real gymnasium
• In attic
• Thorildsplan
• In attic

9
Car ski-box
1 m
Plastic scintillator
High-voltage and signal cables
Photomultiplier
10
A Scintillator Detector
Cosmic ray muon
High voltage in
A charged particle excites electrons in the
scintillator. These return to the ground state
with the emission of fluorescence light,
typically at UV wavelengths.
Signal out
PMT
2 x 104 photons
Plastic scintillator
11
(No Transcript)
12
PhotoMultiplier Tube (PMT)
(fotomultiplikator)
Fotoelektriska effekten (1905)
Muon
Current pulse out
e-
many electrons
few electrons
13
(No Transcript)
14
(No Transcript)
15
(No Transcript)
16
(No Transcript)
17
Data Acquisition
Pressure sensor
HV out
GPS receiver
Ethernet
12V in
GPS antenna
Sensors
Embedded Linux processor
3 x PMT inputs
18
The GPS system

• 24 satellites
• 6 orbital planes
• 4 satellites per plane
• 20200 km altitude / 55o inclination

• Anywhere on the earth ?
• 4 satellites above horizon

4 satellites ? lat. / long. / height / time 1
satellite ? time (if position known)
Clinton turns off Selective Availability May
2000
19
100 MHz counter
Stop
Start
Pulse per second (PPS)
G P S
20
m
1 K
PMT
22 pF
1
-
50 R

AD8055
To PLA

2
AD8561
3
-
AD5300
From PLA
DAC
Vref
To PLA
ADC
Vref
AD7827
21
System Design
22
Cosmic Ray Telescope
23
SEASA heads into space
24

• PART 2 Data files

25
Q What is a trigger?

• A When the three scintillator detectors at a
  station each register the passage of a particle
  during a 1 microsecond (1 x 10-6 seconds) period

• t1 lt t2 lt t3
• (t3 t1) lt 1 ms

t3
t2
t1
26
Trigger (3 detectors required)
PMT 1
Trig. time 1
Coincidence gate length 1 microsecond
Coinc. window
PMT 2
Trig. time 2
ToT3
PMT 3
Trig. time 3
Time
27
Data files

• Each time a station registers a trigger, the
  electronics sends data characterising the cosmic
  ray event to the stations Linux computer (more
  about the details of this data soon)
• The event data is then sent to a computer at KTH
  where it is stored in a database
• Every so often, we produce data files from the
  information stored in the database. The data file
  will typically correspond to a period of time
  (e.g. 1 month of running).
• Each line in the data file describes a different
  trigger recorded by the station
• Each column in the data file represents a
  variable describing the trigger

28
Typical data file (each line represents a
trigger)
Offset (nanoseconds)
Station ID
Temperature (K)
Counting rates (Hz)
GPS time (seconds)
Pressure (hPa)
OBS! The files you analyse may look a little
different to this
29
How is the trigger time defined?

• The trigger time (ie the time when a trigger
  occurs) is derived from the GPS system
  (yyhhmmss)
• This allows one to compare trigger times between
  widely separated detector stations and look for
  simultaneous activity which could indicate that a
  large air shower has been created over Stockholm
• However
• The GPS time is only accurate to 1 second
• Our electronics allows the trigger time to be
  measured with 5 nanoseconds resolution within a
  given second
• The format of this time information is under
  review because Excel can only read 15 digits.
• We will change this in the files that you receive!

30
What are the counting rates?

• Each station registers a trigger approximately
  once a minute
• i.e. all three scintillators are hit within 1
  microsecond once a minute
• Each trigger corresponds to an air shower
  generated by a primary cosmic ray proton with an
  energy above approximately 1015 eV
• Since the number of shower particles hitting the
  ground depends on the primary cosmic ray energy
• Each separate scintillator is hit by secondary
  cosmic rays (mostly muons, generated by lower
  energy primaries) much more frequently about
  100 times a second (100 Hz)
• The rate of hits (number per seconds) is measured
  by the SEASA electronics
• Can be used to monitor the scintillator
  detectors, but is also sensitive to effects like
  atmospheric pressure (thinkness of atmosphere),
  and the activity of the Sun.

31
What happens now?

• Before the next meeting (22 okt), we will make
  the data files available via the SEASA homepage
• PhD student Mószi Kiss will show how to study the
  data using Excel, e.g.
• How to read the files into Excel
• How to study relationships between variables
• A basic knowledge of Excel will be expected!
• We will also give some concrete suggestions for
  project work using the data
• Mån 12/11 Data analysis, continued
• Mån 14/1 Data analysis preliminary discussion
  of results
• Mån 4/2 Presentation of results to group
