1' Telescope

1
1. Telescope
2
Enclosure Design Studies
3
(No Transcript)
4
LSST Strawman design short-tube 3.5 degree
diameter field

• Modified Paul-Baker, Willstrop Mercenne-Schmidt
  or Laux design
• 8.36 m aperture primary mirror f / 1.25
• 3.5 degree full field of view
• Three aspheric mirror design
• Primary and tertiary mirror are a continuous
  surface 4.0 cm separation between beams
• Three fused silica spherical corrector lenses
• L1 is 1.6 m diameter
• Five interchangeable fused silica filters,
  13.5-22.0 mm thick
• CCD in vacuum, L3 is vacuum barrier
• 25 mm space CCD-L3
• Vertex of secondary mirror is 1.1 m from CCD
  array
• Effective etendue 230 (m-deg)2
• including all losses obstruction and
  vignetting, coatings and detector fill

5
2. Camera
6
Shutter design

• Requirements
• Shutter fits between the filter and L3
• Aperture diameter .76m

L1
Shutter
Detector array
1.6m
Filter
L3
L2
7
Filter exchange mechanism

• New optical design
• 3.5º field of view ? optics and detector array
  are larger
• Includes shutter
• Due to space constraints, single pivot mechanism
  no longer fits

8
Filter exchange mechanism

• 4-bar linkage allows filter to move past shutter
  and fit inside the outer camera Dewar

9
Filter exchange mechanism
10
Camera optics
1600
1120.346
11
L2

• mechanical stop
• thermal barrier
• soft support
• filters

L3

• Camera integration issues
• FPA / elx assembly
• elx access

Secondary mirror
12
External services

• DC-DC converters, power conditioning, ..
• misc environmental / commercial components
• Temp controllers
• Vacuum monitors / controllers
• etc.

13
3. Focal Plane Assembly
14
Conceptual design giga-bit serial data link

• 32 channel analog signal processing (ASIC)
• CCD clock buffer bias (ASIC or discrete)

sensor
FEE

• Intermediate cable for signals, clocks, misc
  control, thermal standoff
• 90 conductors

Timing ADCs

• Features
• No digital activity (except clocks) in FEE
• Differential analog signals to ADC
• Maximal separation of ADCs digital from FEE
  sensors
• High immunity to digital/analog x-talk.

15
Conceptual design giga-bit serial data link
16
Thermal zones
Zone-1 -100 to -60 degC
Zone-2 -20 to 20 degC

• Zone-1
• Sensors Front end electronics
• High stability loop DT few 0.1s degC

• Zone-2
• Data collection, etc
• Lower stability loop DT few degC

17
4 FOV ? 74 cm ?
WFS
8/5/04 workshop CCDs 3x3
3.5 FOV ? 64 cm ?
X
X
X
X
X
X
X
X
X
X
X

• 4096x4096 pixels
• 10 µm pixels
• 1678 mm2 active
• 41.7 mm x 41.7 mm Si
• 42 mm pitch (0.3 mm gaps)
• 95 fill factor
• 25 x 3x3 225 chips
• If allow dummies outside 64cm, then?21 rafts
  with 9 live4 corners with 3 live ea
• 201 live chips total

X
X
X
X
X
X
X
X
X
X
X
X
X

• wea 8/6/04

18
FPA Structure design/FEA - Layton Hale-

• Modeling
• Deflections, gravity
• Normal modes
• Thermal
• x-y motions

19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
4. Raft
23
Focal Plane Array - Integration -
24
Focal Plane Array - Integration -
25
Focal Plane Array

• Based on Raft structures
• Multiple (e.g. 9) CCD modules on local stiff
  raft structures
• Each CCD module kinematically mounted to raft
• CCD modules adjusted by vendor (preferred) for
• Parallel
• Height
• Raft features
• Optically flat (lt 1u)
• Kinematically mounted to FPA Structure
• Raft mount adjustability
• Manual (vernier screws, )
• Actuated (Piezo, )

26
CCD Module/Raft assembly
CCD
Wire bonds
Aluminum nitride carrier/pwb
High density interconnects
Invar frame
Assembly tool holes
27
CCD Module/Raft assembly
CCD
Aluminum nitride carrier/pwb
Kinematic mounts
Invar frame
28
(No Transcript)
29
Raft assy detail
-Tim Thurston-
30
Assembly detail guide pins
-Tim Thurston-
31
FPA raft with electronics
32
Raft conceptual design - Thermal modeling -
-Tim Thurston-

• Thermal modeling in progress
• Detailed CCD module model with heat sources
• Heat removal through kinematic mounting studs
  (MIT-LL)
• Heat removal through direct strap to CCD module

33
Sloan Digital Sky Survey
34
(No Transcript)
35
(No Transcript)
36
(No Transcript)
37
(No Transcript)
38
5. CCD package
39
Mosaic Packaging
140 K plate attached to space radiator.
40
CCD Subassembly
41
(No Transcript)
42
(No Transcript)
43
CCD Module
-Tim Thurston-
44
LBNL 4-Side Buttable AlN Pattern
45
LBNL 4-Side Buttable Package
46
(No Transcript)
47
(No Transcript)
48
PanSTARRS CCID45 OTA Package Exploded View of
Package
3-point mount foot with integral pin and shim disk
Ceramic retainer clips
Moly Base
Wirebond Ceramic PGA
49
PanSTARRS CCID45 OTA Package Wirebond Ceramic PGA

• 74 pins used
• Includes temperature sensing diode
• JFETS SST309 in SOT-23 package
• Caps 0.22uF in 0603 size package
• Resistors 100K ohm in 0603 package

• Manufacturer Kyocera
• Material Alumina A440
• Multilayer 4 internal layers top ledge and
  bottom side.
• 94-pin interstitial PGA

50
PanSTARRS CCID45 OTA Package Package Design
51
PanSTARRS CCID45 OTA Package Photos of first
packaged OTA
52
PanSTARRS CCID45 OTA Package Package Dimensions
53
Focal plane power (CCD only) (For 2 sec readout
on 12 sec cadence)
54
SDSS
