2006 New Albany Shale update

1
2006 New Albany Shale update

• Bob Cluff
• The Discovery Group Inc.
• Denver, Colorado
• Presentation to IOGA Annual meeting
• Evansville, Indiana
• 2 March 2006

2
Outline

• Why the sudden buzz?
• How does the New Albany compare to other shale
  gas plays?
• Why is the action in Indiana and Kentucky instead
  of Illinois?
• Whats in this for me?

3
The Buzz

• What has changed
• Gas prices rose dramatically
• Technology advanced in the Barnett play
• Better reserves than ever expected
• Result a huge interest in resource plays built
  up in Denver, Calgary, Tulsa, Ft Worth Houston

4
(No Transcript)
5
Some conversions

• 1 BCF 1,000 MMCF 1,000,000 MCF
• 6 MCFBO on BTU basis
• Currently 5 to 7 MCF per bbl on wellhead basis
• historically closer to 8 to 101
• For back of the envelope economics, a 40 MBO oil
  well is worth about the same as a 250 MMCF gas
  well

6
Resource plays

• Tight gas sands, coal bed methane, and shale gas
  all considered resource plays
• Repeatable, predictable blanket-like
• Gas Factory model for development
• Thought to be primarily engineering driven as
  opposed to geology driven

7
Southern margin shale plays
Schlumberger, Shale Gas white paper
8
Southern PZ margin
9
Resource players

• EnCana, Devon, Chesapeake, Anadarko, Southwestern
  Energy, Vintage, others
• Shell, ExxonMobil are watching or currently
  testing the water
• BP, ConocoPhillips, Chevron appear to be
  sitting it out (for now)
• Shale gas is the hottest thing going in 2006!

10
Technology advances

• Huge water fracs
• Work in Barnett as well or better than gel fracs
• Substantially lower total cost
• Open up enormous drainage areas to well bore
• Horizontal wells
• Can now drill, steer, frac a horizontal well in
  shale shale is competent and stays open
• Almost 2X deliverability of vertical well

11
Barnett water frac

• HUGE water fracs with a light sand load
• gt1,000,000 gallons H2O 50,000 sd
• Object is not to place a conductive sand pack in
  the fracture, but rather to open up a very large
  area of natural fractures (joints)
• Sand might be acting like an abrasive to improve
  natural asperities
• Fm is so tight (nanodarcies) that ANY fracture
  will be orders of magnitude better

12
Barnett Shale- the big hitter

• Started slow, fewer than 100 wells in first 15
  years
• Late 1990s, figured out GIP was much greater
  than previously thought
• 1999 discovered water fracs
• 2002 figured out how to drill and frac
  horizontal shale wells

13
AAPG Explorer, Feb 2005
14
Barnett vs. New Albany
15
Barnettstructure
Discovery Group, 1994, Proprietary report
16
New Albanystructure
GRI-00-0068, after maps constructed in 1976-1981
by ISGS, IGS, KGS
17
Lower Barnett thickness
FW D
Discovery Group, 1994, Proprietary report
18
New Albany thickness
GRI-00-0068, after maps constructed in 1976-1981
by ISGS, IGS, KGS
19
Barnettmaturity( Ro)
Humble Geochemical www.humble-inc.com
20
New Albanymaturity( Ro)
GRI-00-0068 after Barrows Cluff, 1984
21
New Albany RhoB vs TOC
EGSP data, 1976-1979
22
Barnett Shale type curve
n 925, EUR gt 1.4 BCF
IP30 660 MCFD
23
New Albany (Corydon area)type curve
IP30 90 MCFD
24
Why so much activity on the east side of the
basin?

• Historic NAS production has all been in Indiana
  and Kentucky
• Biggest are Shrewsbury, Corydon, Laconia
• Lots of small fields in IN reef trend, e.g.
  Loogootee, with high reported gas rates
• Several small fields south of Pennyrile fault
  zone in KY

25

• Thick section of black shale in Kentucky
• High maturies to the west, approach the Barnett
  analog in places
• Extensive faulting might mean better fracturing
  higher perm
• Open acreage, reasonable terms
• Major pipelines cross the area

26
And why not Illinois?

• Shawneetown N.F. blocks out a large prospective
  area
• More problems with HBP lands shallow
  production- hard to build large blocks
• Less attractive lease terms
• Fewer shows, less encouragement from historic
  activity, only one small gas field discovered

27
2005 activity
28
New Albany reserves reserve expectations

• Corydon-Laconia 0.1 to 0.3 BCF/well
• Maple Branch unknown, probably similar to
  Corydon
• Shrewsbury unknown, but small
• Daviess Cty, IN 0.5 BCF/well??
• Union-Crittenden Cty, KY 0.6-1.0 BCF/well
• Horizontal wells are a wildcard- generally hope
  to get about 2X vertical well reserves or better

29
Whats in it for me?

• If you are in the southern part of the basin,
  youve got mature New Albany under you
• Gas is probably there in significant quantities
• Opinion the NA is fully saturated with gas
• Deliverability is the big question/risk
• Lots of historically tight tests of the shale
• Current testing not far enough along

30
What should you do?

• Adopt a wait, watch, learn approach
• Partner up with other local operators and drill a
  science well to test your area
• Objectives are to
• prove up gas content get data to map GIP
• determine fracture stress orientations for
  horizontal drilling
• test deliverablity with modern gas shale frac
• provide an economic baseline to evaluate vertical
  well performance

31
Coring program

• Full diameter core
• Lithology fracture description
• Sample on site for gas desorption
• Lab protocol includes porosity, bulk density,
  TOC, maturity, minerology, methane adsorption
  isotherms

32
Logging program

• Triple combo of resistivity, density, neutron,
  a spectral gamma ray
• Dipole sonic for stress and frac design
• Imaging logs to determine fracture density and
  orientation
• NMR other specialty logs have not proven very
  useful

33
Completion

• If you have a lot of gas in place,
• Then frac the bejeepers out of it
• (per Kent Bowker)
• Proof of concept well gives you the backup you
  will need to promote your position to a larger
  independent

34
The future

• Future of the New Albany play is still uncertain
• Deliverability reserves are unknown
• Activity in 2006 will be more big acreage plays,
  drilling completion of science wells, and
  horizontal wells to test the play
• It will probably take 50 to 100 wells before we
  really know if it will work
