Parallel Computing

1

• Parallel Computing

• Overview of Parallel Architecture
• MPI and Cluster Computing

2
Definitions

• Multicomputers Interconnected computers with
  separate address spaces. Also known as
  message-passing or distributed address-space
  computers.
• Multiprocessors Multiple processors having
  access to the same memory (shared address space
  or single address-space computers.)
• Note Some use term multiprocessor to include
  multicomputers. The definitions above have not
  gained universal acceptance

3
Flynns Taxonomy
Data Stream
Single Multiple
SISD Uniprocessors
SIMD Processor Arrays Pipelined Vector Processors
Instruction Stream
Multiple Single
MISD Systolic Arrays
MIMD Multiprocessors Multicomputers
4
SISD

• SISD
• Model of serial von Neumann machine
• Single control processor

5
SIMD

• Multiple processors executing the same program in
  lockstep
• Data that each processor sees may be different
• Single control processor issues each instruction
• Individual processors can be turned on/off at
  each cycle (masking)
• Each processor executes the same instruction

control processor
. . .
interconnect
6
MIMD

• All processors execute their own set of
  instructions
• Processors operate on separate data streams
• May have separate clocks
• IBM SPs, TMCs CM-5, Cray T3D T3E, SGI Origin,
  Tera MTA, Clusters, etc.
• MIMD are divided into
• Shared Memory Sometimes called
  Multiprocessors
• Distributed Memory Sometimes called
  Multicomputers

7
A generic parallel architecture
P
P
P
P
M
M
M
M
Interconnection Network
Memory

• Where is the memory physically located?

8
Shared Memory MIMD and Clusters of SMPs

• Since small shared memory machines (SMPs) are the
  fastest commodity machine, build a larger machine
  by connecting many of them with a network.
• Shared memory within one SMP, but message passing
  outside of an SMP.
• Processors all connected to a large shared
  memory.
• Local memory is not (usually) part of the
  hardware.
• Cost much cheaper to access data in cache than
  in main memory.

9
Distributed Memory

• This is what we have!!
• Each processor is connected to its own memory and
  cache but cannot directly access another
  processors memory.
• Each node has a network interface (NI) for all
  communication and synchronization.

10
Parallel Programming Models

• Control
• How is parallelism created?
• What orderings exist between operations?
• How do different threads of control synchronize?
• Data
• What data is private vs. shared?
• How is logically shared data accessed or
  communicated?
• Operations
• What are the atomic operations?
• Data Parallelism vs. Functional Parallelism

11
Trivial Example

• Parallel Decomposition
• Each evaluation and each partial sum is a task.
• Assign n/p numbers to each of p procs
• Each computes independent private results and
  partial sum.
• One (or all) collects the p partial sums and
  computes the global sum.
• Two Classes of Data
• Logically Shared
• The original n numbers, the global sum.
• Logically Private
• The individual function evaluations.
• What about the individual partial sums?

12
Functional Parallelism

• Parallel Decomposition
• Each processor has a different function
• Find the parallelism in this sequence of
  operations
• a ? 2
• b ? 3
• m ? (a b)/2
• s ? (a2 b2)/2
• v ? s m2

13
Multicomputer topology

• Interconnection network should provide
  connectivity, low latency, high bandwidth
• Many interconnection networks developed over
  last 2 decades
• Hypercube
• Mesh, torus
• Ring, etc.

14
Lines and Rings

• Simplest interconnection network
• Routing becomes an issue
• No direct connection between nodes

15
Mesh and Torus

• Generalization of line/ring to multiple
  dimensions
• 2D Mesh used on Intel Paragon 3D Torus used on
  Cray T3D and T3E.

16
Mesh and Torus

• Torus uses wraparound links to increase
  connectivity

17
Hop Count

• Networks can be measured by diameter
• This is the minimum number of hops that message
  must traverse for the two nodes that furthest
  apart
• Line Diameter N-1
• 2D (NxM) Mesh Diameter (N-1) (M-1)
• 2D (NxM) Torus Diameter ?N/2? ?M/2?

18
Hypercube Networks

• Dimension N Hypercube is constructed by
  connecting the corners of two N-1 hypercubes
• Interconnect for Cosmic Cube (Caltech, 1985) and
  its offshoots (Intel iPSC, nCUBE), Thinking
  Machines CM2, and others.

19
Fat-tree Interconnect

• Bandwidth is increased towards the root (but
  aggregate bandwidth decreases)
• Data network for TMCs CM-5 (a MIMD MPP)
• 4 leaf nodes, internal nodes have 2 or 4 children
• To route from leaf A to leaf B, pick random
  switch C in the least common ancestor fat node of
  A and B, take unique tree route from A to C and
  from C to B

Binary fat-tree in which all internal nodes have
two children
20
An Impractical Interconnection Topology

• Completely connected
• Every node has a direct wire connection to every
  other node
• N x (N-1)/2 Wires

21
Shared Address Space Multiprocessors

• 4 basic types of interconnection media
• Bus
• Crossbar switch
• Multistage network
• Interconnection network with distributed shared
  memory (DSM)

22
Bus architectures

• Bus acts as a party line between processors and
  shared memories
• Bus provides uniform access to shared memory (UMA
  Uniform Memory Access) (SMP symmetric
  multiprocessor
• When bus saturates, performance of system
  degrades
• Bus-based systems do not scale to more than 32
  processors Sequent Symmetry, Balance

23
Crossbar Switch

• Uses O(mn) switches to connect m processors and n
  memories with distinct paths between each
  processor/memory pair
• UMA
• Scalable performance but not cost.

24
Some Multistage Networks

• Butterfly multistage

• Shuffle multistage

25
Distributed Shared Memory (DSM)

• Rather than having all processors on one side of
  network and all memory on the other, DSM has some
  memory at each processor (or group of
  processors).
• NUMA (Non-uniform memory access)
• Example HP/Convex Exemplar (late 90s)
• 3 cycles to access data in cache
• 92 cycles for local memory (shared by 16 procs)
• 450 cycles for non-local memory

26
Message Passing vs. Shared Memory

• Message Passing
• Requires software involvement to move data
• More cumbersome to program
• More scalable
• Shared Memory
• Subtle programming and performance bugs
• Multi-tiered
• Best(?) Worst(?) of both worlds

27
Message Passing Interface,Dependencies
28
Single-Program Multiple DataSPMD

• if (my_rank ! 0)
• . . .
• else
• . . .
• We write a single program
• Portions of that program are not executed by some
  of the processors
• We can change the data that each of the
  processors uses for computation

29
Single-Program Multiple DataSPMD

• x p/num // p array size, num cluster
  size
• start myidx
• if (myid num-1)
• end p
• else
• endstartx
• for(istart iltendii1)
• //summation goes here

30
When can two statements execute in parallel?

• On one processor
• statement 1
• statement 2
• On two processors
• processor1 processor2
• statement1 statement2

31
Fundamental Assumption
Willy Zwaenepoel This is ok for completely
unsynchronized parallel execution, but it
excludes the possibility of synchronization among
processors.

• Processors execute independently no control
  over order of execution between processors

32
When can 2 statements execute in parallel?

• Possibility 1
• Processor1 Processor2
• statement1
• statement2
• Possibility 2
• Processor1 Processor2
• statement2
• statement1

33
When can 2 statements execute in parallel?
Willy Zwaenepoel It is really that if there is a
requirement that they be executed in the
sequential order, then they need to be executed
in the same order here. Maybe that is the same.

• Their order of execution must not matter!
• In other words,
• statement1 statement2
• must be equivalent to
• statement2 statement1

34
Example 1

• a 1
• b 2
• Statements can be executed in parallel.

35
Example 2

• a 1
• b a
• Statements cannot be executed in parallel
• Program modifications may make it possible.

36
Example 3

• a f(x)
• b a
• May not be wise to change the program (sequential
  execution would take longer).

37
Example 4

• b a
• a 1
• Statements cannot be executed in parallel.

38
Example 5

• a 1
• a 2
• Statements cannot be executed in parallel.

39
True dependence

• Statements S1, S2
• S2 has a true dependence on S1
• iff
• S2 reads a value written by S1

40
Anti-dependence

• Statements S1, S2.
• S2 has an anti-dependence on S1
• iff
• S2 writes a value read by S1.

41
Output Dependence

• Statements S1, S2.
• S2 has an output dependence on S1
• iff
• S2 writes a variable written by S1.

42
When can 2 statements execute in parallel?
Willy Zwaenepoel At thia point generalize to
arbitrary pieces of code, like small procedures
and explain that dependences hold there too, or
rather use the readset-writeset formalism from
the start?

• S1 and S2 can execute in parallel
• iff
• there are no dependences between S1 and S2
• true dependences
• anti-dependences
• output dependences
• Some dependences can be removed.

43
Example 6
Willy Zwaenepoel Same comment as next slide.

• Most parallelism occurs in loops.
• for(i0 ilt100 i)
• ai i
• No dependences.
• Iterations can be executed in parallel.

44
Example 7
Willy Zwaenepoel There was an issue of the
parallel processors having to have different
variables for the loop index.

• for(i0 ilt100 i)
• ai i
• bi 2i
• Iterations and statements can be executed in
  parallel.

45
Example 8
Willy Zwaenepoel There was some issue here that
there is a dependence caused by I -- addressed by
rewriting the second loop as for j.

• for(i0ilt100i) ai i
• for(i0ilt100i) bi 2i
• Iterations and loops can be executed in parallel.

46
Example 9
Willy Zwaenepoel Maybe we should introduce the
notion on a dependence on itself earlier (before
a loop is introduced). The notion of a
loop-independent dependence was never extended to
different statements within the body. It should
be.

• for(i0 ilt100 i)
• ai ai 100
• There is a dependence on itself!
• Loop is still parallelizable.

47
Example 10
Willy Zwaenepoel Same comment here on different
statements?

• for( i0 ilt100 i )
• ai f(ai-1)
• Dependence between ai and ai-1.
• Loop iterations are not parallelizable.

48
Loop-carried dependence

• A loop carried dependence is a dependence that is
  present only if the statements are part of the
  execution of a loop.
• Otherwise, we call it a loop-independent
  dependence.
• Loop-carried dependences prevent loop iteration
  parallelization.

49
Example 11

• for(i0 ilt100 i )
• for(j0 jlt100 j )
• aij f(aij-1)
• Loop-independent dependence on i.
• Loop-carried dependence on j.
• Outer loop can be parallelized, inner loop cannot.

50
Example 12
Willy Zwaenepoel Say a little more about loop
interchange, make loops with loop-carried
dependences appear on the inside of the nest, the
others on the outside.

• for( j0 jlt100 j )
• for( i0 ilt100 i )
• aij f(aij-1)
• Inner loop can be parallelized, outer loop
  cannot.
• Less desirable situation.
• Loop interchange is sometimes possible.

51
Level of loop-carried dependence

• Is the nesting depth of the loop that carries the
  dependence.
• Indicates which loops can be parallelized.

52
Be careful Example 13

• printf(a)
• printf(b)
• Statements have a hidden output dependence due to
  the output stream.

53
Be careful Example 14
Willy Zwaenepoel Also depends on what f and g
can do to x.

• a f(x)
• b g(x)
• Statements could have a hidden dependence if f
  and g update the same variable.

54
Be careful Example 15
Willy Zwaenepoel Is this the business about the
distance of a dependence in Kens book? It is
also possible to transform this to a nested loop.

• for(i0 ilt100 i)
• ai10 f(ai)
• Dependence between a10, a20,
• Dependence between a11, a21,
• Some parallel execution is possible.

55
Be careful Example 16
Willy Zwaenepoel This requires synchronization
between processors for parallel execution.Goes
against initial assumption.

• for( i1 ilt100i )
• ai
• ... ai-1
• Dependence between ai and ai-1
• Complete parallel execution impossible
• Pipelined parallel execution possible

56
Be careful Example 14

• for( i0 ilt100 i )
• ai f(aindexai)
• Cannot tell for sure.
• Parallelization depends on user knowledge of
  values in indexa.
• User can tell, compiler cannot.

57
An aside

• Parallelizing compilers analyze program
  dependences to decide parallelization.
• In parallelization by hand, user does the same
  analysis.
• Compiler more convenient and more correct
• User more powerful, can analyze more patterns.

58
To remember

• Statement order must not matter.
• Statements must not have dependences.
• Some dependences can be removed.
• Some dependences may not be obvious.

59
Parallelism First Program

• Ability to execute different parts of a program
  concurrently on different machines
• Goal shorten execution time
• There are p processes executing a program
• They have ranks 0, 1, 2, , p-1
• Each process prints out a Hello message

60
Hello World

• include "mpi.h"
• include ltstdio.hgt
• include ltmath.hgt
• int main( int argc, char argv)
• int myid, num, d
• MPI_Init(argc,argv)
• MPI_Comm_size(MPI_COMM_WORLD,num)
• MPI_Comm_rank(MPI_COMM_WORLD,myid)
• if (myid 0) printf("Hello.\n")
• printf("How many processors would you
  like?\n")
• scanf("d", d)
• if (d gt num)
• printf("number too big\n")
• MPI_Bcast(d, 1, MPI_INT, 0, MPI_COMM_WORLD)
• if (myid lt d)
• printf("Hello from Process d of
  d\n", myid, num)

61
MPI Function Calls

• include "mpi.h"
• MPI_Init(argc,argv)
• MPI_Comm_size(MPI_COMM_WORLD,num)
• MPI_Comm_rank(MPI_COMM_WORLD,myid)
• MPI_Bcast(d, 1, MPI_INT, 0, MPI_COMM_WORLD)
• // From example on page 42
• MPI_Send( . . . ) // What goes here? See Page 47
• MPI_Recv( . . . ) // What goes here? See Page 48
• MPI_Finalize()

62
MPI Data Types

• MPI_CHAR
• MPI_INT
• MPI_LONG
• MPI_FLOAT
• MPI_LONG_DOUBLE
