Visualizing Electrons in Atoms and Molecules

1
Visualizing Electronsin Atoms and Molecules
In honor of Milton P. Hanson 40 years colleague
and friend
Arlen Viste 17 April 2004
2
Visualizing Electrons in Atoms and Molecules
and in memory of Prof. Wayne P. Anderson
(1942-2003)Bloomsburg University (PA)colleague
and friend in MoleCVUEfan of Linux and GAMESS
http//facstaff.bloomu.edu/wpa/http//ed.augie.ed
u/webmo/
3
Visualizing Electrons in Atoms and Molecules
Ernst Schumacher Prof. Emeritus University of
Berne Switzerland With son and
grandson http//www.chemsoft.ch/
http//www.dcb.unibe.ch/groups/schumacher/
4
Visualizing Electrons in Atoms and Molecules
FDAFinite Difference Atomic Structure
calculations
Carbon
http//www.dcb.unibe.ch/groups/schumacher/qc/fda.h
tm
5
Visualizing Electrons in Atoms and Molecules
Carbon -- Total density r2R2 vs r1 bohr
0.5292 Å
6
Visualizing Electrons in Atoms and Molecules
Carbon -- Orbitals rR vs r
7
Visualizing Electrons in Atoms and Molecules
Orbital Summary -- Carbon nl occ E
KE lt1/rgt ltrgt 1s 2.00
-10.8710 16.5840 5.7583 0.2643 2s
2.00 -0.6769 1.8255 0.9670 1.5010
2p 2.00 -0.3555 1.4282 0.8313
1.6628 Energy Summary kinetic energy
39.6755 potential energy -77.0810
one-electron energy -51.0043 two-electron
energy 13.5987 total energy -37.4055
virial ratio -1.9428 Energy units1 Hartree
2625.5 kJ/mol 627.51 kcal/mol 27.211 eV
8
Visualizing Electrons in Atoms and Molecules
Silicon -- Total density r2R2 vs r
9
Visualizing Electrons in Atoms and Molecules
Germanium -- Total density r2R2 vs r
10
Visualizing Electrons in Atoms and Molecules
Tin -- Total density r2R2 vs r
11
Visualizing Electrons in Atoms and Molecules
Lead -- Total density r2R2 vs r
12
Visualizing Electrons in Atoms and Molecules
Uuq (Z 114) -- Total density r2R2 vs r
13
Visualizing Electrons in Atoms and Molecules
singlet CH2
http//www.chemsoft.ch/qc/pcgam.html
14
Visualizing Electrons in Atoms and Molecules
Energy units 1 Hartree 2625.5 kJ/mol 627.51
kcal/mol 27.211 eV 219470 cm-1
http//srdata.nist.gov/cccbdb/
CH2 singlet
CH2 triplet 101.5 o
B3LYP
134.1 o Herzberg 102.4 o
NIST 135.5 o ground
state Energy -39.1472226265 a.u.
Energy -39.1665909580 a.u.
15
Visualizing Electrons in Atoms and Molecules
CH2 singlet
Electron density
Electron density surfacewith electrostatic
potential
16
Visualizing Electrons in Atoms and Molecules
CH2 singlet
HOMO - 2
HOMO - 1
HOMO
17
Visualizing Electrons in Atoms and Molecules
Benzenediazonium ionC6H5N2
18
Visualizing Electrons in Atoms and Molecules
Benzenediazonium ion, C6H5N2
Electron density surface
Electron density surface withelectrostatic
potential
19
Visualizing Electrons in Atoms and Molecules
Benzenediazonium ionMolecular Orbitals
HOMO
HOMO - 1
LUMO
20
Visualizing Electrons in Atoms and Molecules
Benzenediazonium ionMolecular Orbitals
HOMO - 2
HOMO - 3
HOMO - 4
21
Visualizing Electrons in Atoms and Molecules
1 a.u. 1 Hartree 2625.5 kJ/mol 627.51
kcal/mol 27.211 eV
CH4 Energy -40.5344787375 a.u.
CH5 Energy-40.7443648344 a.u.
CH5 Energy-40.7467844215 a.u.
22
Visualizing Electrons in Atoms and Molecules
Molecular builders ArgusLab 3.1 and
4.0(Windows)free for academic use
http//www.arguslab.com/
23
Visualizing Electrons in Atoms and Molecules
Molecular builders Marvin (online demo)from
ChemAxon
http//ed.augie.edu/viste/builder/index.html
24
Visualizing Electrons in Atoms and Molecules
Molecular builders GhemicalA molecular modelling
package released under the GNU GPLLinux
http//www.uku.fi/thassine/ghemical/http//bioin
formatics.org/ghemical/http//www.vigyaancd.org/
25
Visualizing Electrons in Atoms and Molecules
Molecular builders PyMolLinux, Mac,
WindowsPyMOL is a USER-SPONSORED molecular
modeling system with an OPEN-SOURCE foundation.
PyMol builder
Jmol display
http//pymol.sourceforge.net/http//pymol.sourcef
orge.net/obtaining.htmlhttp//jmol.sourceforge.ne
t/
26
Visualizing Electrons in Atoms and Molecules
CO polarity
CO
CO electron density with mep
Dipole momentC- O
CO HOMO
mep scale
Calculated dipole moment 0.072 Debye with C-
OExpt 0.1222 D with C- O (electric resonance
molecular beam expt)Frank Jensen, Introduction
to Computational Chemistry, 1999, p. 286
Mulliken charges C 0.019 O
-0.019Löwdin charges C 0.095 O
-0.095
27
Visualizing Electrons in Atoms and Molecules
Protonation of CO
CO Energy-113.3505430503 a.u.
COH Energy -113.5205749573 a.u.
HCO Energy-113.5831658647 a.u.
1 a.u. 1 Hartree 2625.5 kJ/mol 627.51
kcal/mol 27.211 eV
28
Visualizing Electrons in Atoms and Molecules
Best wishes to Milt and Marj!
