Science applications (monitor, detect, understand and predict):

1
(No Transcript)
2
Rationales for timeseries

• Science applications (monitor, detect, understand
  and predict)
• CO2 uptake by the ocean
• biological productivity, biomass, ecosystem
  variables and fluxes
• air-sea fluxes
• thermohaline changes, water mass transformation
• rapid or episodic changes (mixed-layer, blooms,
  convection, MOC, etc)
• mass/heat transports (boundary current,
  over/throughflows, MOC)
• geophysics

• Operational applications
• reference data for forecasting systems (in-situ
  biogeochemical)
• constraints (e.g. transports) for assimilation
  runs
• detection of events
• validation of products

• Technical applications (reference/calibrate/verify
  /...)
• air-sea fluxes
• remotely sensed variables (SST, wind, color)
• sensor calibration (VOS, T/S of floats, ...)
• model statistics, physics and parameterizations
  (and their variability)
• providing sound signals for float naviation,
  acoustic tomography
• testbed for new instrumentation

3

A global ocean timeseries observatory system is
under development internationally

• Started as GOOS/CLIVAR/POGO sponsored (via
  OOPC/COOP) activity
• The system is multidisciplinary in nature,
  collecting physical, meteorological,
• chemical, biological and geophysical
  timeseries observations
• Goal is to make the data are publicly
  available as soon as received and
  quality-controlled by the owner/operator
• An International Steering Team provides
  guidance, coordination, outreach, and
• oversight for the implementation, data
  management and capacity building (18
  scientists operating sites, representing all
  ocean disciplines)
• A pilot system has been defined consisting of
  all operating sites
• and those planned to be established within 5
  years, subject to evaluation in
• terms of the qualifying criteria by the
  Science Team.

4

Definition of an ocean timeseries site in
OceanSITES

• Sustained in-situ observations at fixed
  geographic locations of ocean/climate related
• quantities at a sampling rate high enough to
  unambiguously resolve the signals of interest.
• only truly Eulerian data, i.e. no ship
  sections or underway data, no surveys with
  vessels or gliders around a site. But PRODUCTS
  derived from other systems, e.g. transport
  timeseries from ferry ADCP sections, would be
  included in data base.
• Transport sections using whatever technique
  are included in choke points and major
• boundary current systems IF based on
  Eulerian data (moorings, gliders, tomography,
  etc)
• Coastal timeseries are included when they are
  instrumented to have multidisciplinary
• impact on the global observing system and if
  they are not part of a national coastal buoy
• network.

• Any implemented site fulfilling criteria will
  become part of the system but has to deliver
• its data into the system and to demonstrate
  successful operation and value after 5 years.
• Real-time data telemetry of operational
  variables will be pursued, i.e. make effort if
• technically feasible
• Agreement to make data public in near
  real-time for real-time data or as soon as
  processed
• and post-calibrated for other data

5
VISION
a global network of observatories, coordinated
among many countries, serving many disciplines,
providing data and products freely and in
real-time...
This is a realistic goal as will be shown in the
following A number of requirements and
developments will enable
and drive a sustained/operational future for
moorings
6
Requirement 1 Routine multi-disciplinary
observations (physical,
atmospheric, biogeochemical, geophysical,
biological, tsunami)
Also zooplankton, fish, mammals...
(all existing, feasible, proposed, planned)
7
Requirement 2 Telemetry systems and
standardization
Spar buoy for high-bandwidth satellite telemetry
and power generation

• Acoustic
• mooring sensors ? buoy
• bottom sensors ? buoy
• Inductive
• - mooring sensors ? buoy
• Cables
• mooring/bottom sensors ?
  shore
• Satellite links
• Iridium, ARGOS
• high-bandwidth systems
• Glider relais
• acoustic link to mooring/ bottom sensors,
  transmission via satellite when at surface
• Standardization
• - agreed protocols (e.g.TCPIP) and hardware
  standards (signal levels, baud rate, acoustic
  encoding,etc)

(all existing, feasible, proposed, planned)
8
Requirement 3 Mooring technologies
Available now or in near future surface and
subsurface moorings, winched systems, cabled
moorings, high-latitude spar buoys, virtual
moorings, under-ice moorings,...
9
Requirement 4 Interdisciplinary and
international Coordination
International coordination is critical for
sharing resources, addressing global issues,
standardization and harmonization, attracting and
serving a user community, data management,
visibility and advocacy... ???
10
Requirement 5 Globally coordinated,
consistent, efficient data management
(strategies, technologies,
infrastructure for ocean observatories)

• Need
• data from the entirety of ocean observing
  systems should be easily available, in a single
  operation, in homogeneous formats
• metadata vocabulary independent of sensors and
  platforms and disciplines

• Solutions
• Infrastructure
• centralized global ftp servers (ARGO, GOSUD,
  Global Drifter Center,)
• distributed systems OpenDap (some major
  projects are starting )
• Catalogues (JCommOps, EDIOS)
• Syntax
• NetCDF format definitions (ARGO, OceanSITES,)
• GTS formats (DBCP, VOS, ARGO,.)
• Progress made within single projects/communities
  (ARGO, GOSUD, OceanSITES, Mersea)

11
data management (continued.)

• Challenges
• Semantics
• Is a satellite SST equivalent to an In-Situ SST
  or a Model output SST?
• Overarching solutions
• very complex to solve the problem as a whole,
  difficult to assemble all required expertises
• in one group
• explore mapping techniques between several
  standard vocabularies (MMI project)

• Plan and Vision for Timeseries
• 2 global data portals (under construction in
  OceanSITES)
• NetCDF format has been defined in consistency
  with other/prior program (e.g. ARGO) and with
  the US DMAC philosophy
• multi-disciplinary data from all (public)
  deep-ocean timeseries sites will be available
  in real-time, with single queries
• more challenging since several communities need
  to come together

12
Requirement 6 Homogeneous QC procedures
Data from a SYSTEM of moorings is only useful if
comparable/consistent within each other and with
outside data Operational users must be able to
trust consistent quality flagging/error
estimates - accepting erroneous data can
cause erroneous forecasts - rejecting
extreme but good data can lead to miss important
events in forecast
Need consistent QC procedures between single
moorings AND with other platforms

• 3 required steps for moorings anticipated
• - real time QC needed by various operational
  users required within a few hours ! Must
  be automatic (gross error tests, temporal
  coherence of the time series, consistency
  between different levels,..)
• first delayed mode step before mooring recovery
  e.g. statistical method to compare with
  historical and other data and spatial/temporal
  variability in the area ? offset/drift, error
  bars
• second delayed mode step after mooring recovery
  post-calibration, reduced uncertainty

Methods from ARGO (profiles) and GOSUD
(timeseries) are now being transferred to gliders
and moorings in MERSEA ? experience will be
brought to OceanSITES
13
Requirement 7 Sustained support
(funding, infrastructure,
organization, operation)
GEO (Group on Earth Observation)
http//earthobservations.org Achieve
comprehensive, coordinated and sustained
observations of the Earth system ? Timely,
quality long-term global information as a basis
for sound decision making. The ocean component
is a major element of GEO, and will include an
observatory/mooring network. Many countries are
committing to GEO and to setting up the GEOSS.
OceanSITES is working closely with POGO,
Ocean-United and IOC to provide input to GEO.

• GMES (Global Monitoring for Environment and
  Security) http//www.gmes.info
• A concerted European effort to build end-to-end
  system for monitoring the environment and
  increasing civil security
• make environmental and security-related
  information available
• provide enhanced or new services
• It is planned to include an organization for
  operational ocean observation, which is a natural
  home for an operational mooring activity.

NOAA and NSF
http//www.noaa.gov, www.orionprogram.org The
US NOAA Office of Global Programs is supporting a
number of sustained ocean reference stations,
with a projected growth towards a larger
contribution to a global network. NSF ORION
program is under contruction.
14
Requirement 8 Interaction with users and
definition/provision of products

• Like other sustained systems, timeseries needs
  also have to be defined by applications and users
• environmental and climate monitoring
• science needs
• modelling and forecasting (validation) ?
  reference stations
• management of natural/living resources
• hazard warning and mitigation
• ....

• Add value to data by providing products and
  indicators, e.g.
• intensity of processes (air-sea fluxes,
  critical vertical/horizontal exchanges,
  productivity,....)
• state and health of the oceanatmosphere
  (physics/climate, ecosystem, inventories,
  chemicals, populations,...)
• forecast/warning indicators (El Nino, NAO,
  blooms, pollution, earthquake,...)
• (Funds are being sought from NOAA for a
  scientific support position with this goal)

15
Status and Developments
Since JCOMM 2005 meeting in Halifax, OceanSITES
is a recognized component of global ocean
observing system being integrated under GOOS,
JCOMM, etc.
16
Outcomes of OceanSITES meeting, February 06,
Hawaii

• requesting special status wrt DBCP both action
  group and science project (since not
  operational, many differences like ship-based and
  watercolumn, no project office support, etc)

• OceanSITES Data Team met for first time and
  agreed on wide range of issues, approaches,
  architectures (more below)

• OceanSITES website was transferred to WHOI/CICOR
  and design reviewed

• OceanSITES brochure was reviewed and fine-tuned
  (available in print now)

• Clarification on what type of timeseries are
  included in OceanSITES only truly Eulerian
  ones, i.e. no ship sections or underway data, no
  surveys with vessels or gliders around a site.
  But PRODUCTS derived from other systems, e.g.
  transport timeseries from ferry ADCP sections,
  would be included in data base.

• OceanSITES involvement in Ocean-United and GEO
  agreed

17
Counting and nomenclature of sites/network
Clarify name Best is ocean reference station
observatory ocean timeseries
site Make clear when only air-sea flux
reference stations are meant.
18

•
  Tropical arrays
• Agreed to include/keep in OceanSITES format
  regardless of transitioning to DBCP (included
  Don Conlee in Steering Team for this).
• Count routine tropical arrays separately and
  shows as box.
• Include the enhanced or super sites in
  reference network counting and show as separate
  sites

19
OceanSITES Data System

• A data format has been agreed on, modelled after
  ARGO, consistent with other international and
  US efforts, NetCDF
• conventions on architecture and procedures
  established (DACs, GDACs, portals, etc)

20
OceanSITES Data System

• Coriolis/IFREMER started to be one GDAC, waiting
  to hear about a NOAA GDAC
• Sample data are flowing now from - WHOI
  air-sea flux sites - ANIMATE/MERSEA sites -
  NOAA/KEO mooring - Dickey Bermuda mooring -
  MOVE moorings - MBARI moorings (under way) -
  ship hydrography from Hawaii/Bermuda (under way)
• Plan to expand and invite others, once data
  system and format is demonstrated and
  operational
• in future, it will be a requirement to
  contribute data publicly, in order to be part of
  OceanSITES, reflected on implementation maps

21
Color coding to represent data status
22
Science Implementation
Scientific applications are driving most of the
existing sites at present
circulation
air-sea flux
biogeochemistry
23
Science drivers to occupy and sustain global
sites
24
Science drivers to occupy and sustain global
sites
25
Website
www.oceansites.org
26
Brochure now available
27

• Invitation to other projects present (IMBER,
  SOLAS, GEOTRACES, etc)
• to
• express interests and rationales for specific
  timeseries sites (existing or additional
  ones)
• cooperate on implementation, maintenance,
  operation of sites
• cooperate on data system for timeseries-type
  data

28
(No Transcript)
29
Nutrient and chlorophyll data at PAP
30
5-year internal transport timeseries from ongoing
MOVE project
31
US/NSF OOI/ORION initiative
Ambitious transformative long-term
infrastructure enabling novel research(interactiv
e communication/control to all sensors, seafloor,
moving platforms, profilers, many sensors and
disciplines, adaptable)
32
Realtime boundary current observing system under
development

• Moorings
• determine net mass transport, including eddies,
  recirculations,...
• For heat transport need
• vT dx dz
• Gliders
• provide regular upper layer T-weighting of v
  distribution in stream coordinates
• IESpressure
• when upper-layer flow and heat content is know,
  this provides lower-layer correlation of v and T.

33
Possible configuration.
34
Possible issues for JCOMM

• facilitate cooperation with other communities
  (tsunami, waves, etc)
• facilitate sharing of ships (including
  inter-agency, e.g. NOAA-UNOLS)
• facilitate sharing of infrastructure, e.g can
  ORION and NOAA contribute to upgraded PAPA or
  Peru Stratus moorings ?
• help with advocacy to GEO what do JCOMM and
  IOC do ?
• help with project office support ?

35
Thank you..
