Advanced Game Technology CMPCD3026 CMPSEM044

1
Advanced Game TechnologyCMPCD3026-CMPSEM044
Abdennour El Rhalibi Room 723 a.elrhalibi_at_livjm.ac
.uk
2
Course Details (Attempt)

• 3D Game Engines Components
• DirectX D3D, 3D Modelling and Rendering
• Meshes, Level Loading and Editing
• Terrain Rendering and LOD
• Camera Setting and Animation
• Spatial Data structure BSP and PVS
• NPC Behaviour and 3D PathFinding A, Flocking,
  Scripting
• 3D Collision Detection and Response
• Shading languages
• Game networking Issues Architecture, Protocol,
  Event Synchronisation
• Introduction to Console Programming

3
Meshes, Level Loading and Editing Lecture 3

• Abdennour El Rhalibi

4
Overview

• 3D Rendering systems
• Basic Concepts
• 3D Primitives
• Meshes
• D3D Data Structures
• Vertex Buffers (VB)
• Flexible Vertex Format (FVF)
• Loading and Editing
• Meshes
• Setting World and View
• Transforming

5
3D Rendering systems

• The modeling-rendering paradigm
• Graphics pipeline
• At the head of the pipeline, all of a model's
  vertices are declared relative to a local
  coordinate system.
• The first stage of the geometry pipeline
  transforms a model's vertices from their local
  coordinate system to a coordinate system that is
  used by all the objects in a scene.
• In the next stage, the vertices that describe
  your 3-D world are oriented with respect to a
  camera.
• The next stage is the projection transformation.
  In this part of the pipeline, objects are usually
  scaled with relation to their distance from the
  viewer in order to give the illusion of depth to
  a scene.
• In the final part of the pipeline, any vertices
  that will not be visible on the screen are
  removed. This process is called clipping. After
  clipping, the remaining vertices are scaled
  according to the viewport parameters and
  converted into screen coordinates. The resulting
  vertices - seen on the screen when the scene is
  rasterized - exist in screen space.

6
Basic Concepts

• DX uses Left Hand Coordinate System. OpenGL uses
  Right Hand Coordinate System
• Primitives are built using vertices, stored in
  vertex buffers
• Different types of primitives D3DPT_POINTLIST,
  D3DPT_LINELIST, D3DPT_LINESTRIP,
  D3DPT_TRIANGLELIST,  D3DPT_TRIANGLESTRIP, D3DPT_T
  RIANGLEFAN
• Each face has a normal associated with it.
  Normals are vectors perpendicular to the faces
  surface and point the way the face is facing
• Face normals are specified using order of
  vertices, Clock-Wise or Counter-Clock-Wise
• Faces with normal facing away from the camera are
  usually backfaced culled

7
3D Primitives

• 3-dimensional shapes can be composed of 2D
  (coplanar) primitives in space (usually
  triangles).
• Each triangle (or coplanar polygon) on a 3D shape
  is called a face.
• Smooth surfaces can be achieved by enough
  primitives and correct use of shading.

8
Different Primitives

• D3DPT_POINTLIST, D3DPT_LINELIST, D3DPT_LINESTRIP,
  D3DPT_TRIANGLELIST,  D3DPT_TRIANGLESTRIP, D3DPT_T
  RIANGLEFAN

9
Meshes

• A scene is a collection of objects or models. An
  object is represented as a triangle mesh
  approximation.
• The triangles of the mesh are the building blocks
  of the object that we are modeling.
• We use the terms all interchangeably to refer to
  the triangles of a mesh polygons, primitives and
  mesh geometry.
• Triangles are primitives, but Direct3D also
  supports line and point primitives.

10
Meshes

• Meshes are data structures that hold several
  primitives to create complex shapes
• You can associate vertices, faces, materials,
  textures, and more to a mesh
• Meshes can be created with a modeling software
  (like 3D Studio) and then exported to X file
  format and loaded

11
Polygonal Meshes

• The major way to represent objects in games and
  computer graphics.
• A bunch of triangles that together form a surface
  (mesh)
• But how to store them?
• How to draw them?
• Answer.

12
Types of Primitives
13
Rendering Primitives

• Several calls to do thisHRESULT DrawPrimitive(
  D3DPRIMITIVETYPE PrimitiveType, UINT StartVertex,
  UINT PrimitiveCount )HRESULT DrawPrimitiveUP(
  D3DPRIMITIVETYPE PrimitiveType, UINT
  PrimitiveCount, CONST void pVertexStreamZeroData,
  UINT VertexStreamZeroStride )
• Etc, etc, etc (see SD for more..)
• UP User Pointer, i.e., store your primitive
  in system memory. Works, but slow.

14
Indexed Primitives

• Learn to Share Vertices
• No indexingN triangles x 3 vertices 3N
  verticesIn a large mesh, 6 triangles store the
  same vertex! (seperately!)
• Indexing reduces to one instance of each vertex!

15
Indexed Primitives

• Now we can refer to a primitive by a list of
  indices (Index Buffer) which index into the list
  of vertices (Vertex Buffer)
• This saves memory, is faster, and cache coherent
  on the video card (to an extent)

1 2 3 4 1 4 3 4 4 3 6 7 8 9 10
16
Vertex Buffers

• Vertex buffers, represented by the
  IDirect3DVertexBuffer9 interface, are memory
  buffers that contain vertex data
• Vertex buffers can contain any vertex type -
  transformed or untransformed, lit or unlit
• The flexibility of vertex buffers make them ideal
  staging points for reusing transformed geometry
• Ex Rendering models that use multiple textures
  the geometry is transformed only once, and then
  portions of it can be rendered as needed,
  interleaved with the required texture changes
• Vertex buffer is described in terms of its
  capabilities if it can exist only in system
  memory, if it is only used for write operations,
  and the type and number of vertices it can
  contain traits described by D3DVERTEXBUFFER_DESC


17
Flexible Vertex Formats

• A flexible vertex format
• (FVF) code describes
• the contents of vertices
• stored interleaved in a
• single data stream
• struct BLENDVERTEX
• D3DXVECTOR3 v // Referenced as v0 in the vertex
  shader
• FLOAT blend1 // Referenced as v1.x in the vertex
  shader
• FLOAT blend2 // Referenced as v1.y in the vertex
  shader
• FLOAT blend3 // Referenced as v1.z in the vertex
  shader
• // v1.w 1.0 - (v1.x v1.y v1.z)
• D3DXVECTOR3 n // Referenced as v3 in the vertex
  shader
• FLOAT tu, tv // Referenced as v7 in the vertex
  shader
• define D3DFVF_BLENDVERTEX (D3DFVF_XYZB3D3DFVF_NO
  RMALD3DFVF_TEX1)

18
3DStep1 project

• The following slides introduce 3D programming
  with reference to a minimal example program
  called 3dstep1 - which
• loads a 3D object from disk
• displays the lit object on screen
• allows the user to rotate the object around the y
  axis
• Allows the user to extend the transform to rotate
  the object around the x an z axis and to
  translate in all the plans

19
Modelling and Loading
20
Rendering modes

• Can be set to solid, wire-frame or point

21
Initialise 3D world

• Any 3D world must have . . .
• Some sort of camera and viewing system
• Lighting and rendering settings
• Objects and ways of transforming them

22
Initialise 3D world

• To initialise the 3D world in D3D we have to
  specify three matrices

23
The matrices

• The world transformation matrix defines how to
  translate, scale, and rotate the geometry in the
  3-D model space.
• The view transformation matrix defines the
  position and rotation of the view. The view
  matrix is the camera for the scene.
• The projection transformation matrix defines how
  geometry is transformed from 3-D view space to
  2-D viewport space.

24
Initialise 3D world

• A D3D 3D world must have . . .
• A camera - set in D3D by setting a camera matrix
  and a perspective projection matrix
• Lighting - in D3D could be directional, point,
  spot, or ambient lighting
• Device rendering settings - fill and backface
  culling modes, depth (z) buffering
• Objects - 3D objects, created on the fly, or
  loaded from disk in the D3D .x file format (which
  you may have modelled in 3DStudio MAX)

25
D3D Z buffering

• D3D uses z (depth) buffering in order to work out
  which polygons to display on screen
• Considering what colour a particular pixel will
  be a ray is cast into the scene
• any number of polygons may be intersected by the
  ray
• the z buffer is used to determine which is
  nearest and therefore visible

26
So to Initialise the 3D world . . .

• Need to
• Turn on depth buffering
• Set rendering (fill) and backface culling modes
• create a camera matrix and set its parameters
• set the camera matrix to be the device camera
  matrix
• set the perspective projection matrix
• set the projection matrix to be the device
  projection matrix

27
Turn on depth buffering

• Two lines of code are needed to turn z buffering
  on using the DXU library

28
Back face culling

• Back face culling is used to remove surfaces that
  should be facing away from the camera
• Can be set to none, clockwise, or anticlockwise
• The orientation is calculated from the surface
  normal vector
• Whether the inside or outside surface is shown
  depends on whether the polygon vertices are
  specifies clockwise or anticlockwise

29
Back face culling

• None
• Clockwise
• Anticlockwise

30
Set Rendering (fill) and cull modes

• One function call each . . .

31
Setting up the camera matrix

• To set up camera matrix we specify
• the cameras position in space
• where the camera is looking
• and which way is up

32
Setting up the projection matrix

• Need to specify
• the field of view (how much of the scene we can
  see)
• view aspect ratio (image width height ratio)
• distance to front clipping plane
• distance to back clipping plane

33
Clipping planes
34
Effect of changing field of view
35
The world matrix

• Transformations of the world matrix will
  transform all items in the world
• Set to identity matrix - no transformation

36
Putting it all together - Initialise3DWorld
37
Camera aspect ratio

• Aspect ratio is device width/device height
• Screen is usually 640 by 480 1.333
• Wrong aspect ratio leads to image distortion
• eg rotate car with screen 400x400 and a. ratio
  1.33

38
Lights

• There are three main types of lights
• Point lights - a point in space emitting light
• Spot lights, like real spot lights
• directional lights, light that comes from a
  certain direction and exists everywhere in the
  world - doesnt occur in real life but probably
  the most useful type to use
• Also ambient light - exists everywhere in scene -
  by itself its like cartoon rendering - solid
  colour with no shading

39
Point lights

• Point lights have colour and position in space
• They give off light equally in all directions

40
Spotlights

• Spotlights have colour, position, and direction
  in which they emit light
• Light emitted from a spotlight is made up of a
  bright inner cone and a larger outer cone, with
  the light intensity diminishing between the two.
• Spotlights are affected by falloff, attenuation,
  and range.

41
Directional lights

• Directional lights have only colour and
  direction, not position.

42
Ambient light

• Background light, is modelled as a constant
• With ambient light alone, all surfaces have equal
  brightness

43
Putting it together - the InitialiseLights
function
44
Dealing with 3D objects

• In D3D objects are stored in .x files
• To load an object into your program you need to
  define a data structure to store it
• The DXUMESH struct does this for you
• You can draw the mesh with the DXUDrawMesh()
  function
• When you are finished with the mesh you should
  dispose of it with the DXUReleaseMesh() function

45
Dealing with 3D objects - code
46
Transforming an object

• We can transform an object by transforming the
  WORLD matrix
• This is easiest way to transform
• BUT it actually applies the transformation to the
  whole world
• Which is OK if we only have one object, but is
  NOT OK if we need to transform objects
  independently

47
D3DXMatrixRotationY() function

• To set up a matrix for rotation we can use
  D3DXMatrixRotationY() which we pass a pointer to
  a matrix and an angle in radians
• Then if we set the device World matrix to be a
  matrix with rotation then the world will be
  rotated
• (in the following code the DegToRad() macro
  converts from degrees to radians)

48
Putting it together - the UpdateWorld () function
49
3DStep1 - functions

• Discussion so far has described in detail three
  functions in the program
• Initialise3DWorld()
• InitialiseLights()
• UpdateWorld()
• We just need a main loop and a functions to load
  the world, render it, and release it - to
  complete the program

50
3DStep1- LoadWorld()

• This loads the car mesh, a font for writing, and
  initialises the 3D world and lighting

51
3DStep1- RenderWorld()

• Draws the mesh and string

52
3DStep1- Release World

• Release resources

53
3DStep1- WinMain()

• The Winmain() function does the D3D, windows, and
  input initialisation we have already seen and
  discussed
• It calls LoadWorld() to initialise the world
• Game loop calls updateWorld and renderWorld
• Cleans up on exit()

54
(No Transcript)
55
Summary

• You should be able to take 3Dstep1 and do various
  things like
• load up a different object
• load up two objects
• play around with the lighting parameters
• create another light
• transform the object around the other axes
• Etc
