GPGPU in Medical Imaging Applications

1
GPGPU in Medical Imaging Applications

• Kevin Gorczowski

2
Overview

• Random Walks for Interactive Organ Segmentation
  in Two and Three Dimensions
• Interactive, GPU-Based Level Sets for 3D Brain
  Tumor Segmentation
• Image Registration by a Regularized Gradient Flow
• Accelerating Popular Tomographic Reconstruction
  Algorithms on Commodity PC Graphics Hardware

3
GPUs and Medical Imaging

• Computations involving 2D and 3D images
• Already a natural fit for use of GPUs
• Often involve numerical computations
• ODEs and PDEs
• Numerical accuracy not always top priority
• Visually correct and speed most important

4
Image Segmentation

• Find the boundary or interior of a specific organ
  or structure
• Hand-tracing still a standard clinical practice
• Example use radiation cancer treatment
• Take CT scan on initial day
• Segment organ
• Use segmentation to aim radiation
• Problem organs move between days!
• Hand-tracing much too time consuming to do each
  day

5
Random Walks for Interactive Organ Segmentation
in Two and Three Dimensions (2005)

• Goal Segmentation using only small amount of
  user interaction
• User specifies seed points
• Seeds labeled according to organ/structure
• Segmentation propagates toward seed points

6
Seed and Segmentation Examples
Seeds gray Segmentations black
7
Methodology

• Unlabeled pixels (non-seeds)
• Send out random walker
• Determine probability that random walker will
  reach a labeled pixel first, ahead of all other
  labels
• Assign pixel maximum probability label

8
Random Walkers on Graph
9
Formulating Images as Weighted Graphs

• Nodes pixels
• Edges between neighboring pixels
• Edge weight function of intensity difference
  between pixel and its neighbor
• Weight function
• g pixel intensity, ß free parameter
• Able to use same ß throughout

10
Solution

• Probability of random walker reaching seed point
  same as solution to Dirichlet problem
• Partial differential equation on interior of
  region with conditions at boundary of region
• Boundary conditions at seed pixels
• 1 if seed pixel belongs to label being searched
  for
• 0 otherwise
• Computation of solution involves solving linear
  system with graph Laplacian matrix

11
(No Transcript)
12
GPU Implementation

• Linear system LX -BM must be solved for each
  seed label
• Only M, seed boundary conditions, changes
• Can use RGBA channels to solve for 4 labels
  simultaneously
• Progress of segmentation can be updated on screen

13
GPU Implementation

• L is symmetric and diagonal is determined by
  off-diagonal elements
• Can store L as size n of pixels, instead of n
  x n
• Textures are same size as original images
• Linear system solved using conjugate gradient
• Only matrix-vector product and vector
  inner-product required

14
(No Transcript)
15
Interactive, GPU-Based Level Sets for 3D Brain
Tumor Segmentation (2003)

• Uses deformable model approach
• Before, started with pixel seeds and labeled
  pixels individually
• Here, start with template model of
  organ/structure
• Deform model to fit target image
• Resulting model represents boundary

16
Deformable Models

• Two classes of deformable shape models
• Parametric
• Parameterized curves or surfaces
• Spherical harmonics, wavelets
• Geometric
• Curves as embedded, implicit level sets of
  higher-dimensional functions
• Can change topology (may or may not be advantage
  depending on application)

17
Level Sets

• Curve or surface all points such that some
  function f(x) 0
• f R3 -gt R, x position
• Can describe motion (deformation) as PDE
• v(t) pixel-wise velocities
• Implement deformations by choosing vs

18
Velocities for Segmentation

• Velocities usually have two components when used
  for segmentation
• Data term
• Smoothness term
• Data term drives curve toward boundaries
• Typically areas of high contrast in image
• Smoothness term constrains curve from becoming
  too irregular
• Prevents leaking out of small discontinuities
  in image edges

19
Leaking without Smoothness Term
20
Problems

• Data term usually introduces free parameters
• Their data term
• I image intensity
• e determines range of values considered inside
  object
• T determines how bright object is
• Basically, T is mean intensity and e is variance
• User has to choose these free parameters
• If segmentation runs at interactive speed (GPU),
  user can be much more productive

21
GPU Implementation Issues

• For stability, curve must move at most one pixel
  at each iteration
• Results in many iterations before solution
• Need to keep as much on GPU as possible
• Major speedup if only places where f is close to
  zero are considered
• How to pack for GPU
• Changes after each iteration

22
Data Packing

• Subdivide data into 16x16 tiles
• Only tiles with non-zero derivatives sent to GPU

23
Data Packing

• Evaluation of PDE requires discrete derivatives
• Pixels need to access neighbors
• CPU calculates and sends texture coordinates of
  neighbor pixels in packed format
• GPU does neighbor lookups and finite differences
  used for gradient and curvature
• CPU also sends vertices of active tiles for quad
  rendering

24
Data Packing

• CPU needs to active tiles for each iteration so
  it can calculate neighbor pixels
• GPU writes out a small (lt64KB), encoded texture
  telling which tiles are active
• Checks if a tile boundary has been crossed
• Limits CPU lt-gt GPU bus use

25
Performance

• CPU 1.7GHz Xeon
• 7-8 iterations/sec
• Highly-optimized, sparse-field, CPU-based
  solver"
• Radeon 9700 Pro
• 60-70 iteration/sec
• Running time of GPU implementation scales
  linearly with number of active voxels
• Overhead for feedback image calculation about 15
  of total GPU time

26
Results
Semi-automatic result has less discontinuities
across slices than hand-traced segmentation
27
Movies
28
Image Registration by a Regularized Gradient Flow
(2004)

• Image registration
• Try to get intensities in multiple images to
  match spatially
• Simple case use similarity transforms to align
  images as best as possible
• Complex case non-rigid registration
• Each pixel has its own displacement

29
Application Atlas Formation

• Lorenzen (UNC) created sharp mean images by
  finding mean deformation

30
Registration Formulation

• Must define a measure of how closely two images
  match
• Can formulate as an energy function

31
Registration as Optimization

• Given formulation as energy function
• Problem becomes a global optimization of an
  objective function
• Find minimum of energy function

32
Uniqueness of Solution
33
Discretization
34
Algorithm Pseudocode
35
GPU Implementation
36
Results
37
Results
38
Results
39
Results
40
Performance
41
Accelerating Popular Tomographic Reconstruction
Algorithms on Commodity Graphics Hardware

• Computed Tomography
• CT scan, used to be CAT scan
• X-ray source
• Object attenuates x-rays
• Collector (2D sheet) measures left-over radiation
• Source and collector rotate around object

42
Reconstruction

• Only information acquired through scan is 2D
  image at collector
• Have collector image for each angle f (position
  of source/collector on circle)
• Must solve for attenuation of scanned object at
  points on 3D grid

43
Formulation

• Amount of radiation collected at pixel (u,v) of
  collector for angle f
• µ attenuation (unknown)
• Q0 original x-ray energy at source
• L distance between source and collector
• Integrate attenuation along x-ray

44
Formulation

• Rewrite
• i pixel index of
• collector
• Voxel form (loop
• through object voxel
• Grid)

45
Formulation

• wij weight of voxel js contribution to
  detector pixel i
• Determined ahead of time by interpolation and
  integration rules

46
Solving for Attenuation

• Mf number of pixels in collector for angle f
• Know qi and wij, solve for attenuation
  (backprojection)

47
Final Image Reconstruction

• Feldkamp algorithm
• SART iterative
• algorithm
• OS-EM algorithm

48
GPU Implementation

• Each iteration requires at least one
  backprojection and projection
• Each backprojection is O(n3)
• No real way around complexity
• Must use brute force speed
• Many CT machines use FPGAs or ASICs
• Expensive
• Inflexible

49
GPU Implementation

• Volume data stored at stacks of textures
• Discrete form of projection and backprojection
  operations
• Updates of current volume attenuation performed
  through texture blends

50
GPU Implementation

• Can use RGBA channels to compute orthogonal
  projections
• Projection matrices are equal
• Four 90 increments of f
• Cant do this in SART because of incremental
  volume updates
• Instead, fold volume in half (RG)
• Projection matrices are same except for reflection

51
Results
52
Performance
53
References

• Leo Grady, Thomas Schiwietz, Shmuel Aharon,
  Rudiger Westermann, "Random Walks for Interactive
  Organ Segmentation in Two and Three Dimensions
  Implementation and Validation", Proceedings of
  MICCAI 2005, vol. 2, 2005, pp. 773-780.
• Aaron E. Lefohn, Joshua E. Cates and Ross T.
  Whitaker, Interactive, GPU-Based Level Sets for
  3D Segmentation, Proceedings of MICCAI 2003,
  vol. 2, 2003, pp. 564-572.
• Robert Strzodka, Marc Droske, and Martin Rumpf.
  Image Registration by a Regularized Gradient
  Flow - A Streaming Implementation in DX9 Graphics
  Hardware. Computing, 73(4)373389, 2004.
• Fang Xu, Mueller, K. Accelerating Popular
  Tomographic Reconstruction Algorithms on
  Commodity PC Graphics Hardware. IEEE
  Transactions on Nuclear Medicine. Volume 52,
  Issue 3, Part 1, June 2005. pp. 654- 663.
