Confidence in Metrology: At the National Lab

1
Confidence in MetrologyAt the National Lab
On the Shop Floor
National Research Conseil national Council
Canada de recherches

• Alan Steele, Barry Wood Rob Douglas
• National Research Council
• Ottawa, CANADA
• e-mail alan.steele_at_nrc.ca

2
Outline

• Measurements
• Communications, Comparisons
• Fluctuations, Predictions
• Confidence
• Comparisons, Proficiency Tests, on the Shop Floor
• Probability Calculus
• confidence intervals
• confidence levels
• A Toolkit for Excel
• some Visual Basic Code
• A Worked Example
• with real comparison data
• Conclusions

3
Measurement means Communication

• The sole purpose of measurement is to communicate
  an aspect of physical reality from one person,
  place and time to another person, place and
  time. or autonomous system for which a person
  is responsible

Alas, my work is all in vain If it doesnt
get to Roundheads brain

• The two people must have in common an
  understanding of the measurand a system of
  numbers and units of measurement a means for
  describing measurement accuracy

4
Measurement means Comparison

• Any useful measurement is a comparison
• The world uses the SI to provide a network that
  can inter-relate most of these comparisons
• The implied inter-relationships are checked by
  special Comparisons for Quality Assurance Shop
  floor Calibrations (with NMIs) Proficiency
  Demonstrations (with NMIs) Bilateral
  Comparisons (between NMIs) Regional
  Comparisons (among NMIs) CIPM Key Comparisons
  (among NMIs)
• At NMIs, special definition-based comparisons are
  also required for the kelvin, second, kilogram
  etc.

5
Measurement means Fluctuations

• Usually, fluctuations can be observed in a
  measurement even when we try to keep everything
  as constant as possible - WE INCLUDE THIS

• Usually, larger fluctuations are observed as
  temperature, pressure, humidity are allowed to
  vary - WE INCLUDE THIS
• Usually, we anticipate an even larger range of
  fluctuations if the measurement were to be made
  by other reasonable means - WE INCLUDE THIS IN
  STANDARD UNCERTAINTY

6
Measurement means Prediction

• The most useful aspect of a measurement is its
  predictive ability, either explicit or implicit
• The results of past comparisons are used to infer
  results for future comparisons

?

• There is a challenge to relate environmental
  conditions, history and aging to the accuracy
  ofa future comparison

7
Confidence as a Commodity

• Measurement Confidence starts with CIPM, BIPM,
  CCs, definition-based standards and realizations
• MRA, JCRB, Key Comparisons and Regional and
  Bilateral Comparisons demonstrate confidence
• Shared research and visits help develop
  Confidence in equivalence to the SI
• This system builds confidence at the National Lab
  level

8
Confidence as a Commodity

• You can buy Confidence from your NMI (NRC, NIST)
  as calibration reports and Round-robin
  proficiency tests
• You can multiply Confidence in a well-run lab
  (CLAS) or on your factory floor
• You can sell Confidence as a commodity within
  your organization, as well as to your
  organizations clients
• To market Confidence, it should be technically
  rigorous and accessible to non-statisticians

9
False Confidence

• Any technically unjustified confidence claim is
  potentially very harmful to any calibration or
  testing laboratorys reputation
• Overly strong or technically wrong confidence
  claims are potentially lethal or actionable
• Sometimes clients need protection from
  themselvesWhy do you have to measure it? I just
  want a calibration certificate for it!!
• Rigour and careful wording can avoid false
  confidence

10
Overly Complicated Confidence

• The equivalence study of eleven 10 Volt zeners
  showed a difference of Lab A - Lab B 2.73?1.91
  ppm with 230 degrees of freedom, where the ?1.91
  is the expanded uncertainty corresponding to
  approximately 95 confidence for a Student-t
  distribution with 230 degrees of freedom, k1.97
  times the pair standard uncertainty, 0.97 ppm, of
  the pair difference determined from the internal
  standard uncertainty statements of the
  measurements from the two laboratories (?1.06 ppm
  for Lab A and ?1.49 ppm for Lab B), with a
  correlation coefficient of 0.76 accounting for a
  covariance of 1.2x10-12. The external standard
  deviation was also evaluated with 21 degrees of
  freedom and gave a Birge ratio of 1.2.
• There is a very limited market for this type of
  Confidence Statement, which still requires the
  user to deal with the 2.7 ppm bias it reveals...

11
Simple Confidence Statements

• Lab A and Lab B are equivalent. Not Rigorous
• ... 10 V measurements from Lab A and Lab B can
  be expected to agree with each other within 4.3
  ppm, 19 times out of 20.Has potential

12
Improved Confidence Statements

• The Mutual Recognition Arrangement formalizes the
  Key Comparison differences as the preferred means
  for generating confidence about equivalence
• New methods are being used to transform
  comparisons into statements of confidence
  likeOn the basis of this Comparison, similar
  measurements made by Lab A and Lab B can be
  expected to agree with each other to within 4.3
  ppm, with 95 confidenceor 19 times out of
  20.
• This clearer Confidence Statement has a wider
  market

13
Communicating with your Clients

• Clarity is important to
• Users of your measurements
• Your users management and QA managers
• Your users clients
• Your management
• Your NMI can help you to communicate confidence
  clearly

14
Confidence from NMIs

• The methods used to create statements of
  confidence for Key Comparisonscan be used for
  proficiency testing done by your NMI
• Some calibration reports can also be used to
  generate this type of confidence statement,
  provided that the travel uncertainty of the
  artefact is under proper statistical control.

15
Confidence for your Clients

• The methods used to create statements of
  confidence for Key Comparisons can be used for
  proficiency testing done by you on your factory
  floor
• The statements are the simplest quantitative
  expressions about the equivalence of two
  measurement stations

16
Proficiency Testing

• Accreditation bodies routinely specify that
  proficiency testing on a regularly scheduled
  basis is a requirement for maintaining
  accreditation
• Usually the Pilot Laboratory for the comparison
  is the National Metrology Institute
• Usually the Pilot Laboratory result is taken as
  the comparison reference value, and the
  participants are initially evaluated against
  this truth
• This is a time-consuming and expensive exercise!

17
Proficiency Demonstrations

• A pilot lab measures and sends one or more
  artefacts around to be measured at other Labs
• Pilot re-measures artefact
• Pilot receives otherLabs measurements,analyzes
  them in escrow as comparisons,assigns travel
  uncertainty and prepares a report.

3
2
4
14
15
5
1
16
Pilot Lab
13
6
12
11
7
10
9
8
18
Proficiency Demonstrations

• CIPM organizes them for NMIs
• NMIs (NRC) organizes them for you
• Do you organize them for yourself ?
• Do you organize them for your clients ?

19
Proficiency Demonstrations NMIs

• A pilot NMI measures and sends one or more
  artefacts around to be measured by NMIs
• Pilot NMI re-measures the artefact
• Pilot NMI receives otherNMIs measurements,analy
  zes them in escrow as comparisons,assigns travel
  uncertainty and prepares a report,CC and CIPM
  approve report, results posted on internet.

3
2
4
14
15
NRC
5
1
16
Pilot NMI
13
6
12
11
7
10
9
8
20
Proficiency Demonstrations CLAS labs

• NRC measures and sends one or more artefacts
  around to be measured by CLAS labs
• NRC re-measures the artefact
• NRC receives CLASlabs measurements,analyzes
  them in escrow as comparisons,assigns travel
  uncertainty and prepares a report.

3
2
Your Lab
4
14
15
5
1
16
NRC
13
6
12
11
7
10
9
8
21
Proficiency Demonstrations Shop-Floor

• You measure and send one or more artefacts around
  to be measured by instruments you normally
  calibrate
• You re-measure the artefact
• You receive otherworkstations
  measurements,analyze them in escrow as
  comparisons,assign travel uncertainty and
  prepare a report.

3
2
4
14
15
5
1
16
Your Lab
13
6
12
11
7
10
9
8
22
Proficiency Demonstrations vs Calibrations

• Proficiency Demonstrations evaluate travel
  uncertainty better
• Proficiency Demonstrations evaluate everything
  affecting the best capabilities, including
  environment and operator...
• Proficiency Demonstrations can establish tighter
  equivalence
• Proficiency Demonstrations require more artefacts
  and more organization
• Proficiency Demonstrations have new statistical
  tools and toolkits available for evaluating
  comparisons

23
Comparisons

• Measurement comparisons provide the main
  experimental evidence for equivalence
• In general, all participants measure a common
  artifact and their various results are analyzed
  from a single common perspective
• The participants may be different laboratories,
  or different measurement stations on your shop
  floor

24
Key Comparisons and NMIs

• National Metrology Institutes have recently
  signed a Mutual Recognition Arrangement in
  which the validity of their Calibration and
  Measurement Capabilities is expressed
• The scientific underpinning for this arrangement
  is a series of Key Comparisons which are
  conducted at the very highest levels of metrology
• In practice, they are not much different from the
  proficiency tests already in general use among
  accredited laboratories around the world

25
Reporting Results

• A metrologist reports a result in two parts
• the mean value mL
• the uncertainty uL
• The results are plotted as data points with error
  bars

26
Uncertainty Budgets

• The ISO Guide to the Expression of Uncertainty of
  Measurement is widely used as the basis for
  formulating and publishing laboratory uncertainty
  statements regarding measurement capabilities
• Error bars are an intrinsically probabilistic
  description of our belief in what will happen
  next time based on what we have done in the past

27
Uncertainty Budgets

• Error bars are intrinsically probabilistic
• The ? standard uncertainty interval contains 68
  of the events, or 68 of the histogrammed events,
  or 68 of the probability density function, in
  physical sciences often referred to as the
  probability distribution

28
Probability Distributions

• An ISO Guide-compliant uncertainty statement
  means that the error bars represent the most
  expert opinion about the underlying normal
  (Gaussian) probability distribution
• The fancy name for working with these
  distributions is Probability Calculus
• In general, we are interested in integrals of the
  probability distribution
• Integration is only fancy addition

29
Confidence Levels

• A confidence level is what we get upon
  integrating a probability distribution over a
  given range a,b
• The fractional probability of observing a value
  between a b is the normalized integration of
  the probability distribution function in the
  range a, b
• This is just addition of all the bits of the
  function between a b

30
Confidence Intervals

• Remember a confidence level is what we get by
  integrating the distribution over a given range
  a,b
• The confidence interval is the fancy name for the
  range associated with the confidence level
• The range -1s,1s is the 68 confidence
  interval
• The range -2s,2s is the 95 confidence interval

31
Why would you want to do this?

• Lots of time and energy (and expense!) is
  invested in creating a laboratory result in a
  comparison
• Getting the maximum amount of information from a
  measurement comparison is desirable
• Youd like to show off your confidence to
  colleagues (and auditors!)
• Quantifying things is what we do as metrologists
• Your clients may want specific quantified answers
  to questions of Demonstrated Equivalence based on
  your Proficiency Testing results

32
How hard is it to do this?

• With normal distributions, the arithmetic is
  pretty easy
• You can try this for yourself and really see how
  it works
• or you can let us do it for you!
• We have generated simple expressions to help
  evaluate normal confidence levels and normal
  confidence intervals, using well known
  statistical methods developed over the last
  hundred years or so
• We have put these expressions into a Toolkit for
  Excel

33
A Toolkit for Excel

• At NRC, we have written a Quantified Demonstrated
  Equivalence Toolkit for Microsoft Excel
• The Toolkit is freely available by contacting us
  at
• qde_at_nrc.ca
• Well add you to our mailing list and send you a
  copy of the sample spreadsheet with the Toolkit,
  plus a Users Guide in .pdf format

34
Toolkit Functions and Macros

• The Toolkit contains Functions to
• calculate pair uncertainties (including
  correlations)
• calculate weighted averages
• calculate confidence levels
• calculate confidence intervals
• The Toolkit contains Macros to
• generate bilateral tables of equivalence
• generate bilateral tables of confidence
  intervals
• generate bilateral tables of confidence levels

35
Toolkit Philosophy and Operation

• Functions and Macros are built right in to the
  Spreadsheet, and work just like regular Excel
  components

36
Toolkit Philosophy and Operation

• The code is written in Visual Basic
• You can examine the code to see how it works
• Long variableNames help to self document the
  programs
• You dont have to look at the code or write your
  own functions to use the QDE Toolkit from NRC

37
A Worked Example

• 13 Laboratories participated in a Proficiency
  Test at 10 kW

38
Comparison to the NMI En

• One common measure of success in Proficiency
  Tests is the Normalized Error
• This is the ratio of the laboratory deviation to
  the expanded uncertainty
• En(k2) abs(mLab - mRef)/sqrt(ULab2 URef2)
• Generally, the Laboratory passes when En lt 1

• En is a dimensionless quantity

39
Comparison to the NMI QDC

• A quantified approach to Proficiency Tests is to
  ask the following question
• What is the probability that a repeat comparison
  would yield results such that Lab 1s 95
  uncertainty interval encompasses the Pilot Lab
  value?
• We call this Quantified Demonstrated Confidence

• QDC is a dimensionless quantity expressed in

40
Comparison to the NMI En vs QDC

• and
  are
  both dimensionless quantities
• En and its interpretation as an acceptance
  criterion are difficult to explain to
  non-metrologists
• QDC and its numerical value are easily explained
  to non-metrologists
• Note that when En 1 (and URef ltlt ULab) QDC 50

Normalized Error
Quantified Demonstrated Confidence
41
Comparison to the NMI QDE0.95

• A different quantified approach to Proficiency
  Tests is to ask the following question
• Within what confidence interval can I expect the
  Lab 1 value and the Pilot Lab value to agree,
  with a 95 confidence level?
• We call this Quantified Demonstrated Equivalence

• QDE0.95 is a dimensioned quantity, same units as V

42
Comparison between Labs Agreement

• We can ask similar questions about agreement
  between any two participants in the experiment
• Within what confidence interval (in ppm) can I
  expect the Lab 1 value and the Lab 2 value to
  agree, with a 95 confidence level?

43
Comparison between Labs Confidence

• What if we ask
• What is the probability that a repeat comparison
  would yield results such that Lab 1s 95
  uncertainty interval encompasses Lab 2s value?
• Or how about
• What is the probability that a repeat comparison
  would yield results such that Lab 2s 95
  uncertainty interval encompasses Lab 1s value?

44
Comparison between Labs Confidence

• The answers to these questions of Quantified
  Demonstrated Confidence are shown here

45
Quantifying Equivalence

• What is the probability that a repeat comparison
  would have a Lab 2 value within Lab 1s 95
  uncertainty interval?

Probability Calculus tells us the answer
QDC 47
95 interval

• This is exactly the type of awkward question
  that a Client might ask!

46
Quantifying Equivalence

• What is the probability that a repeat comparison
  would have a Lab 1 value within Lab 2s 95
  uncertainty interval?

Probability Calculus tells us the answer
QDC 22
95 interval

• These subtly different awkward questions have
  very different straightforward answers!

47
Tricky things about Equivalence

• Equivalence is not transitive
• Lab 1 and Lab 2 may both be equivalent to the
  Pilot, but not to each other!
• Equivalence is not commutative
• we are asking two very different questions here!

48
Conclusions

• You are already doing quite a bit of Probability
  Calculus when you present your results
• The arithmetic for quantified calculations is
  very straightforward when we have Normal
  Distributions
• Adding Statistical Confidence explicitly into
  your Labs results helps you to explain them to
  non-metrologists, and to present precisely what
  Proficiency Testing has demonstrated for
• equivalence from different National Laboratories
• accreditation assessment
• your clients
• your factory floor

49
A Toolkit for Excel

• At NRC, we have written a Quantified Demonstrated
  Equivalence Toolkit for Microsoft Excel
• The Toolkit is freely available by contacting us
  at
• qde_at_nrc.ca
• Well add you to our mailing list and send you a
  copy of the sample spreadsheet with the Toolkit,
  plus a Users Guide in .pdf format
