Batch Rekeying for Secure Group Communications

1
Batch Rekeying for Secure Group Communications

• By X.S. Li, Y.R. Yang, M.G. Gouda, and S.S.Lam
• presented by Lori Flynn

2
Motivation

• Secure group communications is important Internet
  design issue for profitable applications and
  privacy of communications.
• Messages made secure using keys, making rekeying
  efficient is important.

3
Motivation

• When nodes leave the group, the privacy of future
  messages must be assured by rekeying
• When nodes join the group, the privacy of
  previous messages must be assured by rekeying

4
Motivation

• Problems with individual rekeying
• inefficiency
• out-of-sync problem between keys and data
• This paper proposes solutions to these problems.

5
Rekeying

• Straightforward rekeying requires 2 encryptions
  for a join and N-1 encryptions for a leave
• Join new group key sent to members via multicast
  (using the previous group key) and via unicast to
  new member (encrypted using its individual key)

6
Rekeying

• Straightforward rekeying requires 2 encryptions
  for a join and N-1 encryptions for a leave
• Leave previous group key cannot be used (or it
  would compromise future communications) so the
  new group key must be encrypted with each
  individual key.

7
Rekeying

• Straightforward rekeying requires 2 encryptions
  for a join and N-1 encryptions for a leave
• More scalable rekeying uses a key graph approach.

8
Key Graph

• Nodes are each given multiple keys.
• For a single leave request, key tree reduces
  server processing cost to O(log N)

9
(No Transcript)
10
Key Tree Costs

• Join 2 log_d(N)
• Leave d log_d(N) -1

11
(No Transcript)
12
Key Star rekeying cost

• Join 2
• Leave N-1

13
Key Star u4 leaves
14
(No Transcript)
15
(No Transcript)
16
(No Transcript)
17
Batch Rekeying

• Wait an interval, then the key server processes
  all joins and leaves at once
• Leave positions cant be controlled, but joins
  can be placed optimally in the key tree.

18
(No Transcript)
19
Key Stars batch rekeying server cost
20
Key Tree Rekeying Cost
21
(No Transcript)
22
Example (fig. 6) u4 and u9 leave, u10 joins.
23
(No Transcript)
24
(No Transcript)
25
(No Transcript)
26
(No Transcript)
27
(No Transcript)
28
(No Transcript)
29
(No Transcript)
30
(case 1 continued, JL)
31
(No Transcript)
32
(No Transcript)
33
(No Transcript)
34
N1024, d 2
N4096, d4
Leaves
Leaves
Joins
Joins
35
(No Transcript)
36
Case 1 J L
37
Case 2 J lt L
38
Case 3 J gt L and L 0
39
Case 4 J gt L and L gt 0
40
Rekeying batch vs. individual with key star
41
Key Tree batch rekeying costs
42
N4096, d4
N1024, d2
L
L
J
J
43
N4096, d 4
N1024, d2
44
N4096, d4
N1024, d2
L
L
J
J
45
N4096, d4
N1024, d2
L
Joins
Joins
46
N4096
N1024
J
J
47
N1024, JL
N4096, JL
L
L
48
N4096, J0
N1024, J0
L
L
49
N4096
N1024
D4 better than d2,32
D4 better than d2,8,16
J
J
50
(No Transcript)
51
Contribution

• Concept of periodic batch rekeying which can
  improve efficiency and alleviate out-of-sync
  problem
• Marking algorithm to process batch of join/leave
  requests
• Analysis of key servers processing cost for
  rekeying which shows substantial savings.

52
Contribution (contd)

• Show that when number of requests in a batch is
  not large, best tree degree is four. Otherwise,
  key star is best.

53
Conclusion

• Two problems were identified with rekeying
• inefficiency
• out-of-sync problems
• Periodic batch rekeying improves the key servers
  performance substantially
• The marking algorithm is efficient

54
Conclusion(contd)

• When number of requests is not large in a batch,
  four is the best tree degree. Otherwise, tree
  star is better.

55
Thats all.

• Questions?
