Mt' Princeton Geothermal LLC

1
Mt. Princeton Geothermal LLC

• Colorado Rural Electric Operations and
  Engineering Conference
• Mt. Princeton Hot Springs
• 8 April 2009
• Frederick B. Henderson III, Ph.D.
• Chief Scientist, Mt. Princeton Geothermal LLC

2
Mt. Princeton Geothermal LLC

• Geothermal Energy Types
• Geothermal Heat Pumps Shallow
• Hydrothermal, Direct Use - Intermediate
• Hydrothermal, Electricity Intermediate
• Engineered Geothermal (Energy) Systems - Deep

3
Baseline Geothermal Electricity

• Why Geothermal Energy Now?
• Only baseline alternative energy
• 24/7 on off
• No air or water pollution
• No storage requirement
• Upfront cost no fuel supply required
• In many US Co-op back yards

4
Mt. Princeton Geothermal LLC

• Mt. Princeton Geothermal Project
• First Geothermal Electricity in Colorado
• Stages
• I. Geology, Geophysics, Land Leasing
• Permitting - 2008
• II. Thermal Gradient Drilling Targeting -
  2009
• III. Deep Slim Hole Drilling Pump Tests -
  2009
• IV. Production Injection Drilling and Plant
  Development - 2010

5
Mt. Princeton Geothermal LLC

• Regulatory and Permitting
• Thermal Gradient Drilling
• Public meeting and permits DONE
• Exploration Well Exploratory Drilling
• Need Public meetings and permits
• Production and Injection Well Drilling
• Need Public meetings and permits
• Plant and Well Piping Development
• Need Public meetings and permits
• Final Permitting County Planning
  Commissioners

6
(No Transcript)
7
(No Transcript)
8
TOPOGRAPHY Upper Arkansas River Basin
Study Area
Buena Vista
Salida
N
San Luis Valley
Source USGS Seamless In ArcGIS database
9
Hot Springs
N
Hot Springs

• Occur Along the Range Front Fault
• Appear at Offset Zones
• Altered Quartz Monzonite
• Temperatures Vary
• 40-82 ºC
• Unique Geochemistry

Mosquito Range
Sawatch Range
J. Dimick, 2007
10 km
http//earth.google.com
10
Mt. Princeton Geothermal LLC

• Chaffee County Geothermal
• Potential Order of Energy Potential
• Mt. Princeton HS Highest T and HF
• Cottonwood HS 2nd High Heat, HF?
• Poncha Springs HS 3rd High Heat HF?
• Hecla Junction Warm Springs Warm
• HF ? HF Heat Flow

11
Mt. Princeton Geothermal LLC

• Primary Target
• Deep (2,000 3,000) Fracture Reservoir
• Prove sustainable flow of 15,000 gpm for 10 MW
  production
• Deep target for
• 1) hotter temperature 250F
• 2) Prove no surface water table impact

12
Mt. Princeton Hot Springs Well Log Study

13
GENERALIZED GEOTHERMAL SYSTEM
Hot Springs
PERMEABLE BEDS
IMPERMEABLE BEDS
ALTERED / MINERALIZED
CRYSTALLINE ROCKS
FRACTURE ZONE
COLD WATER FLOW
HOT WATER FLOW
HEAT SOURCE
14
GIS Database Based on Chaffee County GIS
database D. Reimer
BUENA VISTA
A
N
Gravity Points
1 Mile
2006 LINE
PROPOSED 2009 LINE
A
SP Resistivity
Mt Princeton H.S.
2008 LINE
Gravity Points
2005 LINE
15
A
A
Mt Princeton Hot Springs
Trout Creek
Maxwell Park
HYDROTHERMAL SYSTEM
HEAT SOURCE
LITHOLOGY
STRUCTURE
Fault with Inferred Motion
Fractures
16
Total field magnetic intensity vs distance along
2008 CSM seismic line
MPHS
17
North Line Gravity
(Dots only!)
High
Low
18
SP Response Contours and ArcGis Elevation and
Roads Map
Silica Precipitation causes plugging.
UTM, northing
Orientation of Fracture
UTM, easting
mV
19
Low Resolution SP Response
Deer Valley Ranch
20
Where to drill?

• Fault Maps after
• Cleaning up the lines

Chalk Cliffs
Drill Location
21

• Add SP DC
• Fault Maps after
• Self Potential
• Resistivity

22
Mt. Princeton Geothermal LLC

• Stage II Thermal Gradient Drilling
• ? Description and Goal
• ? Thermal gradients and Heat Flow
• ? State heat flow map
• ? AMAX 1973-5 heat flow drilling
• ? Plans for 2009
• ? Permitting
• ? Estimated Cost 100,000

23
Baseline Geothermal Electricity

• Thermal Gradient (degrees/distance)?
• X Rock Heat Conductivity
• Heat Flow
• (in mW/m²)?

24
(No Transcript)
25
(No Transcript)
26
AMAX WELLS
AMAX WELLS
27
Mt. Princeton Geothermal LLC
28
Mt. Princeton Geothermal LLC

• Future Plans and New Technologies
• ? General Plan
• ? Fall 2008 Additional geophysics
• as needed (CSM Proposal) 150,000
• Thermal Gradient Drilling 150,000
• ? Spring Summer 2009 Initial
• deep reservoir drilling 2-4 Million
• ? Fall 2009 2010 Additional production
  and
• re-injection drilling 5 Million
• Surface plant development 30-40 Million

29
(No Transcript)
30
Mt. Princeton Geothermal LLC

• Geothermal Hot Spring Energy
• The perfect exploration storm
• Exploration I Hot springs transmission lines
• Exploration II Geology thermal gradient ID
• Deep drilling PUC allowed utility development
  funding Extended Tax Credits PPPAs
• New technology UTC-type mid Theat systems
• New markets Utility required profile standards
  20 alternative energy by 2020 11.5 years

31
(No Transcript)
32
Baseline Geothermal Electricity

• Shallow Temperature Survey (STS)
• Mt. Princeton Geothermal LLC is working with GEO,
  CSM and CGS to develop a STS system in the Mt.
  Princeton-Chaffee County area in order to do a
  state wide first cut of hot springs prospects for
  large thermal indication of producible deep
  targets. Development costs 55,000

33
(No Transcript)
34
Mt. Princeton Geothermal LLC OPPORTUNITIES FOR
INVESTMENT
