Chapter 8.5 AUTHENTICATION AND KEY DISTRIBUTION

1
Chapter 8.5 AUTHENTICATION AND KEY DISTRIBUTION

• Prepared by
• Karthik V Puttaparthi
• kputtaparthi1_at_student.gs
  u.edu

2
OUTLINE

• Overview
• Protocols and Communication Services
• Design of Authentication Protocols
• Needham-Schroeder Protocol
• Denning-Sacco Protocol
• Kerberos Protocol
• Kerberos Protocol Version V
• References

3
PROTOCOLS AND COMMUNICATION SERVICES

• Authentication is the process of verifying the
  identity of an object entity.
• Password verification is a simple example of
  one-way user identification.
• In a distributed environment, there is a greater
  need to authenticate the machine the user
  connects to as well.
• This type of mutual authentication is even more
  important for communication between autonomous
  principals under different administrative
  authorities in a client/server distributed
  environment.

4
PROTOCOLS AND COMMUNICATION SERVICES

• Messages being exchanged must also be
  authenticated such that they are free of forgery,
  counterfeiting and repudiation.
• Forgery could occur when a communication key is
  compromised.
• A counterfeit is the replay of a secret message
  in the context of communication.
• Repudiation is the denial of sending what seems
  to be an authenticated message.

5
PROTOCOLS AND COMMUNICATION SERVICES

• For message authenticity, an irreproducible
  secret message digest can be used to sign the
  message.
• Secrecy of information can be accomplished by
  encryption using secret keys.

6
Design of Authentication Protocols

• Connection
  Connectionless
• Peer processes
• Client / Server
• Authentication protocols are all about
  distribution and management of secret keys.
• Key distribution in a distributed environment is
  an implementation of distributed authentication
  protocols.

Interactive One-way
Session Request / Response
7
Design of Authentication Protocols

• Design of distributed authentication protocols
  depends on underlying communication service, i.e.
  connectionless or connection-oriented.
• Most distributed applications follow
  Client/Server programming paradigm and
  Client/Server interaction is viewed as request /
  reply communication.
• Session key can also be used for Client / Server
  communication. Conceptually similar with
  tickets.
• A ticket is a signed certificate that contains
  information for authenticating the client.
• Kerberos Protocol was the first one to use the
  ticket notion.

8
Design of Authentication Protocols

• All protocols assume that some secret information
  is held initially by each principal.
• Authentication is achieved by one principal
  demonstrating the other that it holds that secret
  information.
• All protocols assume that system environment is
  very insecure and is open for attack.

9
Design of Authentication Protocols

• Message received by a principal must have its
  origin authenticity, integrity and freshness
  verified.
• To achieve these goals, most protocols need to
  rely on an authentication server.
• Authentication server delivers good quality
  session keys to requesting principals securely.

10
Design of Authentication Protocols

• Protocol are divided into two categories to
  verify the freshness of a message.
• First category uses nonce and challenge/ response
  handshake to verify freshness.
• Second category uses timestamps and assumes that
  all machines in distributed system are
  clock-synchronized.

11
Needham-Schroeder Protocol (1978)

• First to use the encryption techniques for
  authentication and key distribution.
• Five Steps
• A-gtS A, B, Na
• S-gtA Na, B, Kab, A, KabKbsKas
• A-gtB A, KabKbs
• B-gtA NbKab
• A-gtB Nb - 1Kab
• A contacts S which returns a session key and
  certificate encrypted with Kbs.
• B decrypts it and does a nonce handshake with A
  assure the freshness.
• Subtracting 1 from Nb in last message ensures
  that its not a replay of the previous message
  from B to A.

12
Needham-Schroeder Protocol (1978)

• Five Steps
• A-gtS A, B, Na
• S-gtA Na, B, Kab, A, KabKbsKas
• A-gtB A, KabKbs
• B-gtA NbKab
• A-gtB Nb - 1Kab
• Denning and Sacco found a drawback.
• If session key between A and B is compromised, an
  intruder can impersonate A by carrying out last 3
  steps.
• Needham-Schroeder responded by requiring A to
  obtain another nonce from B before it contacts S
  and requiring S to put this nonce into
  certificate to be forwarded to B.

13
Denning-Sacco Protocol (1981)

• Uses timestamps rather than nonce to guarantee
  message freshness.
• A-gtS A, B
• S-gtA B, Kab,TsA, Kab, TsKbsKas
• A-gtB A, Kab, TsKbs
• A and B can verify the message freshness by
  checking
• Clock T lt ?t1 ?t2

14
Denning-Sacco Protocol (1981)

• Clock is the local clock time. ?t1 is normal
  discrepancy between servers clock and local
  clock. ?t2 is expected network delay.
• So long ?t1 ?t2 is less than the interval
  between two contiguous authentication sessions,
  message freshness is guaranteed.
• Denning-Sacco has better performance than
  Needham-Schroeder as it eliminates message
  handshake.
• But drawback is that all machines must be
  clock-synchronized with authentication server.

15
Kerberos Protocol (1980)

• As a part of project Athena at MIT, Kerberos is
  one of the most promising implementation of
  authentication service.
• Based on Needham-Schroeder but also uses
  timestamps suggested by Denning-Sacco.
• Authentication service is divided on two servers
  Kerberos Server and Ticket Granting Server (TGS).

16
Kerberos Protocol (1980)

• Simplified version of Kerberos that treats
  Kerberos server and TGS as single entity S.
• 1. A-gtS A, B
• 2. S-gtA Kab, TicketabKas
• Where Ticketab B, A, addr, Ts, L, KabKbs
• 3. A-gtB Authenticatorab, Ticketab
• Where Authenticatorab A, addr, TaKab
• 4. B-gtA Ta 1Kab
• A sends its own identity to S before it connect
  to B.
• S responds with session key Kab and a ticket for
  B.

17
Kerberos Protocol (1980)

• 1. A-gtS A, B
• 2. S-gtA Kab, TicketabKas
• Where Ticketab B, A, addr, Ts, L, KabKbs
• 3. A-gtB Authenticatorab, Ticketab
• Where Authenticatorab A, addr, TaKab
• 4. B-gtA Ta 1Kab
• Ticket contains identities of B and A, IP of A,
  timestamp Ts, lifetime L and a session key to
  identify A.
• A now creates its own authenticator containing
  As identity, its IP and timestamp and sends it
  to B along with the Bs ticket.
• B decrypts the ticket and authenticator, and
  compares two pieces of information.

18
Kerberos Protocol (1980)

• First, their identity and address information
  must match.
• Second, discrepancy between time in authenticator
  and current local time must not exceed a
  predetermined value.
• If these match, B authenticates the As identity
  and allows the service request to proceed.
• Drawbacks of Kerberos were identified by Bellovin
  and Merritt.
• Drawback includes difficulty in adapting to all
  environments, and the need for special purpose
  hardware.
• To fix some of these problems, Kerberos has been
  upgraded to version V.

19
Kerberos Protocol Version V
1993
Authentication Server Ticket Granting Server
1 Client 2 3 4
Server 5
K
C
S
G
C-gtK C, G, N K-gtC Kcg, NKc, Ticketcg C-gtG Authenticatorcg, Ticketcg G-gtC Kcs, NKcg, Ticketcs C-gtS Authenticatorcs, Ticketcs
20
Kerberos Protocol Version V (cont)

• This protocol separates the authentication server
  S into Kerberos server (K) for authentication and
  Ticket Granting Server (G).
• Client (C) first sends identity for itself and
  TGS to Authentication Server K. (Message 1)
• Authentication Server K does the initial login
  and grants ticket for TGS. (Message 2)
• Client (C) sends authenticator to TGS to identify
  itself (like simplified Kerberos). (Message 3)

21
Kerberos Protocol Version V
1993

• Message 4 and 5 are similar to Message 2 and 3
  respectively.
• Most widely implemented protocol.
• Implemented in Distributed Computing Environment
  (DCE) security service and SESAME (A Secure
  European System for Application in a Multi-vendor
  Environment).

22
References

• Distributed Operating Systems and Algorithms by
  Randy Chow and Theodore Johnson
• On the design of authentication protocols for
  third generation ieeexplore.ieee.org/iel5/8635/273
  71/01217358.pdf
• Clifford Neumann. The Kerberos Network
  Authentication Service (V5). Internet Draft
  ietf-cat-kerb-kerberos-revision-04.txt, June 1999
• http//en.wikipedia.org/wiki/Needham-Schroeder
  March 29, 2007
• http//web.mit.edu/Kerberos/ April 2, 2007
• http//en.wikipedia.org/wiki/Kerberos_28protocol
  29 April 8, 2007
