Combinatorial and algebraic tools for multigrid

1
Combinatorial and algebraic tools for multigrid
Yiannis Koutis Computer Science
Department Carnegie Mellon University
2
multilevel methods

• www.mgnet.org
• 3500 citations
• 25 free software packages
• 10 special conferences since 1983
• Algorithms not always working
• Limited theoretical understanding

3
multilevel methods our goals

• provide theoretical understanding
• solve multilevel design problems
• small changes in current software
• study structure of eigenspaces of Laplacians
• extensions for multilevel eigensolvers

4
Overview

• Quick definitions
• Subgraph preconditioners
• Support graph preconditioners
• Algebraic expressions
• Low frequency eigenvectors and good partitionings
• Multigrid introduction and current state
• Multigrid Our contributions

5
quick definitions

• Given a graph G, with weights wij
• Laplacian A(i,j) -wij, row sums 0
• Normalized Laplacian
• ?(A,B) is a measure of how well B approximates A
  (and vice-versa)

6
linear systems preconditioning

• Goal Solve Ax b via an iterative method
• A is a Laplacian of size n with m edges.
  Complexity depends on ?(A,I) and m
• Solution Solve B-1Ax B-1b
• Bzy must be easily solvable
• ?(A,B) is small
• B is the preconditioner

7
Overview

• Quick definitions
• Subgraph preconditioners
• Support graph preconditioners
• Algebraic expressions
• Low frequency eigenvectors and good partitionings
• Multigrid introduction and current state
• Multigrid Our contributions

8
combinatorial preconditionersthe Vaidya thread

• B is a sparse subgraph of A, possibly with
  additional edges
• Solving Bzy is performed as follows
• Gaussian elimination on degree 2 nodes of B
• A new system must be solved
• Recursively call the same algorithm on to get
  an approximate solution.

9
combinatorial preconditionersthe Vaidya thread

• Graph Sparsification Spielman, Teng
• Low stretch trees Elkin, Emek, Spielman, Teng
• Near optimal O(m poly( log n)) complexity

10
combinatorial preconditionersthe Vaidya thread

• Graph Sparsification Spielman, Teng
• Low stretch trees Elkin, Emek, Spielman, Teng
• Near optimal O(m poly( log n)) complexity
• Focus on constructing a good B
• ?(A,B) is well understood B is sparser than A
• B can look complicated even for simple graphs A

11
Overview

• Quick definitions
• Subgraph preconditioners
• Support graph preconditioners
• Algebraic expressions
• Low frequency eigenvectors and good partitionings
• Multigrid introduction and current state
• Multigrid Our contributions

12
combinatorial preconditionersthe Gremban -
Miller thread

• the support graph S is bigger than A

13
combinatorial preconditionersthe Gremban -
Miller thread

• the support graph S is bigger than A

1
2
3
1
2
2
1
1
1
Quotient
2
2
3
1
1
3
3
4
4
3
4
3
2
1
1
1
2
3
1
2
2
1
1
14
combinatorial preconditionersthe Gremban -
Miller thread

• The preconditioner S is often a natural graph
• S inherits the sparsity properties of A
• S is equivalent to a dense graph B of size equal
  to that of A ?(A,S) ?(A,B)

• Analysis of ?(A,S) made easy by work of
• Maggs, Miller, Ravi, Woo, Parekh
• Existence of good S by work of Racke

15
Overview

• Quick definitions
• Subgraph preconditioners
• Support graph preconditioners
• Algebraic expressions
• Low frequency eigenvectors and good partitionings
• Multigrid introduction and current state
• Multigrid Our contributions
• Other results

16
algebraic expressions

• Suppose we are given m clusters in A
• R(i,j) 1 if the jth cluster contains node i
• R is n x m
• Quotient
• R is the clustering matrix

17
algebraic expressions

• The inverse preconditioner
• The normalized version
• RT D1/2 is the weighted clustering matrix

18
Overview

• Quick definitions
• Subgraph preconditioners
• Support graph preconditioners
• Algebraic expressions
• Low frequency eigenvectors and good partitionings
• Multigrid introduction and current state
• Multigrid Our contributions
• Other results

19
good partitions and low frequency invariant
subspaces

• Suppose the graph A has a good clustering defined
  by the clustering matrix R
• Let
• Let y be any vector such that

20
good partitions and low frequency invariant
subspaces

• Suppose the graph A has a good clustering defined
  by the clustering matrix R
• Let
• Let y be any vector such that
• Theorem
• The inequality is tight up to a constant for
  certain graphs

21
good partitions and low frequency invariant
subspaces

• Let y be any vector such that
• Let x be mostly a linear combination of
  eigenvectors corresponding to eigenvalues close
  to ?
• Theorem
• Prove
  ?
• We can find random vector x and check the
  distance to the closest y

22
Overview

• Quick definitions
• Subgraph preconditioners
• Support graph preconditioners
• Algebraic expressions
• Low frequency eigenvectors and good partitionings
• Multigrid introduction and current state
• Multigrid Our contributions

23
multigrid short introduction

• General class of algorithms
• Richardson iteration
• High frequency components are reduced

24
initial and smoothed error
initial error smoothed error

25
the basic multigrid algorithm

• Define a smaller graph Q
• Define a projection operator Rproject
• Define a lift operator Rlift

1. Apply t rounds of smoothing
2. Take the residual r b-Axold
3. Solve Qz Rprojectr
4. Form new iterate xnew xold Rlift z
5. Apply t rounds of smoothing

26
algebraic multigrid (AMG)

• Goals The range of Rproject must approximate the
  unreduced error very well. The error not reduced
  by smoothing must be reduced by the smaller
  grid.

27
algebraic multigrid (AMG)

• Goals The range of Rproject must approximate the
  unreduced error very well. The error not reduced
  by smoothing must be reduced in the smaller
  grid.
• Jacobi iteration
• or scaled Richardson
• Find a clustering
• Rproject (Rlift)T
• Q RprojectT A Rproject

28
algebraic multigrid (AMG)

• Goals The range of Rproject must approximate the
  unreduced error very well. The error not reduced
  by smoothing must be reduced in the smaller
  grid.
• Jacobi iteration
• or scaled Richardson
• Find a clustering heuristic
• Rproject (Rlift)T heuristic
• Q RprojectT A Rproject

29
two level analysis

• Analyze the maximum eigenvalue of
• where
• The matrix T1 eliminates the error in
• A low frequency eigenvector has a significant
  component in

30
two level analysis

• Starting hypothesis Let X be the subspace
  corresponding to eigenvalues smaller than ? . Let
  Y be the null space of Rproject.
  Assume, ltX,Ygt2 ?/?
• Two level convergence error reduced by
• Proving the hypothesis ? Limited cases

31
current state

• there is no systematic AMG approach that has
  proven effective in any kind of general context
• BCFHJMMR, SIAM Journal on
  Scientific Computing, 2003

32
Overview

• Quick definitions
• Subgraph preconditioners
• Support graph preconditioners
• Algebraic expressions
• Low frequency eigenvectors and good partitionings
• Multigrid introduction and current state
• Multigrid Our contributions

33
our contributions two level

• There exists a good clustering given by R. The
  quality is measured by the condition number
  ?(A,S)
• Q RT A R
• Richardsons with
• Projection matrix

34
our contributions - two level analysis

• Starting hypothesis Let X be the subspace
  corresponding to eigenvalues smaller than ? . Let
  Y be the null space of Rproject RTD1/2
  Assume, ltX,Ygt2 ?/?
• Two level convergence error reduced by
• Proving the hypothesis ? Yes! Using ?(A,S)
• Result holds for t1 smoothing
• Additional smoothings do not help

35
our contributions - recursion

• There is a matrix M which characterizes the error
  reduction after one full multigrid cycle
• We need to upper bound its maximum eigenvalue as
  a function of the two-level eigenvalues
• the maximum eigenvalue of M is upper bounded by
  the sum of the maximum eigenvalues over all
  two-levels

36
towards full convergence

• Goal The error not reduced by smoothing must be
  reduced by the smaller grid
• A different point of view
• The small grid does not reduce part of the error.
  It rather changes its spectral profile.

37
full convergence for regular d-dimensional
toroidal meshes

• A simple change in the implementation of the
  algorithm
• where
• T2 has eigenvalues 1 and -1
• T2 xlow xhigh

38
full convergence for regular d-dimensional
toroidal meshes

• With tO(log log n) smoothings
• Using recursive analysis ?max(M) 1/2
• Both pre-smoothings and post-smoothings are
  needed
• Holds for perturbations of toroidal meshes

39
Overview

• Quick definitions
• Subgraph preconditioners
• Support graph preconditioners
• Algebraic expressions
• Low frequency eigenvectors and good partitionings
• Multigrid introduction and current state
• Multigrid Our contributions

40

• Thanks!
