Software Testing

• Sudipto Ghosh
• CS 406 Fall 99
• November 23, 1999

2
Learning Objectives

• Coverage Principle
• Saturation principle
• Mutation testing
• Test case generation and tool support
• Testing OO programs
• Testing distributed and real-time systems

3
Principle underlying test assessment

• Uniform principle that underlies test assessment
  throughout the testing process
• Coverage Principle
• Result of intensive research at Purdue and other
  research groups in software testing

4
The coverage principle

• To formulate and understand the coverage
  principle, we need to understand
• coverage domains
• coverage elements
• Coverage domain
• finite domain, related to the program under test
• Coverage element
• individual elements in the domain

5
The coverage principle (contd)
Coverage Domains
Coverage Elements
Requirements Functions Statements Branches All
uses All paths
6
The coverage principle

• Measuring test adequacy and improving a test set
  against a set of well-defined, increasingly
  strong, coverage domains leads to improved
  confidence in the reliability of the system under
  test.

7
The coverage principle (contd)

• Note the following properties of a coverage
  domain
• It is related to the program under test.
• It it finite.
• It may come from program requirements, related to
  the inputs and outputs.
• Exercise Give examples.
• It may come from the program code.
• Exercise Give examples.
• It aids in measuring test adequacy and the
  progress made in testing.

8
Using coverage criteria

• Improving coverage improves our confidence in the
  correct functioning of the program under test
• Given a program P, and a test set T, suppose that
  T is adequate w.r.t. a coverage criterion C.
• Does that mean that P is error free?
• Obviously ???

9
Test effort

• Several measures available
• Size of the test set T
• A test set with a larger number of test cases
  corresponds to higher effort than one with less
  number of test cases

10
Error detection effectiveness

• Each coverage criterion has its error detection
  ability.
• How do you measure effectiveness?
• Fraction f of faults guaranteed to be revealed by
  a test T that satisfies C.
• At least a fraction f of the faults in P will be
  revealed by test T that satisfies C.
• No absolute measure of effectiveness of any given
  coverage criterion for a general class of
  programs and arbitrary test sets.

11
Error detection effectiveness (contd)

• Empirical studies conducted by researchers give
  us an idea of the relative goodness of various
  coverage criteria.
• For a variety of criteria, we can make a
  statement like
• Criterion C1 is definitely better than C2.
• Sometimes, we can say
• Criterion C1 is probably better than C2.

12
Error detection effectiveness (contd)

• Such information allows us to construct a
  hierarchy of coverage criteria
• This hierarchy helps in organizing and managing
  testing.

13
The saturation effect

• The rate at which new faults are discovered
  reduces as test adequacy w.r.t. a finite coverage
  domain increases.
• The rate reduces to zero when the coverage domain
  is exhausted.

Rate of fault discovery
0
1
Coverage
14
Saturation effect Fault view
N
Remaining Faults
M
0
tfs
tfe
tds
tdfe
tme
Functional
Testing Effort
15
Saturation effect Reliability view
Rm
Rd
Rdf
Rf
Reliability
Rm
Rdf
Mutation
Rd
Dataflow
Rf
Decision
Functional
tfs
tfe
tds
tde
tdfs
tdfe
tms
tfe
True reliability (R) Estimated reliability
(R) Saturated region
Testing Effort
FUNCTIONAL, DECISION, DATAFLOW AND
MUTATION COVERAGE PROVIDE VARIOUS TEST EVALUATION
CRITERIA
16
Mutation testing

• Fundamentally different from previous approaches.
• Take a program.
• Create mutants by making simple changes.
• Goal of testing is to make sure that each mutant
  produces an output different from the output of
  the original program.

17
Mutant operators

• Makes a small unit change in the program
• Replace an arithmetic operator by another
• Replace a constant by another
• Change an array reference
• Change the label for a goto statement
• Replace a variable by a special value (like 0)
• First-order mutant obtained by making exactly one
  change.
• Need to model real faults.

18
Basis for mutation testing

• Competent programmer hypothesis
• Coupling effect

19
Competent programmer hypothesis

• Programmers are generally competent and dont
  create programs at random.
• A programmer produces a program that is very
  close to a correct program.
• A correct program can be constructed from an
  incorrect program with minor changes in the
  program.

20
Coupling effect

• Test cases that distinguish programs with minor
  differences with each other are so sensitive that
  they will also distinguish programs with more
  complex differences.

21
Mutation testing

• You are building up your test set T with test
  cases.
• Generate mutants for P. Suppose that there are N
  mutants.
• Execute each mutant and P on each test case in T.
• Find how many mutants were distinguished. These
  mutants are called dead. Let there be D dead
  mutants.

22
Mutation testing

• For each mutant that was not distinguished
  (called, live), find out how many are equivalent
  to P, i.e. they will always produce the same
  output as P. Let E be the number of equivalent
  mutants.
• The mutation score is
• Add more test cases to T and continue testing
  until the mutation score is 1.

23
Using mutation testing to improve test sets

• Empirically shown to be stronger than c-uses and
  p-uses.
• Suppose that you have used some coverage criteria
  and you have a test set T adequate w.r.t. the
  criteria.
• You have removed all the errors found during
  testing and now the program passes the tests in
  T.
• You can use mutation testing to improve T.

24
Performance

• Serious problem with mutation testing
• Number of mutants generated with the first-order
  operators is large
• Fortran For a program with L lines of code, the
  total number of mutants is L2
• All have to be compiled and executed
• Tester has to spend considerable time to decide
  if some mutants are equivalent. This is an
  undecidable problem.

25
Test case generation and tool support

• Once you have decided a coverage criterion, there
  are two problems
• Decide if a test set is adequate w.r.t. the
  criterion
• Generate a set of test sets
• Difficult to do both tasks manually
• Feasibility of a path is an undecidable problem

26
Test generation

• Fully automated tool not possible
• Tools aid the tester
• Ways
• Tool randomly generates tests until the criterion
  is satisfied
• Generates a lot of unnecessary tests

27
Test generation

• Testing is done manually by performing structural
  testing iteratively
• Tools gives feedback on what paths are left
• Static dataflow tools can be used to decide what
  input values should be given for that path to be
  executed
• Symbolic evaluation techniques can be used
• Ingenuity and creativity of the tester is
  important
• Often the criteria is weakened (lt 100)

28
Testing tools

• Usual steps
• Instrument the program with probes
• Execute the program with test cases
• Analyze the results of the probe data

29
Testing object oriented programs

• Not really different if you are using black-box
  testing
• Why is white-box testing different for OO?
• White-box likely to be at unit level.
• Basic unit is Class
• Fundamental differences between testing classes
  and functions
• Testing methods individually and functions may be
  similar

30
Testing OO Programs

• Testing all methods separately is not same as
  testing the class
• Class cannot be tested directly only an instance
  can be tested.
• How do you test abstract classes?
• Control flow characterized by message passing
  among objects, no sequential control flow within
  a class like in a function
• Different approach required.

31
Testing OO Programs

• State associated with object also influences the
  path of execution methods of a class can
  communicate among themselves using the state.
• for function, arguments and global variables
  determine the path of execution
• Inheritance
• structure of inheritance hierarchy
• kind of inheritance

32
Problems with inheritance

• Structure (lattice or tree)
• Lattice - a class at the bottom may inherit some
  features more than once
• Classes are more complex and error-prone
• Kind (strict or redefining allowed)
• Dynamic binding of operations, we dont know
  until run-time whether the operation is defined

33
Techniques

• Exercise the routines provided by an object with
  the goal of uncovering errors in the
  implementation of the routines or state of the
  object or both
• Find patterns of method invocation of the object
  under test with different arguments.
• State-based testing tests for interaction by
  changing the state of the object under which the
  methods are tested.

34
Testing distributed software

• Uniprocessor environment assumptions do not hold
• Global environment
• Deterministic execution
• Sequential execution of instructions
• Insertion of debugging statements do not alter
  execution of product
• Timing-dependent faults
• Need special techniques
• history files

35
Issues in testing real-time systems

• Real-world inputs
• No control over timing
• No control over order
• Similar problems as with distributed software
• Often no human operators
• More robustness required
• high fault-tolerance
• Difficulty in setting up test cases

36
Testing real-time systems

• Structure analysis
• Correctness proofs
• Systematic testing
• Statistical testing
• Simulation
