Conductivity Theory

1
Conductivity Theory

• Applied to Proper Hardware Selection

2
Conductivity Measurement

• Used to Measure and Control the Percent
  Concentration of Acids, Bases and Salts in
  Solution
• Measures Total Concentration
• Not Ion Specific
• May be Used to Determine the Dominant Chemical

3
Electrolytes

• Acids
• Substances which ionize in solution and produce
  hydrogen ions, H
• Hydrochloric Acid (HCl) dissociates into H Cl-
• Bases
• Substances which ionize in solution and produce
  hydroxide ions, OH-
• Sodium Hydroxide, NaOH, dissociates into Na
  OH-
• Salts
• Substances which ionize in solution and produce
  neither hydrogen or hydroxide ions
• Sodium Chloride, NaCl, dissociates into Na Cl-

4
Typical Conductivity Values
5
Conductivity Measurement

• Units of Measurement
• U.S. Units Micromhos/cm
• International Units MicroSiemens/cm
• 1.0 S/cm 1,000 mS/cm 1,000,000 uS/cm
• umho/cm uS/cm
• Conductivity is the Reciprocal of Resistance
• 1.0 MicroSiemen/cm 1,000,000 Ohms/-cm
• 1,000,000 MicroSiemens/cm 1.0 Ohm/-cm

6
Conductivity Measurement

• High Purity Water Applications
• Power Semiconductor Manufacturing
• Conductivity Measured as Resistivity in
  MegOhms/cm
• Pure Water 18.18 Meg Ohms/-cm 0.055 uS/cm
• Water Water Treatment Applications
• Industrial Boilers Cooling Towers
• Conductivity Measured in Total Dissolved Solids
  (TDS)

7
Conductance of Common Acids, Bases and Salts _at_
25oC
8
Conductivity Measurement

• Each Acid, Base and Salt has Its Own Temperature
  Vs. Concentration Curve
• The Temperature Slope Varies for Different
  Chemicals
• Acids 1.0 - 1.6 /oC
• Natural Waters 2.0/oC
• Bases gt 1.8 - 2.2/oC
• High Purity Water 2.3 - 7.3/ oC

9
Specific Conductivity of Sulfuric Acid
10
5.0 Sulfuric Acid Solution
11
Change in Temperature Slope/oC
12
Conductivity Measurement

• Apply an AC Voltage to Two Electrodes of Exact
  Dimensions
• Acids, Bases and Salts (NaCl) Dissolve in
  Solution and Act as Current Carriers
• The Current Flow is Directly Proportional to the
  Total Dissolved Solids in Solution
• The Physical Dimensions of a Conductivity
  Electrode are Referred to as the Cell Constant
• Cell Constant is Length/Area Relationship
• Distance Between Plates 1.0 cm
• Area of Each Plate 1.0 cm x 1.0 cm
• Cell Constant 1.0 cm-1
• Cell Constant
• Used to Determine the Measuring Range of the
  Analyzer
• Acts as Multiplier
• Used to Calibrate Analyzer
• Determined Using NBS Standards
• Can be NIST Traceable

13
Four Electrode Conductivity Cells

• Measures Current and Voltage Drop
• Current Increases with an Increase in Voltage
  Drop Across Electrodes
• Compensates for Minor Coatings on Conductivity
  Electrodes
• Used for Higher Range Measurement

14
Inductive Conductivity

• Also Known as Toroidal and Electrodless
• Principle of Measurement
• Two Sealed Wire Wound Coils Electrically Coupled
  by Solution Conductivity
• Advantage
• No Electrodes Exposed to the Measured Solution
• Not Affected by Coating
• Disadvantage
• - 10 Accuracy
• High Range Measurement Only gt 100 uS/cm

15
Reverse Osmosis Unit
pH Transmitter
Feed Water
Acid Feed
Feed Water Tank
Conductivity Transmitter
RO Unit
Waste
16
Demineralizer Unit
Acid Regeneration
Caustic Regeneration
Conductivity Transmitter
Conductivity Transmitter
Mixed Bed
Anion Bed
Cation Bed
Conductivity Transmitter
To Water Storage
Conductivity Transmitter
Conductivity Transmitter
17
Power Utilities Average Number of Analyzers for
Each Demin Unit

• Type Number
• Conductivity 4
• Concentration 2
• pH 1
• Total 7
• Usually 2 per generation unit (make up
  polisher) and built in pairs
• Total X 4 28 Analyzers per Unit
• Two Units Built at a time 56 Analyzers

18
Power Utilities Average Number of Analyzers Per
Generating Unit

• Analyzer Type Number
• pH 5
• Specific Conductivity 6
• Cation Conductivity 11
• Condensate Analyzer 1
• Total 23
• Usually Units Built in Pairs 46 Analyzers

19
Boiler Blowdown and Condensate Return Lines
20
Clean in Place (CIP)
Conductivity Transmitter
CIP Return Lines
Caustic
Process Vessels
Caustic Dilution Tank
Solution Recovery
Conductivity Transmitter
Water
