3G Network

1
3G Network
Disampaikan oleh

• Uke Kurniawan Usman

2
The idea 3G Network
Pendahuluan
The Convergence

• Mobile telephony
• The internet technology
• Media business

3G Network
Kebutuhan akses informasi dimana saja
Driven technology
high speed mobile access with Internet Protocol
(IP)-based services
Multimedia, hiburan, dsb
3
Pendahuluan
Syarat-Syarat 3G
Data sirkuit dan paket kecepatan tinggi 144 kbps
vehicular 384 kbps pedestrian 2 Mbps Indoor
Transmisi Simetrik Asimetrik
Enhanced Voice
Communications Entertainment E-Commerce Informatio
n Transaction Travel
Aplikasi Multi-Media
Global Roaming 3G? 3G 2G ? 3G
Multi-Environment Operation Vehicular, Outdoor
to Indoor, Indoor Office, Satellite
4
Technology
Pendahuluan

• 1G
• wireless

AMPS (Advanced Mobile Phone Service)
- Analog voice service - No data service
2G wireless
CDMA (Code Division Multiple Access) TDMA (Time
Division Multiple Access) GSM (Global System for
Mobile Communications) PDC (Personal Digital
Cellular)
- Digital voice service - 9.6K to 14.4K
bit/sec. - CDMA, TDMA and PDC offer one-way
data transmissions only - Enhanced calling
features like caller ID - No always-on data
connection
3G wireless
W-CDMA (Wide-band Code Division Multiple
Access) CDMA-2000
- Superior voice quality - Up to 2M bit/sec. -
always-on data - Broadband data services like
video multimedia - Enhanced roaming
5
Pendahuluan
2G Vs 3G
6
3G didesain untuk memberikan .
Pendahuluan

• Aplikasi-aplikasi dari lingkup market yang luas
  , market mengendalikan teknologi
• Komunikasi dan terminal yang Advanced,
  lightweight, easy-to-use terminal
• Instant, real-time multimedia communications
• Global mobility and roaming
• A wide range of vendors and operators, offering
  choice, competition and affordability
• High-speed e-mailand Internet access

7
Pendahuluan
Kemampuan 3G .

• 1. Capability to support circuit and packet data
  at high bit rates
• 144 kilobits/second or higher in high mobility
  (vehicular) traffic
• 384 kilobits/second for pedestrian traffic
• 2 Megabits/second or higher for indoor traffic
• 2. Interoperability and roaming
• 3. Common billing/user profiles
• Sharing of usage/rate information between service
  providers
• Standardized call detail recording
• Standardized user profiles
• 4. Capability to determine geographic position of
  mobiles and report it to both the network and the
  mobile terminal
• 5. Support of multimedia services/capabilities
• Fixed and variable rate bit traffic Bandwidth on
  demand
• Asymmetric data rates in the forward and reverse
  links
• Multimedia mail store and forward
• Broadband access up to 2 Megabits/second

8
Problems

• Tanggapan market .perlukah layanan 3G ?
• Data trafik adalah campuran antara dedicated data
  (voice) dan non dedicated data
• QoS masing-masing layanan berbeda

Lalu bagaimana..?
9
Problems

• Tanggapan market

Perlu jaringan transisi untuk membiasakan pasar
dengan layanan 3G
Kemampuan Fungsional
IMT-2000 capable systems
WCDMA 2 Mbps
EDGE/IS-136 384 kbps
GPRS 115 kbps
Packet Switched
HSCSD 57.6 kbps
Circuit Switched
Circuit data lt9.6 kbps
Speech
10
Problems

• Data trafik adalah campuran antara dedicated data
  (voice) dan non dedicated data

Perlu dipisahkan antara trafik suara (dedicated
channel) dengan trafik data
GMSC
PSTN
Circuit Switched Traffic
MSC
MAP
A-bis
A
HLR/AUC GPRS Register
Peer Elements
BSC
BTS
GPRS Register H/VLR
PCU
MAP
Gb
SGSN
SGSN
Packet Traffic
Gn
GGSN
GGSN
Gi
11
Problems

• QoS masing-masing layanan berbeda

Pemberian prioritas yang berbeda tergantung
data yang dilewatkan trafik suara, atau data,
atau suara yang dijadikan data
Suara (dedicated channel)
Probabilitas Blocking
3G
Throghput, delay
Data (non dedicated channel)
12
Voice Over IP
Problems
Cost
PSTN
PPDN
Problem
GGSN
GMSC
Throughput untuk VoIP secara independentharus
lebih besar dari throughput untuk data yang lain
( internet, fax, dsb )karena memerlukan delay
yang lebih rendah
MSC
SGSN
XCDR
Voice over Packet
Voice over Circuit
BTS
?
?

• Transmission
• MSC Costs
• Transcoders

• Transmission
• IP Routers
• Media Gateways

13
Arsitektur
The Service provider
Server
IP Address
PSTN
GGSN
GMSC
SGSN
MSC
GPRS SERVICE IMPLEMENTATION
XCDR
GSM SERVICE IMPLEMENTATION
BTS
Phone (Client)
14
Arsitektur Lengkap
Integrasi Dengan 3G
Ini jaringan 3G dengan kemampuan yang lengkap !!
15
E-commerce
E- Commerce Over 3G
16
3G Network
to Others Fixed/Mobile Networks
Common 2G/3G Core Network - switch nodes -
services nodes - transport pipes
2G network
3G network
2G Mobile Phone and Devices
Dual Band 2G/3G Mobile Phone and Devices
3G Mobile Phone and Devices
17
Diskusi
Transmisi

• Unjuk kerja transmisi pita lebar, indoor dan
  outdoor
• Perencanaan transmisi WCDMA ( kapasitas,
  efisiensi spektrum, perilaku sel terhadap
  interferensi (cell breathing), analisis handoff,
  dsb
• Perbaikan sistem (smart antenna, software radio)
  dan unjuk kerjanya
• dll

Jaringan

• Interkoneksi antar jaringan dan topologi
• Billing, roaming
• Protokol dan signalling
• Dll
