Mining frequent patterns in a database

1
Mining frequent patterns in a database

• Advisor Anthony J. T. Lee
• Presenter Chun-sheng Wang

2
Outline

• Introduce the basic concept of data mining
• Topic 1 Mining frequent itemsets with
  multi-dimensional constraints
• Topic 2 Mining inter-transactional patterns
• Topic 3 Mining Inter-sequence patterns
• Topic 4 Mining closed patterns
• Topic 5 Mining patterns in a time-series database

3
Basic Concept of Data Mining

• Data mining is the task of discovering knowledge
  from a large amount of data.
• One of the fundamental data mining problems, is
  to mine frequent patterns.
• Frequent pattern mining is to discover all the
  patterns whose supports in the database exceed a
  user-specified threshold.

4
Applications

• Association rules
• Financial data analysis
• Web traversal analysis
• Weather forecasting
• Bioinformatic data mining
• Multimedia data mining
• Traversal path analysis

5
Association Rules

• Association rule is of the form X?Y, where X and
  Y are both frequent itemsets in the given
  database and X?Y?.
• The support of X?Y is the percentage of
  transactions in the given database that contain
  both X and Y, i.e., P(X?Y).
• The confidence of X?Y is the percentage of
  transactions in the given database containing X
  that also contain Y, i.e., P(YX).

6
Frequent Itemsets Mining

• frequent itemsets
• (a)2,(b)2,(c)4,(d)2
• (ac)2,(ad)2,(bc)2,(cd)2
• (acd)2
• c ? d
• support50
• confidence100

7
Sequential Patterns

• A sequence is an ordered list of itemsets, and
  denoted by lts1s2slgt, where sj is an itemset.
• sj is also called an element of the sequence, and
  denoted as (x1x2xm), where xk is an item.
• The support of a sequence ? in a sequence
  database is the number of sequences containing ?.
• A sequence ? is called a sequential pattern if
  its support ? min-support.

8
Sequential Patterns Mining

• frequent patterns
• lt(a)gt4,lt(b)gt2,lt(c)gt2
• lt(ab)gt2,lt(c),(a)gt2,
• lt(c),(b)gt2
• lt(c),(ab)gt2

9
Algorithm of Mining Frequent Itemsets

• Apriori
• Candidate generation-andtest
• Level-wise it iteratively generates candidate
  k-itemsets from previously found frequent
  (k-1)-itemsets, and then checks the supports of
  candidates to form frequent k-itemsets.
• Lk-1

Lk
Ck
10
Apriori example

• L1(a)2,(b)2,(c)4,(d)2
• C2(ab),(ac),(ad),(bc),(bd),(cd)
• L2(ac)2,(ad)2,(bc)2,(cd)2
• C3(acd)
• L3(acd)2

11
Algorithm of Mining Frequent Itemsets (contd)

• FP-growth
• The method constructs a compressed frequent
  pattern tree, called FP-tree.
• A divide-and-conquer strategy is used to
  recursively decompose the mining task into a set
  of smaller tasks in conditional databases, and to
  concatenate the suffix itemset with the frequent
  itemsets generated from a conditional FP-tree.

12
T
Td
13
Algorithm of Mining Sequential Patterns-PrefixSpan

• It finds length-1 sequential patterns in the
  target database first, and partitions the
  database into smaller projected databases with
  the prefix of each sequential pattern previously
  found.
• The sequential patterns can be mined by
  constructing corresponding projected databases,
  each of which can be mined recursively.
• It preserves the element order in the mining
  process.

14
(No Transcript)
15
Topic 1 Mining Frequent Itemsets with
Multi-dimensional Constraints

• Frequent itemset mining often generates a very
  large number of frequent itemsets.
• Only the subset of the frequent itemsets and
  association rules is of interest to users.
• Users need additional post-processing to find
  useful ones.
• Constraint-based mining pushes user-specific
  constraints deep inside the mining process to
  improve performance.
• With multi-dimensional items, constraints can be
  imposed on multiple dimensional attributes.

16
Topic 1 Mining Frequent Itemsets with
Multi-dimensional Constraints
Multi-dimensional Constraints
itemID a1 a2 . am ik
(k1, k2 , km) A iA (A1,
A2,, Am) A1A.a1
17
Topic 1 Mining Frequent Itemsets with
Multi-dimensional Constraints

• Multi-dimensional constraints can be categorized
  according to constraint properties.
• anti-monotone, monotone, convertible and
  inconvertible
• It can be also classified according to the number
  of sub-constraints included.
• Single constraint against multiple dimensions,
• Ex max(S.cost) ? min(S.price)
• Conjunction and/or disjunction of multiple
  sub-constraints,
• Ex (C1 S.cost ? v1) ? (C2 S.price ? v2)

18
Anti-monotone Monotone

• Anti-monotone A constraint Ca is anti-monotone
  if and only if whenever an itemset S violates Ca,
  so does any superset of S.
• Ex min(S) ? v
• Monotone A constraint Cm is monotone if and only
  if whenever an itemset S satisfies Cm, so does
  any superset of S.
• Ex max(S) ? v

19
Topic 1 Mining Frequent Itemsets with
Multi-dimensional Constraints

• We extend constraints to place over
  multi-dimensional itemsets and develop algorithms
  to mine frequent itemsets with multi-dimensional
  constraints by extension of CFG (Constrained
  Frequent Pattern Growth),
• Overview of our algorithm
• Phase 1 Frequency check
• Phase 2 Constraint check
• Phase 3 Conditional database construction

20
Example Cam ? max(S.cost) ? min(S.price)

d-conditional Database d-conditional Database
c,a c,a


Database Database
c c,a,d c,b c,a,b,d c c,a,d c,b c,a,b,d


Frequent items c,a
Frequent items c, a, b, d
a,d-conditional Database



21
Results
22

• Anthony J. T. Lee, Wan-chuen Lin and Chun-sheng
  Wang, Mining association rules with
  multi-dimensional constraints, The Journal of
  Systems and Software, Vol. 79, No. 1, pp. 79-92,
  2006.

23
Topic 2 Mining Inter-transactional Patterns

• A transaction could be the items bought by the
  same customer, or the events happened on the same
  day, and so on.
• Intra-transactional association rules
  associations among items within the same
  transaction.
• Ex buy (X, diapers) gt buy (X, beer)
  support80
• Inter-transactional association rules
  association relations across different
  transactions.
• Ex If the prices of IBM and SUN go up,
  Microsofts will most likely 80 increases the
  next day.

24
Topic 2 Mining Inter-transactional Patterns

• Extended transaction denoted by
• z(t2-t1)u1(t2-t1), u2(t2-t1), , un(t2-t1)
• Extended item denoted as u1(t2-t1)
• Reference point t1
• Megatransaction y z1(0)?z2(t2-t1)? ...
  ?zk(tk-t1)
• Maxspan tk-t1 lt maxspan in y

25
Example
26
ITP-miner Example
27
Results
28
Topic 3 Mining Inter-sequence Patterns

• Inter-sequence model

Transaction ID
1
2
3
4
5
6
7
8
9
10
1
2
3
4
5
6
7
8
9
10
Transaction Time
ltc(ab)d(ad)gt
lt gt
ltdd(ac)bdgt
ltbcgt
lt(bc)cbgt
lte(ac)bacgt
ltb(ab)ccgt
ltabgt
ltaccgt
ltceacc(ce)gt
29
Application Example

• The degree of daily stock price movement can also
  be viewed as a sequence.
• The inter-transaction association rule
• If stock A and stock B go up on day 1, stock C
  and stock D are very likely to go up on day 3.
• Rule ?0(AB) ? ?2(CD)
• The inter-sequence association rule
• If stock B goes up more than stock A on day 1,
  stock D is very likely to go up more than stock C
  on day 3.
• Rule ?0ltBAgt ? ?2ltDCgt

30
Example
The database

• min_support 3
• maxspan 1

31
ISP-Miner Algorithm
32
ISP-Miner Algorithm
33
Results
34
Topic 4 Mining Closed Patterns

• frequent itemsets
• (a)2,(b)2,(c)4,(d)2
• (ac)2,(ad)2,(bc)2,(cd)2
• (acd)2
• Closed itemsets
• (c)4,(bc)2,(acd)2

35
Topic 5 Mining Closed Patterns in a Time-series
Database

• A time-series segment is an ordered and
  continuous list in the form t1, t2, , tm
  describing the property of the subject over time.
• Step 1 Find the frequent segments and points in
  each segment-set. (suffix tree construction)
• Step 2 Use those frequent segment-sets to find
  the associations among them. (suffix tree closed
  patterns mining)

36
Topic 5 Mining Closed Patterns in a Time-series
Database
37
Step 1 Frequent Segment Discovery (Suffix Tree
Approach)
38
Thank You!
39
References

• R. Agrawal and R. Srikant. Fast algorithms for
  mining association rules, In Proceeding of Int.
  Conf. on Very Large Data Bases, pages 487-499,
  Santiago, Chile, September 1994.
• H. Lu, L. Feng, and J. Han, Beyond
  intratransaction association analysis mining
  multidimensional inter-transaction association
  rules. ACM Transactions on Information Systems,
  18(4), pages 423-454, October 2000.
• J. Pei, J. Han, B. Mortazavi-Asl, J. Wang, H.
  Pinto, Q. Chen, U. Dayal, and M.-C. Hsu. Mining
  Sequential Patterns by Pattern-Growth The
  PrefixSpan Approach. IEEE Transactions on
  Knowledge and Data Engineering, 16(10), pages
  1424-1440, 2004.
• A. K. H. Tung, H. Lu, J. Han, and L. Feng.
  Efficient mining of intertransaction association
  rules. IEEE Transactions on Knowledge and Data
  Engineering, 15(1), pages 43-56, January 2003.
• J. Han, J. Pei, Y. Yin and R. Mao, Mining
  Frequent Patterns without Candidate Generation A
  Frequent-Pattern Tree Approach, Data Mining and
  Knowledge Discovery, 8(1)53-87, 2004.
• Anthony J. T. Lee, Wan-chuen Lin and Chun-sheng
  Wang, Mining association rules with
  multi-dimensional constraints, The Journal of
  Systems and Software, Vol. 79, No. 1, pp. 79-92,
  2006.
